USG6712E-AC

Brands: Huawei
(0 reviews)
95063.62 105626.25 10% Off

Model: USG6712E-AC - Huawei USG6712E&USG6716E New-Generation Firewalls

Detail: Huawei USG6712E AC Host (2*100G (QSFP28) + 2*40G (QSFP+) + 20*10GE (SFP+) + 2*10GE (SFP+) HA AC Power)

Huawei USG6712E is Huawei's next-generation firewall. It provides the latest features and works in conjunction with other security devices to actively defend against network threats, enhance border detection functions, effectively defend against advanced threats and solve performance degradation problems.

Quick Spec

Table 1 shows the Quick Specs.

Product Code

USG6716E-AC

Description

USG6712E AC Host [2 x 100G (QSFP28) + 2 x 40G (QSFP+) + 20 x 10 GE (SFP+) + 2 x 10 GE (SFP+) HA, and AC Power]

Dimensions (H x W x D) mm

44 x 442 x 600

Form Factor/Height

1U

USB Port

1 x USB 3.0

MTBF

25 years

IPv4 Firewall Throughput1 (1518/512/64-byte, UDP)

120/120/100 Gbit/s

IPv6 Firewall Throughput1 (1518/512/84-byte, UDP)

120/120/26 Gbit/s

Firewall Throughput (Packet Per Second)

150 Mpps

VLANs (Maximum)

4094

VLANIF Interfaces (Maximum)

1024

High Availability Configurations

Active/Active, Active/Standby

Product Details

Huawei USG6712E provides these features:

 Comprehensive and integrated protection

* Integrates the traditional firewall, VPN, intrusion prevention, antivirus, data leak prevention, bandwidth management, URL filtering, and online behavior management functions all in one device.

* Interworks with the local or cloud sandbox to effectively detect unknown threats and prevent zero-day attacks.

* Implements refined bandwidth management based on applications and websites, preferentially forwards key services, and ensures bandwidth for key services.

 More comprehensive defense

* The built-in traffic probe of a firewall extracts traffic information and reports it to the CIS, a security big data analysis platform developed by Huawei. The CIS analyzes threats in the traffic, without decrypting the traffic or compromising the device performance. The threat identification rate is higher than 90%.

* The deception system proactively responds to hacker scanning behavior and quickly detects and records malicious behavior, facilitating forensics and source tracing.

 High performance

* Enables pattern matching and accelerates encryption/decryption, improving the performance for processing IPS, antivirus, and IPSec services.

* The throughput of a 1U device can reach 160 Gbit/s.

 High port density

* The device has multiple types of interfaces, such as 100G, 40G, and 10G interfaces. Services can be flexibly expanded without extra interface cards.

Compare to Similar Items

Table 2 shows the comparison.

Product Code

USG6712E-AC

USG6716E-AC

Description

USG6712E AC Host [2 x 100G (QSFP28) + 2 x 40G (QSFP+) + 20 x 10 GE (SFP+) + 2 x 10 GE (SFP+) HA, and AC Power]

USG6716E AC Host (2*100G (QSFP28) + 2*40G (QSFP+) + 20*10GE (SFP+) + 2*10GE (SFP+) HA, AC Power)

Dimensions (H x W x D) mm

44 x 442 x 600

44 x 442 x 600

Form Factor/Height

1U

1U

IPv4 Firewall Throughput1 (1518/512/64-byte, UDP)

120/120/100 Gbit/s

160/160/100 Gbit/s

IPv6 Firewall Throughput1 (1518/512/84-byte, UDP)

120/120/26 Gbit/s

160/120/26 Gbit/s

FW+SA* Throughput2

55 Gbit/s

60 Gbit/s

FW+SA+IPS Throughput2

40 Gbit/s

40 Gbit/s

FW+SA+IPS+Antivirus Throughput2

35 Gbit/s

38 Gbit/s

Full Protection Throughput3

33 Gbit/s

36 Gbit/s

Full protection Throughput (Realworld)4

16 Gbit/s

18 Gbit/s

Concurrent Sessions (HTTP1.1)1

35,000,000

50,000,000

New Sessions/Second (HTTP1.1)1

1,400,000

1,600,000

IPSec VPN Throughput1 (AES-256+SHA256, 1420-byte)

100 Gbit/s

120 Gbit/s

Get More Information

Do you have any question about the USG6712E-AC?

Contact us now via Live Chat or [email protected].

USG6712E-AC Specification

USG6712E-AC Specification

Description

USG6712E AC Host [2 x 100G (QSFP28) + 2 x 40G (QSFP+) + 20 x 10 GE (SFP+) + 2 x 10 GE (SFP+) HA, and AC Power]

Dimensions (H x W x D) mm

44 x 442 x 600

Form Factor/Height

1U

Fixed Interface

2*100G (QSFP28) + 2*40G (QSFP+) + 20*10GE (SFP+) + 2*10GE (SFP+) HA1

Note

1. Some 10G ports and 100G ports are mutually exclusive. The ports can be configured as follows: 2 * 100G (QSFP28) + 2 * 40G (QSFP+) + 12 * 10GE (SFP+) + 2 * 10GE (SFP+) HA or 4 * 40G (QSFP+) + 20 * 10GE (SFP+) + 2 * 10GE (SFP+) HA

USB Port

1 x USB 3.0

MTBF

25 years

Weight (Full Configuration)

12 kg

Local Storage

Optional, SSD (1*2.5inch) supported, 240G/HDD (1*2.5inch supported, 1TB

AC Power

Supply 100V to 240V, 50/60Hz

Power Consumption (Average/Maximum)

382.9W/566W

Heat Dissipation

>1935.3 BTU/h

Power Supplies

Dual AC power supplies

Operating Environmen(Temperature/Humidity)



Temperature: 0°C to 45°C (without optional HDD);

5°C to 40°C (with optional HDD)

Humidity: 5% to 95% (without optional HDD), non-condensing;

5% to 95% (with optional HDD), non-condensing

Non-operating Environment



Temperature: -40°C to +70°C

Humidity: 5% to 95% (without optional HDD), non-condensing;

5% to 95% (with optional HDD), non-condensing

Operating Altitude (maximum)

5,000 meters (without optional HDD);

3,000 meters (with optional HDD)

Non-operating Altitude (maximum)

5,000 meters (without optional HDD);

3,000 meters (with optional HDD)

Noise

Maximum value < 72 dBA

IPv4 Firewall Throughput1 (1518/512/64-byte, UDP)

120/120/100 Gbit/s

IPv6 Firewall Throughput1 (1518/512/84-byte, UDP)

120/120/26 Gbit/s

Firewall Throughput (Packet Per Second)

150 Mpps

Firewall Latency (64-byte, UDP)

15 µs

FW+SA* Throughput2

55 Gbit/s

FW+SA+IPS Throughput2

40 Gbit/s

FW+SA+IPS+Antivirus Throughput2

35 Gbit/s

Full Protection Throughput3

33 Gbit/s

Full protection Throughput (Realworld)4

16 Gbit/s

Concurrent Sessions (HTTP1.1)1

35,000,000

New Sessions/Second (HTTP1.1)1

1,400,000

IPSec VPN Throughput1 (AES-256+SHA256, 1420-byte)

100 Gbit/s

Maximum IPsec VPN Tunnels (GW to GW)

120,000

Maximum IPsec VPN Tunnels (Client to GW)

120,000

SSL Inspection Throughput5

18 Gbit/s

SSL VPN Throughput6

10 Gbit/s

Concurrent SSL VPN Users (Default/Maximum)

100/30000

Firewall Policies (Maximum)

60,000

Virtual Firewalls (Maximum)

1,000

URL Filtering: Categories

More than 130

URL Filtering: URLs

Can access a database of over 120 million URLs in the cloud

Automated Threat Feed and IPS Signature Updates

Yes

Third-Party and Open-Source Ecosystem



Open API for integration with third-party products, providing RESTful and NetConf interface

Other third-part management software based on SNMP, SSH, Syslog

Co-operation with third-party tools, such as Tufin, Algosec and Firemon

Collaboration with Anti-APT solution

Centralized Management

Centralized configuration, logging, monitoring, and reporting is performed by Huawei eSight and eLog

VLANs (Maximum)

4094

VLANIF Interfaces (Maximum)

1024

High Availability Configurations

Active/Active, Active/Standby

1. Performance is tested under ideal conditions based on RFC2544, 3511. The actual result may vary with deployment

environments.

2. Antivirus, IPS, and SA performances are measured using 100 KB HTTP files.

3. Full protection throughput is measured with Firewall, SA, IPS, Antivirus and URL Filtering enabled. Antivirus, IPS and SA

performances are measured using 100 KB HTTP files.

4. Full protection throughput (Realworld) is measured with Firewall, SA, IPS, Antivirus and URL Filtering enabled, Enterprise

Mix Traffic Model.

5. SSL inspection throughput is measured with IPS-enabled and HTTPS traffic using TLS v1.2 with AES128-GCM-SHA256.

6. SSL VPN throughput is measured using TLS v1.2 with AES128-SHA.

*SA: Service Awareness.

Note: All data in this document is based on USG V600R006.

Hardware

CB, CE-SDOC, ROHS, REACH&WEEE(EU), RCM, NRTL, FCC&IC, CCC, VCCI

Regulatory Compliance



Products comply with EU directives 2014/30/EU (Low Voltage Directive), 2014/35/EU (EMC Directive), and 2011/65/EU (RoHS Directive).

Safety



UL 60950-1

CSA-C22.2 No. 60950-1

EN 60950-1

IEC 60950-1

EMC: Emissions



EN55032 Class A

CISPR 32 Class A

ETSI EN 300 386

AS/NZS CIPSR 32

CAN/CSA-CISPR 32-17

IEC 61000-3-2/EN 61000-3-2

IEC 61000-3-3/EN 61000-3-3

FCC CFR47 Part 15 Subpart B Class A

ICES-003 Class A

VCCI V-3 Class A

EMC: Immunity



EN 55024

CISPR 24

ETSI EN 300 386
