Cisco Catalyst 3560CX Series compact enterprise class layer 3 switch WS-C3560CX-12TC-S offers 12 Gigabit Ethernet ports, 2 Gigabit Ethernet RJ-45 uplinks, 2 SFP uplinks.
Quick Specs
Figure 1 shows the appearance of WS-C3560CX-12TC-S.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C3560CX-12TC-S |
|
Feature Set |
IP Base |
|
Uplink Interfaces |
2 x 1G copper plus 2 x 1G SFP |
|
Ports |
12 x 10/100/1000 Gigabit Ethernet |
|
Forwarding Bandwidth |
16 Gbps |
|
Switching Bandwidth (full-duplex capacity) |
32 Gbps |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Dimensions |
4.44 x 26.9 x 21.3 cm |
|
Package Weight |
4.65 Kg |
Product Details
Figure 2 shows the front panel of WS-C3560CX-12TC-S.
Note:
|
① |
Mode button |
⑤ |
SFP module slots |
|
② |
USB mini-Type B (console) port |
⑥ |
Switch LEDs |
|
③ |
12 x 10/100/1000 ports |
⑦ |
RJ-45 Console Port |
|
④ |
2 x 1G copper |
⑧ |
USB Type A port |
·Switch LEDs include SYST, STAT, SPEED, and Console LED.
Table 2 shows the three LEDs descriptions.
|
LED |
Color/Port Mode |
Description |
|
SYST (System LED) |
Off |
System is not powered on. |
|
Green |
System is operating normally. |
|
|
Amber |
System is receiving power but is not operating properly. |
|
|
STAT |
Port status |
The port status. This is the default mode. |
|
SPEED |
Port speed |
The port operating speed: 10, 100, or 1000 Mb/s. |
The console LEDs show which console port is in use.
If you connect a cable to a console port, the switch automatically uses that port for console communication. If you connect two console cables, the USB-mini console port has priority.
Table 3 shows the Console LED description.
|
LED |
Color |
Description |
|
RJ-45 console port |
Green |
RJ-45 console port is active. USB-mini console port LED is not active. |
|
Off |
Port is not active. USB-mini console port is active. |
|
|
USB-mini console port |
Green |
USB-mini console port is active. RJ-45 console port LED is not active. |
|
Off |
Port is not active. RJ-45 console port is active. |
The Accessories
Table 4 shows some recommended cables.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
Compare to similar item
|
Models |
WS-C3560CX-12TC-S |
|
|
Uplinks |
2 x 1G copper plus 2 x 1G SFP+ |
2 x 1G copper plus 2 x 10G SFP+ |
|
Ports |
12 x 10/100/1000 Gigabit Ethernet |
12 x 10/100/1000 Gigabit Ethernet |
|
Feature set |
IP Base |
IP Base |
|
PoE Output Ports |
12 PoE+ |
None |
|
Available POE Power |
240W |
None |
Get more information
Do you have any question about the WS-C3560CX-12TC-S?
Contact us now via Live Chat or [email protected].
WS-C3560CX-12TC-S Specification
WS-C3560CX-12TC-S Specifications |
|
| Model | Cisco Catalyst 3560-CX 12-port compact Switch |
| Layer | Layer 3 |
| Ports | 12 x 10/100/1000 Ethernet Ports |
| Uplinks | 2 SFP&2GE uplinks |
| Management | Managed |
| Brand | Cisco |
| Compatible Devices | Compatible Devices |
| Power Over Ethernet (PoE) | No |
| Stackable | Yes |
| POWER CONSUMPTION | 20.8W at 100% throughput |
| Form Facto | Rack-mountable |
| Included Components | Accessories, Switch |
| Dimensions LxWxH | 15 x 10 x 15 inches |
| Operating Temperature | 23°F to 113°F (-5°C to 45°C) |
| Software Support | Cisco IOS Software |
