WS-C3560CX-8PC-S compact enterprise class layer 3 switch offers 8-port Gigabit Ethernet data POE+ models. This switch support both 2 x 1 Gigabit copper and 2 x 1 Gigabit SFP uplinks.
Quick Specs
Figure 1 shows the appearance of WS-C3560CX-8PC-S.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C3560CX-8PC-S |
|
Feature Set |
IP Base |
|
Uplink Interfaces |
2 Gigabit Ethernet RJ-45 uplinks, 2 SFP upliks |
|
Ports |
8 x Gigabit Ethernet ports |
|
Forwarding Bandwidth |
16 Gbps |
|
Switching Bandwidth (full-duplex capacity) |
32 Gbps |
|
Available POE Power |
240W |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Dimensions |
4.44 x 26.9 x 23.8 cm |
|
Package Weight |
4.65 kg |
Product Details
Figure 2 shows the front panel of WS-C3560CX-8PC-S.
Note:
|
① |
Mode button |
⑤ |
SFP module slots |
|
② |
USB Type A port |
⑥ |
12 x 10/100/1000 ports |
|
③ |
USB mini-Type B (console) port |
⑦ |
Switch LEDs |
|
④ |
2 x 1G copper |
⑧ |
RJ-45 Console Port |
·Switch LEDs include SYST, STAT, SPEED, POE LEDs and Console LED.
Table 2 shows the three LEDs descriptions.
|
LED |
Color/Port Mode |
Description |
|
SYST (System LED) |
Off |
System is not powered on. |
|
Green |
System is operating normally. |
|
|
Amber |
System is receiving power but is not operating properly. |
|
|
STAT |
Port status |
The port status. This is the default mode. |
|
SPEED |
Port speed |
The port operating speed: 10, 100, or 1000 Mb/s. |
|
POE |
Off |
PoE is not enabled. |
|
Green |
PoE is enabled. Ports are functioning correctly. |
|
|
Blinking Amber |
· PoE mode is not selected · At least one of the 10/100 or 10/100/100 PoE ports has been denied power · At least one of the ports has a PoE fault |
The console LEDs show which console port is in use.
If you connect a cable to a console port, the switch automatically uses that port for console communication. If you connect two console cables, the USB-mini console port has priority.
Table 3 shows the Console LED description.
|
LED |
Color |
Description |
|
RJ-45 console port |
Green |
RJ-45 console port is active. USB-mini console port LED is not active. |
|
Off |
Port is not active. USB-mini console port is active. |
|
|
USB-mini console port |
Green |
USB-mini console port is active. RJ-45 console port LED is not active. |
|
Off |
Port is not active. RJ-45 console port is active. |
The Accessories
Table 4 shows some recommended cables.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
Compare to similar item
|
Models |
WS-C3560CX-8PC-S |
|
|
Uplinks |
2 x 1G copper plus 2 x 1G SFP+ |
2 x 1G copper plus 2 x 1G SFP+ |
|
Ports |
12 x 10/100/1000 Gigabit Ethernet |
8 x 10/100/1000 Gigabit Ethernet |
|
Feature set |
IP Base |
IP Base |
|
PoE Output Ports |
12 PoE+ |
12 PoE+ |
|
Available POE Power |
240W |
240W |
Get more information
Do you have any question about the WS-C3560CX-8PC-S?
Contact us now via Live Chat or [email protected].
WS-C3560CX-8PC-S Specification
WS-C3560CX-8PC-S Specifications |
|
| Product Model | WS-C3560CX-8PC-S |
| Ports | 8 x 10/100/1000 Ethernet Ports |
| Uplinks | 2 SFP & 2 GE uplinks |
| Layer | Layer 3 |
| Power over Ethernet (PoE) | Yes |
| Flash Memory Installed | 128 megabyte |
| RAM Installed | 512 megabyte |
| PoE Budget | 240 watt |
| Power Over Ethernet (PoE) | PoE+ |
| Switching Type | Gigabit Ethernet |
| Frequency | 50/60 hertz |
| Software Type | Cisco IOS IP Base |
| MTBF | 569,530 Hours |
| QoS Support | Yes |
| Management | CLI, Web management, SNMP |
| Security Features | ACLs, Port security, DHCP snooping |
| Product Dimensions (W x D x H) | 10.6 x x9.4 x 1.7 inch |
| Operating Humidity | 5 - 95% (non-condensing) |
