The new platforms are architected to enable the next phase of branch-office evolution, providing rich media collaboration and virtualization to the branch while maximizing operational cost savings The Integrated Services Routers Generation 2 platforms are future-enabled with multi-core CPUs, Gigabit Ethernet switching with enhanced POE, and new energy monitoring and control capabilities while enhancing overall system performance. This CISCO1941-2.5G/K9 is the same as CISCO1941/K9, except the 2.5G installed DRAM.
Quick Specs
Figure 1 shows the front view of CISCO1941-2.5G/K9.
Table 1 shows the Quick Specs of the CISCO1941-2.5G/K9.
|
Product Code |
CISCO1941-2.5G/K9 |
|
Form Factor |
Desktop - modular - 2U |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Network / Transport Protocol |
IPSec, L2TPv3 |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing |
|
Remote Management Protocol |
SNMP, RMON |
|
Compliant Standards |
IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag |
|
Features |
Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED) |
|
Dimensions (W x D x H) |
34.3 cm x 29.2 cm x 8.9 cm |
|
DRAM Memory |
2.5 GB |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Router Interfaces |
1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
|
Expansion Slot(s) |
2 (total) / 2 (free) x HWIC |
|
Manufacturer Warranty |
1 year warranty |
Product Details
Figure 2 shows the ports and slots on the back panel of CISCO1941-2.5G/K9.
Note:
|
① |
On/Off switch |
⑩ |
CF 0 LED |
|
② |
Input power connection |
⑪ |
ISM or WLAN LED |
|
③ |
AUX port |
⑫ |
EN (Enable USB console) LED |
|
④ |
GE 0/0 |
⑬ |
USB serial port—USB 5-pin mini USB Type-B |
|
⑤ |
Kensington security slot |
⑭ |
EN (Enable RJ-45 console) LED |
|
⑥ |
CompactFlash 1 |
⑮ |
RJ-45 serial console port |
|
⑦ |
CF 1 LED |
⑯ |
GE 0/1 |
|
⑧ |
HWIC slot 1 (EHWIC, HWIC, or WIC)—double wide |
⑰ |
USB ports—two USB 2.0 Type-A ports |
|
⑨ |
CompactFlash 0 |
The Accessories
Table 2 shows some recommended accessories of CISCO1941-2.5G/K9.
|
Models |
Description |
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900, 2900, 3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900, 2900, 3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900, 2900, 3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900, 2900, 3900 |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
HWIC two routed port Cisco Router High-Speed WAN Interface card |
|
|
1-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco Voice/WAN Card VWIC3-1MFT-T1/E1 |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-T1/E1 |
|
|
Cisco Voice&WAN T1/E1 interface moudle VWIC3-1MFT-G703 |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
Compare to Similar Items
Table 3 shows the comparison between CISCO1941/K9 and CISCO1941-2.5G/K9.
|
Model |
CISCO1941-2.5G/K9 |
|
|
Interface |
2 GE |
2 GE |
|
EHWIC slot |
2 |
2 |
|
SIM Slot |
1 |
1 |
|
DRAM Memory |
512 MB (installed) / 2 GB (max) |
2.5 GB |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
256 MB (installed) / 8 GB (max) |
|
Rack Unit |
2U |
2U |
Get more information
Do you have any question about the CISCO1941-2.5G/K9?
CISCO1941-2.5G/K9 Specification
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CISCO1941-2.5G/K9 |
| Product Type | Router |
| Form Factor | Desktop - modular - 2U |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | IPSec, L2TPv3 |
| Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing |
| Remote Management Protocol | SNMP, RMON |
| Features | Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED) |
| Compliant Standards | IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag |
| DRAM Memory | 2.5 GB |
| Flash Memory | 256 MB (installed) / 8 GB (max) |
| LED Status Lights Indicators | Link activity, power |
| Connectivity Slots | |
|---|---|
| Router Interfaces | 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 Management : 1 x console - RJ-45 Management : 1 x console - mini-USB Type B Serial : 1 x auxiliary - RJ-45 USB : 2 x 4 PIN USB Type A |
| Expansion Slot(s) | 2 (total) / 2 (free) x HWIC 2 (total) / 1 (free) x CompactFlash Card 1 (total) / 1 (free) x Expansion Slot |
| Power Supply | |
| Power Device | Power supply - internal |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Dimensions / Weight / Miscellaneous | |
| Width | 34.3 cm |
| Depth | 29.2 cm |
| Height | 8.9 cm |
| Weight | 5.8 kg |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, AS/NZS 3548, FCC, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438 |
