To meet today's enterprise small branch offices, Cisco 800 Series Integrated Services Routers (ISR) are designed. There are Cisco 800 Series routers, the affordable routers with important network services, support about 50 users when they're designed to provide the secure, reliable WAN connectivity your small offices and remote workers need. The Cisco 800 series currently consists of the 800M, 810, 860, 880, and 890 models but other products of this series are End-Of-Sale models such as 815, 851, 857 and so on. Through diverse WAN Connectivity including xDSL, Ethernet, 3G and 4G, and fiber, high security including encryption, firewall, and URL filtering, this series can offer small business a flexible, high performance, and machine-to-machine deployment.
Quick Specs
Table 1 shows the Quick Specs.
|
Model |
C888-K9 |
|
Use Case |
|
|
Typical deployment |
Small branch, retail, or managed CPE |
|
Typical number of users |
1 executive up to 20 employees |
|
Performance positioning |
Up to 15 Mbps |
|
WAN |
|
|
Ethernet |
- |
|
VDSL2/ADSL2+ |
- |
|
SHDSL |
Multimode EFM/ATM SHDSL |
|
Fiber |
- |
|
3G/4G LTE |
3.7 HSPA+ |
|
Serial |
- |
|
LAN |
|
|
Ports |
4 |
|
802.11 wireless |
2.4 GHz 802.11n integrated antenna |
|
Voice |
- |
|
PoE |
2-port integrated PoE |
|
Software Features |
|
|
Routing protocols |
RIPv1, v2, BGP, OSPF, EIGRP |
|
IPv6 |
Yes |
|
Advanced IP services |
Upgradeable |
|
Video/medianet |
Ready |
|
Security |
|
|
VPN support |
GETVPN, DMVPN with license |
|
ScanSafe |
Ready |
|
IPsec tunnels |
20 |
|
SSL VPN |
With license |
|
Content filtering |
With license |
|
Application Experience |
|
|
Integrated WAN optimization - Cisco WAAS Express |
1.5 Mbps optimized; 30-75 TCP connections; with license |
|
Application Visibility and Control (AVC) |
No |
|
IOS high-availability features |
Yes |
|
Physical Attributes |
|
|
Maximum dimensions |
1.9 x 12.8 x 10.4 in |
|
Maximum weight |
5.5 lb (2.5 kg) |
|
Fanless |
Yes |
|
Optional hardened form factor |
No |
C888-K9 Specification
C888-K9 Specification |
|
| General | |
| Device Type | Router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet |
| Capacity | Wireless VLANs: 8 ¦ IPSec VPN tunnels: 20 ¦ Maximum number of configured SSIDs: 16 |
| Network / Transport Protocol | L2TP, IPSec, FTP, DNS |
| Routing Protocol | RIP-1, RIP-2, HSRP, VRRP, GRE, policy-based routing (PBR) |
| Remote Management Protocol | Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Encryption Algorithm | LEAP, DES, Triple DES, SSL, TLS, PEAP, TTLS, TKIP, WPA, WPA2, PKI, 128-bit AES, 192-bit AES, 256-bit AES, WEP |
| Authentication Method | RADIUS, Radio Service Set ID (SSID), TACACS+, EAP-FAST |
| Features | Firewall protection, NAT support, MDI/MDI-X switch, VPN support, VLAN support, MAC address filtering, Broadcast Storm Control, Intrusion Prevention System (IPS), Multicast Storm Control, Unicast Storm Control, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Spanning Tree Protocol (STP) support, Virtual Route Redundancy Protocol (VRRP) support, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), DHCP server, DNS proxy, DHCP relay, Port Security, 2T3R MIMO technology, DHCP client, Hot Standby Router Protocol (HSRP) support, Management Information Base (MIB), Class of Service (CoS), Call Admission Control (CAC), DiffServ Code Point (DSCP) support |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.3af, IEEE 802.11i, Wi-Fi CERTIFIED, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, CISPR 22, EN50082-1, EN55022 Class B, EN 60555-2, FCC CFR47 Part 15, FCC CFR47 Part 15 B, AS/NZS 3548 Class B, VCCI V-3, ICES-003 issue 4 Class A, KN22, EN 300386, EN55024:1998 + A1 + A2, IEC 61000-6-1:2005, EN 300 386 V1.3.3 |
| RAM | 256 MB |
| Flash Memory | 128 MB |
| Status Indicators | Port status, power |
| Communications | |
| Type | DSL modem |
| Protocols & Specifications | ITU G.991.2 (G.shdsl) |
| Expansion / Connectivity | |
| Interfaces | LAN: 4 x 10Base-T/100Base-TX - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ WAN: 1 x SHDSL ¦ USB: 1 x 4 pin USB Type A ¦ WAN: 1 x BRI ST - RJ-45 |
| Power | |
| Power Device | External power adapter - 60 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Dimensions & Weight | |
| Width | 12.8 in |
| Depth | 9.8 in |
| Height | 1.7 in |
| Weight | 5.51 lbs |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 85% (non-condensing) |
