877621-001 is the HPE ProLiant ML350 Gen10 4110 2.1GHz 8-core 1P 16GB-R P408i-a 8SFF 1x800W RPS Base Server. Driving a wide range of workloads with a flexible, shorter and rackable chassis design that can fit in different physical environments, the secure 2P HPE ProLiant ML350 Gen10 Server delivers the ideal set of performance and expandability for changing business needs making it the choice for growing SMBs, remote/branch offices of large enterprises and data centers.
Quick Spec
Table 1 shows the quick spec.
|
SKU |
877621-001 |
|
Model Name |
HPE ML350 Gen10 4110 1P 16G 8SFF P408i-a 800W FS RPS Base Tower Server |
|
Processor |
4110 (8-Core, 2.1 GHz, 85W) |
|
Number of Processors |
One processor |
|
Memory |
16 GB RDIMM SR 2600 MT/s (1x 16 GB) NOTE: running at 2400 MT/s per processor support |
|
Network Controller |
Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter NOTE: embedded 4x1GbE HPE Ethernet 1Gb 4-port 369i Adapter does not support speeds of 100MB/s and 10MB/s. |
|
Storage Controller |
P408i-a NOTE: 8-Port modular Smart Array. NOTE: Smart Storage battery included. |
|
Hard Drive |
None ship as standard |
|
Internal Storage |
8 SFF chassis with optional SFF HDD Cage Kit (874568-B21) to be selected. Upgradeable to 24 SFF max. Opt. 8 SFF NVMe Express Bay Kit (874569-B21) |
|
Form Factor |
4U Tower |
Product Details
Figure 1 shows the Front View – SFF chassis with optional Gen10 8SFF HDD Cage Kits shown (Rack mode), and Rear View – With HPE Flex Slot RPS shown.
Note (Front View):
|
① |
iLO Service Port |
⑦ |
Power On/Stand-by button and System Power LED |
|
② |
USB 3.0 port |
⑧ |
Box1: optional HDD Drive Cage Bay for additional 8 SFF or 4 LFF drives support, or upgradeable to 2 HH media devices + 1 slim-line DVD. |
|
③ |
USB 3.0 port |
⑨ |
Serial number/iLO information pull tab |
|
④ |
UID Button/LED |
⑩ |
Box2: optional HDD Drive Cage Bay for additional 8 SFF or 4LFF drives support, or upgradeable to 8 SFF NVMe Express Bay |
|
⑤ |
NIC Status LED |
⑪ |
Box3: default with one 8 SFF HDD Drive Cage |
|
⑥ |
System Health LED |
|
|
Note (Back View):
|
① |
HPE Flexible Slot 2 (Optional – empty with power supply blank shown) |
⑧ |
Embedded 2 x 1GbE Network ports |
|
② |
Power supply Power connection |
⑨ |
USB 3.0 port x 2 |
|
③ |
HPE Flexible Slot 1 Power Supply |
⑩ |
PCI Slots (Slots 1-4) – Slot 1 and 3 can support Optional GPU |
|
④ |
Display Port |
⑪ |
Padlock eye |
|
⑤ |
VGA Port |
⑫ |
Serial Port |
|
⑥ |
Dedicated iLO Management Port (RJ45) |
⑬ |
PCI Slots (Slots 5-8) (requires Optional second processor) – Slot 5 and 7 can support Optional GPU |
|
⑦ |
Embedded 2 x 1GbE Network ports |
|
|
Options
Table 2 shows the recommended options.
|
Model |
Description |
|
HPE 128GB (1x128GB) Octal Rank x4 DDR4-2666 CAS-22-19-19 3DS Load Reduced Memory Kit |
|
|
HPE Ethernet 10Gb 2-port 562T Adapter |
|
|
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
|
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
|
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
|
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
|
HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit |
|
|
HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit |
|
|
HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit |
|
|
HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Smart Memory Kit |
Compare to Similar Item
Table 3 shows the comparison.
|
SKU |
877621-001 |
|
|
Model Name |
HPE ML350 Gen10 4110 1P 16G 8SFF P408i-a 800W FS RPS Base Tower Server |
HPE ML350 Gen10 4114 2P 32G 8SFF P408i-a 2x800W FS RPS Performance Rack Server |
|
Processor |
4110 (8-Core, 2.1 GHz, 85W) |
4114 (10-Core, 2.2 GHz, 85W) |
|
Number of Processors |
One processor |
Two processors |
|
Memory |
16 GB RDIMM SR 2600 MT/s (1x 16 GB) |
32 GB RDIMM SR 2600 MT/s (2x 16 GB) |
|
Network Controller |
Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter |
Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter |
|
Storage Controller |
P408i-a |
P408i-a |
|
Hard Drive |
None ship as standard |
None ship as standard |
|
Internal Storage |
8 SFF chassis with optional SFF HDD Cage Kit (874568-B21) to be selected. Upgradeable to 24 SFF max. Opt. 8 SFF NVMe Express Bay Kit (874569-B21) |
8 SFF chassis with optional SFF HDD Cage Kit (874568-B21), upgradeable to 24 SFF. Opt. 8 SFF NVMe Express Bay Kit (874569-B21) |
Get More Information
Do you have any question about the 877621-001?
Contact us now via Live Chat or [email protected].
HPE ML350 Gen10 8SFF 877621-001 Specification
877621-001 Specification |
|
|
Model Name |
HPE ML350 Gen10 4110 1P 16G 8SFF P408i-a 800W FS RPS Base Tower Server |
|
Processor |
4110 (8-Core, 2.1 GHz, 85W) |
|
Number of Processors |
One processor NOTE: Add HPE ML350 Gen10 Xeon-S 4110 Kit (866526-B21) for 2ndprocessor upgrade. |
|
Memory |
16 GB RDIMM SR 2600 MT/s (1x 16 GB) NOTE: running at 2400 MT/s per processor support |
|
Network Controller |
Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter NOTE: embedded 4x1GbE HPE Ethernet 1Gb 4-port 369i Adapter does not support speeds of 100MB/s and 10MB/s. |
|
Storage Controller |
P408i-a NOTE: 8-Port modular Smart Array. NOTE: Smart Storage battery included. |
|
Hard Drive |
None ship as standard |
|
Internal Storage |
8 SFF chassis with optional SFF HDD Cage Kit (874568-B21) to be selected. Upgradeable to 24 SFF max. Opt. 8 SFF NVMe Express Bay Kit (874569-B21) |
|
Optical Drive Bay |
Optional Slimline ODD Bay Kit (874577-B21) for SATA DVD-ROM/DVD-RW optical drive Optional Media Drive Support Kit (874570-B21) for RDX or tape/LTO devices, up to 2 |
|
Optical Drive |
None ship as standard |
|
PCI-Express Slots |
4-slots (x16, x8, x16, x8) as standard NOTE: PCIe slots 5 – 8 require the second optional processor. |
|
Power Supply |
1x 800W HPE FlexSlot Power Supply NOTE: Add a second 800W FlexSlot power supply to get 1+1 power redundancy feature. |
|
Fans |
2 standard fans; Optional redundant fan cage kit (874572-B21, add’l 4 fans) |
|
Management |
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced and HPE OneView Advanced (require licenses) |
|
Energy Star |
2.1 certified |
|
Form Factor |
4U Tower NOTE: Optional Tower-to-Rack conversion kit (874578-B21) to convert the unit to a 5U Rack-mount server. |
