Cisco Catalyst 2960-XR series switches offer power resiliency with optional dual field-replaceable power supplies and IP Lite Cisco IOS software with dynamic routing and Layer 3 features. WS-C2960XR-48LPD-I is one of 2960-XR switches, IP Lite switch, supporting forty-eight 10/100/1000 Ethernet ports with POE+ and Two 10G SFP+ uplinks. IP Lite Image enables basic access layer 3 routing features, such as RIPV1, V2, OSPF stub, EIGRP stub, HSRP, VRRP, PIM stub, etc.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
WS-C2960XR-48LPD-I |
|
Enclosure Type |
Rack-mountable - 1U |
|
Feature Set |
IP Lite |
|
Uplink Interfaces |
2 x 10G SFP+ uplinks |
|
Ports |
48 x 10/100/1000 (POE+) |
|
Available PoE Power |
370W |
|
Forwarding Bandwidth |
108Gbps |
|
Maximum stacking number |
8 |
|
Stack bandwidth |
80G |
|
Switching Bandwidth |
216Gbps |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Dimensions |
44.5 cm x 40.8 cm x 4.45 cm |
|
Package Weight |
16.15 Kg |
Product Details
Figure 1 shows the front panel of WS-C2960XR-48LPD-I.
Note:
·There are Forty-eight 10/100/1000 Ethernet Gigabit Ports and Two 10G SFP+ uplinks on the front panel.
·Two USB Type A ports and one USB mini-Type B (console) port are on the left.
·This switch offers one RJ-45 console port and one Ethernet management port on the left of the front panel.
·Power over Ethernet Plus (PoE+) supports up to 370W of PoE budget for 12 ports with 30W per port or 24 ports with 15.4W per port or 48 ports with 7.4W per port.
Figure 2 shows the back panel of WS-C2960XR-48LPD-I.
Note:
|
① |
FlexStack-Plus module slot and cover |
④ |
PS OK LED |
|
② |
Power supply slot (with blank module) |
⑤ |
AC power connector on the power supply module |
|
③ |
AC OK LED |
The WS-C2960XR-48LPD-I supports stacking with the optional stack kit. It has the FlexStack-Plus module (hot-swappable) that inserts in the slot located in the switch rear panel, and a 0.5-meter FlexStack cable to connect the FlexStack-Plus module ports. The stack module should purchase separately.
The Accessories
Table 2 shows some accessories of WS-C2960XR-48LPD-I.
|
Models |
Description |
|
Catalyst 2960-X FlexStack Plus Stacking Module |
|
|
Cisco FlexStack Stacking Cables |
|
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Console Cable 6ft with RJ45 and DB9F |
|
|
Console Cable 6 ft with USB Type A and mini-B |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
WS-C2960XR-48LPD-I |
|
|
Ports |
48 x 10/100/1000 (POE+) |
48 x 10/100/1000 (POE+) |
|
Available PoE Power |
740W |
370W |
|
Uplinks |
2 x 10 Gigabit SFP+ |
2 x 10 Gigabit SFP+ |
|
Feature Set |
IP Lite |
IP Lite |
|
FlexStack-Plus Stacking |
Optional |
Optional |
Get more information
Do you have any question about the Cisco Catalyst 2960XR-48LPD-I switch?
Contact us now via Live Chat or [email protected].
WS-C2960XR-48LPS-I Specification
WS-C2960XR-48LPS-I Specification |
|
|
Enclosure type |
Rack-mountable - 1U |
|
Ports |
48 x 10/100/1000 (POE+) + 4 x 1G SFP |
|
Network management Interface |
10/100 Mbps Ethernet (RJ-45) |
|
Available PoE Power |
370W |
|
Forwarding bandwidth(Gbps) |
108Gbps |
|
Maximum stacking number |
8 |
|
Stack Bandwidth |
80G |
|
Forwarding Performance |
107.1Mpps |
|
Switching bandwidth |
216Gbps |
|
Maximum active VLANs |
1023 |
|
MAC Address Table Size |
16K (default) |
|
CPU |
APM86392 600MHz dual core |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Status Indicators |
● Per-port status: Link integrity, disabled, activity, speed, and full duplex ● System status: System, RPS, PoE, Stack link status, link duplex, and link speed |
|
Expansion / Connectivity |
|
|
Console ports |
USB (Type-B), Ethernet (RJ-45) |
|
Expansion Slot(s) |
1 FlexStack-Plus slot and 1 power redundant slot |
|
Stack Modules |
C2960X-STACK |
|
Stacking cable |
● CAB-STK-E-0.5M FlexStack-Plus stacking cable with a 0.5 m length ● CAB-STK-E-1M FlexStack-Plus stacking cable with a 1.0 m length ● CAB-STK-E-3M FlexStack-Plus stacking cable with a 3.0 m length |
|
Power supply |
PWR-C2-250WAC |
|
Power Device |
Power supply - redundant - plug-in module |
|
Power Redundancy |
optional |
|
Voltage range (Auto) |
110V-240V |
|
Power Consumption Operational |
0.47kVA |
|
Miscellaneous |
|
|
Width |
17.5 Inches (44.5 cm) |
|
Depth |
16 Inches (40.8 cm) |
|
Height |
1.75 Inches (4.45 cm) |
|
Weight |
14.2 Pounds (6.4Kgs) |
|
Package Weight |
35.6 Pounds (16.15Kg) |
|
Rack Mounting Kit |
Optional |
|
MTBF in hours |
274,380 |
|
Compliant Standards |
● IEEE 802.1D Spanning Tree Protocol ● IEEE 802.1p CoS Prioritization ● IEEE 802.1Q VLAN ● IEEE 802.1s ● IEEE 802.1w ● IEEE 802.1X ● IEEE 802.1ab (LLDP) ● IEEE 802.3ad ● IEEE 802.3af and IEEE 802.3at ● IEEE 802.3ah (100BASE-X single/multimode fiber only) ● IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports ● IEEE 802.3 10BASE-T ● IEEE 802.3u 100BASE-TX ● IEEE 802.3ab 1000BASE-T ● IEEE 802.3z 1000BASE-X ● RMON I and II standards ● SNMP v1, v2c, and v3 ● IEEE 802.3az ● IEEE 802.3ae 10Gigabit Ethernet ● IEEE 802.1ax |
|
System software / license |
|
|
System software |
IOS IP Lite |
|
license |
ENERGY-MGMT, ENERGY-MGT-100-K9 |
|
features |
● IP unicast routing protocols (Static, Routing Information Protocol Version 1 [RIPv1], RIPv2, RIPng, and EIGRP-Stub) ● Advanced IP unicast routing protocols (OSPF for Routed Access) ● EIGRPv3-Stub and PIMv6-Stub are supported as a part of the IPv6 routing suite. ● Equal-cost routing ● Policy-based routing (PBR) ● Hot Standby Routing Protocol (HSRP) and Virtual Router Redundancy Protocol (VRRP) ● Protocol Independent Multicast (PIM) |
|
Network security |
● MAC-based VLAN assignment enables ● Cisco TrustSec uses ● Comprehensive 802.1X ● IPv6 First-Hop Security ● Device Sensor and Device Classifier ● Cisco Trust Anchor Technology ● Cisco Threat Defense ● Private VLANs ● Unicast Reverse Path Forwarding (uRPF) ● Multidomain Authentication ● Access Control Lists (ACLs) ● Switched Port Analyzer (SPAN) ● Secure Shell (SSH) Protocol, Kerberos, and Simple Network Management Protocol Version 3 (SNMPv3) ● TACACS+ and RADIUS authentication ● MAC Address Notification ● Multilevel security on console access BPDU Guard ● Spanning Tree Root Guard (STRG) ● IGMP filtering |
|
Management & Troubleshooting |
● Auto-MDOX ●TDR ● UDLD ● IP SLA Responder ● layer 2 / IP Traceroute ● SPAN ● RSPAN ● Express Setup ● Device Manager ● Cisco Network Assistant ● Smartports + Advisor ● Troubleshooting Advisor ● Drag-and-drop Cisco IOS Upgrade ● IP Address DHCP ● Autoinstall with saved configuration ● Configuration Replace ● DHCP Auto Image Upgrade ● DHCP Port Based Allocation ● Error Disable MIB |
|
Technical Support and Services |
● Cisco SMARTnet Service ● Cisco Smart Foundation Service ● Cisco Smart Care Service ● Cisco SP Base Service ● Cisco Focused Technical Support Services |
|
Environmental Ranges |
|
|
Operating temperature up to 5000 ft (1500 m) |
23ºF to 113º (-5ºC to 45ºC) |
|
Operating temperature up to 10,000 ft (3000 m) |
23ºF to 104ºF (-5ºC to 40ºC) |
|
Short-term exception at sea level* |
23ºF to 131ºF (-5ºC to 55ºC) |
|
Short-term exception up to 5000 feet (1500 m)* |
23ºF to 122ºF (-5ºC to 50ºC) |
|
Short-term exception up to 10,000 feet (3000 m)* |
23ºF to 113ºF (-5ºC to 45ºC) |
|
Short-term exception up to 13,000 feet (4000 m)* |
23º to 104ºF (-5ºC to 40ºC) |
|
Storage temperature up to 15,000 feet (4573 m) |
-13º to 158ºF (-25º to 70ºC) |
|
Operating altitude |
Up to 10,000 (Up to 3000 Meters) |
|
Storage altitude |
Up to 13,000 (Up to 4000 Meters) |
|
Operating relative humidity |
10% to 95% noncondensing |
|
Storage relative humidity |
10% to 95% noncondensing |
