Huawei AR G3 AR160 Series AR162F router builds with 1 Gigabit Ethernet 10/100/1000 COMBO (SFP or RJ-45) WAN port, 1 synchronous/asynchronous WAN port,4 Gigabit Ethernet 10/100/1000 LAN ports and 1 USB.
Quick Specs
Figure 1 shows the appearance of Huawei Router - AR162F.
Table 1 shows the Quick Specs.
|
Product Code |
Huawei Router - AR162F |
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 SA interface and 1 GE combo interface LAN interfaces: 4 10/100/1000M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: GE0-GE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8 kg (6.17 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
Product Details
Figure 2 shows the back panel of Huawei Router - AR162F.
Note:
|
CON/AUX interface |
|
WAN GE Combo interfaces |
|
4 FE electrical interfaces |
|
RST button |
|
Power interface |
|
Jack for power cable locking strap |
|
SA interface |
The Optical transceiver
Table 2 shows the recommended elements for the Huawei Router - AR162F.
|
Model |
Description |
|
FE-SFP Optical Transceiver |
|
|
SFP,100M/155M,Multi-mode Module(1310nm,2km,LC) |
|
|
eSFP,100M/155M,Single-mode Module(1310nm,15km,LC) |
|
|
eSFP,FE,Single-mode Module(1310nm,40km,LC) |
|
|
GE-SFP Optical Transceiver |
|
|
SFP,GE,Electrical Interface Module(100m,RJ45) |
|
|
eSFP,GE,Multi-mode Module(850nm,0.55km,LC) |
|
|
eSFP,GE,Single-mode Module(1310nm,10km,LC) |
|
|
eSFP,GE,Single-mode Module(1310nm,40km,LC) |
|
|
eSFP,GE,Single-mode Module(1550nm,40km,LC) |
|
Compare to Similar Items
Table 3 shows the comparison between AR162F and AR2220E.
|
Model |
AR162F |
|
|
SIC Slots |
0 |
4 |
|
Memory |
512 MB |
1 GB |
|
Flash |
512 MB |
512 MB |
|
Weight |
2.8 kg (6.17 lb) |
6 kg (13.2 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
442.0 mm x 420.0 mm x 44.5 mm |
AR162F Specification
AR162F Specification |
|
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 SA interface and 1 GE combo interface LAN interfaces: 4 10/100/1000M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: GE0-GE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8 kg (6.17 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
