Cisco Catalyst compact switches easily extend an intelligent, fully managed Cisco Catalyst wired switching infrastructure, including end-to-end IP and Borderless Network services, with a single Ethernet cable or fiber from the wiring closet. WS-C2960CPD-8TT-L is one of Cisco Catalyst 2960 compact series switches. It offers two 1G (PoE+ input) uplinks and eight 10/100 Fast Ethernet ports.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
WS-C2960CPD-8TT-L |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x 1G (PoE+ input) |
|
Ports |
8 x 10/100 Fast Ethernet |
|
Forwarding Bandwidth |
10 Gbps |
|
RAM |
128 MB |
|
Flash Memory |
64 MB |
|
Dimensions |
4.44 x 26.9 x 17.2 cm |
|
Package Weight |
3.37 Kg |
Product Details
Figure 1 shows the front panel of WS-C2960CPD-8TT-L.
Note:
· There are two console ports on the front panel, including RJ-45 console port and USB mini-Type B (console) port.
· Eight 10/100 Fast Ethernet ports are on the front panel.
· Two 1G uplinks support PoE+, which can supply power for other devices.
The Accessories
Table 2 shows some recommended cables and SFP modules.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
|
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
1000BASE-BX SFP, 1490NM |
|
|
1000BASE-BX SFP, 1310NM |
|
|
100BASE-FX SFP for FE port |
|
|
100BASE-LX SFP for FE port |
|
|
100BASE-BX10-D SFP |
|
|
100BASE-BX10-U SFP |
Compare to similar item
Table 3 shows the comparison between WS-C2960CPD-8TT-L and WS-C2960CPD-8PT-L.
|
Models |
WS-C2960CPD-8TT-L |
|
|
Uplinks |
2 x 1G (PoE+ input) |
2 x 1G (PoE+ input) |
|
Ports |
8 x 10/100 Fast Ethernet |
8 x 10/100 Fast Ethernet |
|
Available PoE Power |
N/A |
8 PoE Output Ports, Up to 30.8W |
|
Feature set |
LAN Base |
LAN Base |
Get more information
Do you have any question about the WS-C2960CPD-8TT-L?
Contact us now via Live Chat or [email protected].
WS-C2960CPD-8TT-L Specification
WS-C2960CPD-8TT-L Specifications |
|
| Model | WS-C2960CPD-8TT-L |
| Brand | Cisco |
| Product Type | Ethernet Switch |
| Manageable | Yes |
| Ethernet Technology | Gigabit Ethernet,Fast Ethernet |
| Product Family | Catalyst 2960-C |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 10 |
| PoE (RJ-45) Port | No |
| Form Factor | Desktop,Rack-mountable,Wall Mountable |
| Power Source | Power Supply |
| Layer Supported | 2 |
| Uplink Port | Yes |
| Port / Expansion Slot Details | 8 x Fast Ethernet Network,2 x Gigabit Ethernet Uplink |
| Network Technology | 10/100/1000Base-T,10/100Base-TX |
| Limited Warranty | Lifetime |
| Flash Memory | 64 MB |
| Dimensions(H X W X D) | 1.8'' x 10.6'' x 6.8'' |
| Standard Memory | 128 MB |
| Operating Humidity | 10% to 85% (non-condensing) |
