Cisco 2901 Integrated Services Router (ISR) delivers highly secure data, voice, video, and application services for small offices. CISCO2901-SEC/K9 is almost the same as CISCO2901/K9, except that it offers Security bundle.

Quick Specs

Figure 1 shows the front view of CISCO2901-SEC/K9.

Table 1 shows the Quick Specs of the CISCO2901-SEC/K9.

Product Details

Figure 2 shows the ports on the back panel of CISCO2901-SEC/K9.

Note:

① EHWIC slots  0, 1, 2, and 3 (0, Far right)                                          ⑥ CompactFlash 0 and 1

② Aux port                                                                                                   ⑦ USB serial port

③ 10/100/1000 Ethernet port (GE0/0)                                                   ⑧ RJ-45 serial console port

④ Ground                                                                                                    ⑨ 10/100/1000 Ethernet ports (GE0/1)

⑤ CompactFlash 0 and 1                                                                         ⑩ USB0 and USB1 (1, Top)

Figure 3 shows the LEDs on the back panel of CISCO2901-SEC/K9.

Note:

① CompactFlash 0 and 1 (0, Right)                           ⑤ EN (Enable RJ-45 console)

② ISM                                                                               ⑥ S (Speed)

③ PVDM3 0 and 1 (0, Right)                                        ⑦ L (Link)

④ EN (Enable USB console)

The Modules and Cards

Table 2 shows some recommended modules and cards for this router.
