Cisco ONE Catalyst 6824-X-Chassis and 2x40G Standard Tables
C1-C6824-X-LE-40G Specification
C1-C6824-X-LE-40G Specification | |
| General | |
| Device Type | Switch - 24 ports - L3 - managed |
| Enclosure Type | Desktop, rack-mountable 2U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 24 x 1 Gigabit / 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ (breakout compatible) |
| Performance | Forwarding performance: up to 120 Mpps ¦ Switching capacity (full duplex): up to 160 Gbps ¦ IPv4 routing: up to 120 Mpps ¦ IPv6 routing: up to 60 Mpps ¦ Layer 2 bridging: up to 120 Mpps |
| Capacity | IPv4 routes: 256000 ¦ IPv6 routes: 128000 ¦ NetFlow entries: 1000000 ¦ IPv4 routes (Multicast): 128000 ¦ IPv6 routes (Multicast): 64000 ¦ Virtual interfaces (VLANs): 4094 ¦ Domains: 16000 ¦ ACL entries: 64000 ¦ Logical interfaces: 128000 |
| MAC Address Table Size | 128K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | GRE |
| Features | NAT support, MPLS support, IGMP snooping, High Availability, Access Control List (ACL) support, Virtual Route Forwarding-Lite (VRF-Lite), MLD snooping, NetFlow, Virtual Private LAN Service (VPLS), Label Distribution Protocol (LDP), Location ID Separation Protocol (LISP), LISP Across Subnet Mode (ASM), Instant Access (IA), Virtual Switching System (VSS) |
| Compliant Standards | IEEE 802.1ae |
| RAM | 4 GB |
| Expansion / Connectivity | |
| Interfaces | 24 x 10GBase-X SFP+ ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45 ¦ 1 x USB Type A ¦ 1 x mini-USB Type B |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 0 (installed) / 2 (max) |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Miscellaneous | |
| Compliant Standards | NEBS level 3, CISPR 22 Class A, EN 60950, IEC 60950, EN55024, EN55022 Class A, UL 60950, EN50082-1, EN 61000-6-1, AS/NZS 3548 Class A, AS/NZS 60950, GR-1089-CORE, CAN/CSA C22.2 No. 60950, VCCI Class A, ETS 300 386, ETS300019-2-3, FCC CFR47 Part 15 A |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 21.8 in |
| Height | 3.5 in |
| Weight | 34.83 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance parts replacement - 1 year - response time: 10 days |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 149 °F |
| Humidity Range Storage | 5 - 95% (non-condensing) |
