C3925E-CME-SRST/K9 is a Cisco 3925E router bundled with Voice Bundle w/ PVDM3-64, FL-CME-SRST-25, UC License PAK.
When Unified CME is used in SRST mode, it provides more call processing features for the IP phones than those are available with the SRST feature on a router. In addition, to the SRST features such as call preservation, auto-provisioning, and failover, Unified CME in SRST mode also provides most of the Unified CME telephony features for the SCCP phones, including:
• Paging
• Conferencing
• Hunt groups
• Basic automatic call distribution (B-ACD)
• Call park, call pickup, call pickup groups
• Overlay-DN, softkey templates
• Cisco IP Communicator
• Cisco Unified Video Advantage
• Integration with Cisco Unity with MWI support at remote sites, with distributed Microsoft Exchange or IBM Lotus Domino server
Quick Specs
Table 1 shows the Quick Specs of the C3925E-CME-SRST/K9.
|
Product Code |
C3925E-CME-SRST/K9 |
|
Bundle |
Cisco 3925E Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK |
|
Services Performance Engine module |
w/SPE 200 |
|
Rack Units |
3U |
|
Interfaces |
4 integrated 10/100/1000 Ethernet ports with 2 SFP ports |
|
Expansion Slot(s) |
2 service module slots 3 onboard digital signal processor (DSP) slots 3 Enhanced High-Speed WAN Interface Card (EHWIC) slots |
|
RAM |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Dimensions |
47.6 cm x 43.8 cm x 13.3 cm |
Product Details
Figure 1 shows the appearance of the Cisco 3925E/K9 router. C3925E-CME-SRST/K9 is similar with it.
Modularity Features
Table 2 shows recommended modules for this router.
|
Models |
Description |
|
Cisco Services Performance Engine 200 for Cisco 3925E ISR (It's a configured item in the CISCO3925E/K9.) |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
1GB USB Flash Token |
Compare to Similar Routers
Table 3 shows the comparison of CISCO3925E/k9 and C3925E-CME-SRST/K9.
|
Model |
C3925E-CME-SRST/K9 |
|
|
Bundle |
N/A |
Cisco 3925E Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK |
|
SPE |
w/SPE 200 |
w/SPE 200 |
|
Interface |
4GE |
4GE |
|
EHWIC slots |
3 |
3 |
|
SM slots |
2 |
2 |
|
ISM slots |
0 |
0 |
|
DSP |
3 |
3 |
|
SFP |
2 |
2 |
|
Rack Unit |
3U |
3U |
Get more information
Do you have any question about the C3925E-CME-SRST/K9?
C3925E-CME-SRST/K9 Specification
C3925E-CME-SRST/K9 Specification |
|
|
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
C3925E-CME-SRST/K9 |
|
Product Type |
Router |
|
Bundle |
Cisco 3925E Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK |
|
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
C3925E-CME-SRST/K9 |
|
Product Type |
Router |
|
Form Factor |
Desktop - modular - 3U |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Capacity |
Cisco Unified Communications Manager Express sessions : 400 |
|
Network / Transport Protocol |
IPSec, PPPoE, L2TPv3 |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR) |
|
Remote Management Protocol |
SNMP, RMON |
|
Features |
Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN) |
|
Compliant Standards |
IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag |
|
DRAM Memory |
1 GB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
LED Status Lights Indicators |
Link activity, power |
|
Communications |
|
|
Type |
Voice / fax module |
|
Digital Ports Qty |
64 |
|
Protocols & Specifications |
ITU G.168 |
|
IP Telephony |
|
|
Voice Codecs |
G.711, G.722, G.723.1, G.728, G.729, G.729a, G.729ab, G.726 |
|
Connectivity Slots |
|
|
Router Interfaces |
WAN : 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
|
Expansion Slot(s) |
3 (total) / 3 (free) x EHWIC |
|
Power Supply |
|
|
Power Device |
Power supply - internal |
|
Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
|
Dimensions / Weight / Miscellaneous |
|
|
Approximate Width |
18.7 in |
|
Depth |
17.2 in |
|
Height |
5.2 in |
|
Weight |
39 lbs |
|
Compliant Standards |
CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A, CAN/CSA-E60065-00, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438, NEBS |
|
System software |
|
|
Software Included |
Cisco IOS Unified Communications, Cisco Unified Communications Manager Express / Cisco Unified Survivable Remote Site Telephony (25 phones) |
