The Cisco 3925 router, modular Services Performance Engine (SPE) 100, which can be upgraded for even higher performance as next-generation WAN environments evolve.
Quick Specs
Figure 1 shows the appearance of the CISCO3925/K9.
Table 1 shows the Quick Specs of the CISCO3925/K9.
Product Code |
CISCO3925/K9 |
Services Performance Engine module |
w/SPE 100 |
Rack Units |
3U |
Interfaces |
3 integrated 10/100/1000 Ethernet ports with 2 ports capable of RJ-45 or SFP connectivity |
Expansion Slot(s) |
2 service module slots 1 Internal Services Module slot 4 onboard digital signal processor (DSP) slots 4 Enhanced High-Speed WAN Interface Card (EHWIC) slots |
RAM |
1 GB (installed) / 2 GB (max) |
Flash Memory |
256 MB (installed) / 8 GB (max) |
Dimensions |
47.6 cm x 43.8 cm x 13.3 cm |
Package Weight |
27.78 Kg |
Product Details
Figure 2 shows the front panel of the Cisco 3925 router.
Note:
① On/Off switch ② Power connector ③ LEDs area
Table 2 shows the LEDs area description.
LED |
Description |
|
SYS status LED |
Solid green |
Solid green indicates normal operation. |
Blinking green |
System is booting or is in ROM monitor mode. |
|
Amber |
System error. |
|
Off |
Power is off or system board is faulty. |
|
ACT status LED |
Solid or blinking green |
Solid or blinking indicates packet activity between the forwarding and routing engine and any I/O port. |
Off |
No packet transfers are occurring. |
|
POE |
Green |
IP phone power is on. |
Amber |
IP phone power is not on. |
|
PS1 / PS2 |
Green |
System is running. |
Amber |
System is not running. |
Figure 3 shows the back panel of the Cisco router 3925/K9 with LEDs.
Note:
① Compact flash 0 and 1 (0, right) ② ISM ③ PVDM3 0,1,2 and 3 (0, far right) ④ EN (Enable USB console) ⑤ EN (Enable RJ-45 console) ⑥ SFP S ⑦ SFP EN ⑧ S (Speed) ⑨ L (Link)
Table 3 shows the description of these LEDs on the back panel.
LED |
Color |
Description |
Location |
CompactFlash 1 |
Green |
Flash memory is busy. |
Back Panel |
Amber |
Initialized with error. |
||
Blinking Green then turns off |
CompactFlash is ready for removal. |
||
CompactFlash 0 |
Green |
Flash memory is busy. |
Back Panel |
Amber |
Initialized with error. |
||
Blinking Green then turns off |
CompactFlash is ready for removal. |
||
S (Speed) |
1 blink + pause |
GE port operating at 10 Mb/s. |
Back Panel |
2 blink + pause |
GE port operating at 100 Mb/s. |
||
3 blink + pause |
GE port operating at 1000 Mb/s. |
||
L (Link) |
Green |
GE link is established. |
Back Panel |
Off |
No GE link is established. |
||
EN (RJ-45 console port) |
Green |
The RJ-45 console port is active. |
Back Panel |
EN (USB serial console port) |
Green |
The USB console port is active. |
Back Panel |
ISM |
Green |
Initialized. |
Back Panel |
Amber |
Initialized with error. |
||
Off |
Not installed. |
||
PVDM3 0,1,2 and 3 |
Green |
PVDM is initialized. |
Back Panel |
Amber |
PVDM is detected but not initialized. |
||
Off |
No PVDM installed. |
||
SFP S |
Blinking green |
Blinking frequency indicates port speed. |
Back Panel |
SFP EN |
Off |
Not present. |
Back Panel |
Green |
Present and enabled. |
||
Amber |
Present with failure. |
Figure 4 shows the back panel of the Cisco 3925 router with slots and ports.
Note:
① Compact flash 0 and 1 (0, right) ② EHWIC 0,1,2 and 3 (0, far right) ③ USB serial port ④ RJ-45 serial console port ⑤ AUX port ⑥ SFP 1 and SFP 2 (2, top)
⑦ 10/100/1000 Ethernet port GE 0/1 and GE 0/2 (GE 0/1, down) ⑧ 10/100/1000 Ethernet port GE 0/0 ⑨ USB 0 and USB 1 (1,top) ⑩ Ground ⑪ Service module slots
Figure 5 shows the SPE area and you can upgrade these slots and ports directly by one SPE module.
The Cisco 3900 Series offers field-replaceable SPEs which allow you to protect your initial investment in the Cisco 3900 platform for a longer time period and scale router performance as your network and branch-office needs grow.
Modules and License
Table 4 shows modules and licenses for this router.
Models |
Description |
Cisco Services Performance Engine 100 for Cisco 3925 ISR. (It's a configured item in the CISCO3925/K9.) |
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
Internal Services Module (ISM) with Services Ready Engine |
|
16-channel high-density voice DSP module |
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
1GB USB Flash Token |
|
Licenses |
Description |
Cisco 3900 License L-FL-39-HSEC-K9 U.S. Export Restriction Compliance license for 3900 series |
|
Cisco 3900 Router License - FL-39-SNA= SNA E-Delivery License for Cisco 3925/3945 for Cisco 3900 Series |
|
Cisco Application Experience License ISR 3900 series - includes licenses for: AppX, DATA and WAASX. |
|
Cisco 3900 License L-SL-39-SEC-K9 Security E-Delivery PAK for Cisco 3900 Series |
|
Cisco 3900 License L-SL-39-UC-K9 Unified Communication E-Delivery PAK for Cisco 3900 Series |
Get more information
Do you have any question about the Cisco 3925/K9 router?
CISCO3925/K9 Specification
CISCO3925/K9 Specification |
||
General |
||
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
CISCO3925/K9 |
|
Product Type |
Router |
|
Form Factor |
Desktop - modular - 3U |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Capacity |
Cisco Unified Communications Manager Express sessions : 250 Cisco Unified SRST sessions : 730 |
|
Network / Transport Protocol |
IPSec, PPPoE, L2TPv3 |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR) |
|
Remote Management Protocol |
SNMP, RMON |
|
Encryption Algorithm |
SSL |
|
Features |
Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN) |
|
Compliant Standards |
IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag |
|
DRAM Memory |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
LED Status Lights Indicators |
Link activity, power |
|
Connectivity Slots |
||
Router Interfaces |
3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
|
Expansion Slots Total (Free) |
4 ( 4 ) x EHWIC |
|
Power Supply |
||
Power Device |
Power supply - internal |
|
Voltage Required |
AC 120/230 V ( 47/63 Hz ) |
|
Dimensions / Weight / Miscellaneous |
||
Dimensions (W × D × H) |
18.74 × 17.24 × 5.24 in (47.6 × 43.8 × 13.3 cm) |
|
Package Wight |
61.3 lbs (27.78 Kg) |
|
Weight |
39 lbs (17.7 kg) |
|
Compliant Standards |
CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A, CAN/CSA-E60065-00, ICES- 003 Class A, CS-03, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438 |
|
System Software |
||
IOS Software Included |
Cisco IOS IP Base |
