ITCS C3945-CME-SRST/K9

Sale Off

C3945-CME-SRST/K9

Brands: Cisco

(0 reviews)

﷼ 36161.44 40179.38 10% Off

Model: C3945-CME-SRST/K9 Cisco 3900 Router Voice Bundle

Detail: <p style="margin-bottom: 0px;">3945 Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK</p>

Categories: Routers / Cisco Router ISR 3900
Tags:

C3945-CME-SRST/K9 is a Cisco 3945 router bundled with Voice Bundle w/ PVDM3-64, FL-CME-SRST-25, UC License PAK.

When Unified CME is used in SRST mode, it provides more call processing features for the IP phones than those are available with the SRST feature on a router. In addition, to the SRST features such as call preservation, auto-provisioning, and failover, Unified CME in SRST mode also provides most of the Unified CME telephony features for the SCCP phones, including:

☆ Paging
☆ Conferencing
☆ Hunt groups
☆ Basic automatic call distribution (B-ACD)
☆ Call park, call pickup, call pickup groups
☆ Overlay-DN, softkey templates
☆ Cisco IP Communicator
☆ Cisco Unified Video Advantage
☆ Integration with Cisco Unity with MWI support at remote sites, with distributed Microsoft Exchange or IBM Lotus Domino server

Quick Specs

Table 1 shows the Quick Specs of the C3945-CME-SRST/K9.

Product Code	C3945-CME-SRST/K9
Bundle	Cisco 3945 Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK
Services Performance Engine module	w/SPE 150
Rack Units	3U
Interfaces	3 integrated 10/100/1000 Ethernet ports with 2 ports capable of RJ-45 or SFP connectivity
Expansion Slot(s)	4 service module slots 1 Internal Services Module slot 4 onboard digital signal processor (DSP) slots 4 Enhanced High-Speed WAN Interface Card (EHWIC) slots
RAM	1 GB (installed) / 2 GB (max)
Flash Memory	256 MB (installed) / 8 GB (max)
Dimensions	47.6 cm x 43.8 cm x 13.3 cm

Product Details

Figure 1 shows the front panel of the Cisco 3945 router. C3945-CME-SRST/K9 is similar with it.

Note:

①	②	③
On/Off switch	Power connector	LEDs area

Figure 2 shows the back panel of the Cisco 3945 router with slots and ports. C3945-CME-SRST/K9 is similar with it.

Note:

①	Compact flash 0 and 1 (0, right)	⑦	10/100/1000 Ethernet port GE 0/1 and GE 0/2 (GE 0/1, down)
②	EHWIC 0,1,2 and 3 (0, far right)	⑧	10/100/1000 Ethernet port GE 0/0
③	USB serial port	⑨	USB 0 and USB 1 (1,top)
④	RJ-45 serial console port	⑩	Ground
⑤	AUX port	⑪	Service module slots
⑥	SFP 1 and SFP 2 (2, top)

Modularity Features

Table 2 shows modules for this router.

Models	Description
C3900-SPE150/K9	Cisco Services Performance Engine 150 for Cisco 3945 ISR. (It's a configured item in the CISCO3945/K9.)
SM-ES3G-16-P	Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology
SM-ES3G-24-P	Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology
VWIC3-2MFT-G703	Cisco Voice/WAN Card VWIC3-2MFT-G703
HWIC-2T	2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card
EHWIC-1GE-SFP-CU	Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU
EHWIC-4ESG	Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers
ISM-SRE-300-K9	Internal Services Module (ISM) with Services Ready Engine
MEM-CF-256U1GB	256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900
MEM-CF-256U2GB	256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900
MEM-CF-256U512MB	256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR
MEM-CF-256U4GB	256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900

Compare to Similar Routers

Table 3 shows the comparison of CISCO3945/k9 and C3945-CME-SRST/K9.

Model	CISCO3945/k9	C3945-CME-SRST/K9
Bundle	N/A	Cisco 3945 Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK
SPE	w/SPE 150	w/SPE 150
Interface	3GE	3GE
EHWIC slots	4	4
SM slots	4	4
ISM slots	1	1
DSP	4	4
SFP	2	2
Rack Unit	3U	3U

Get more information

Do you have any question about the C3945-CME-SRST/K9 router?

C3945-CME-SRST/K9 Specification

C3945-CME-SRST/K9 Specifications
Device Type	Router
Bundle	Cisco 3945 Voice Bundle w/ PVDM3-64,FL-CME-SRST-25, UC License PAK
Form Factor	Desktop - modular - 3U
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol	OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing
Remote Management Protocol	SNMP, RMON
Features	Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED)
Compliant Standards	IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag
DRAM Memory	1 GB (installed) / 2 GB (max)
Flash Memory	256 MB (installed) / 8 GB (max)
LED Status Lights Indicators	Link activity, power
Communications
Type	Voice / fax module
Digital Ports Qty	64
IP Telephony
Voice Codecs	G.711, G.722, G.723.1, G.728, G.729, G.729a, G.729ab, G.726
Connectivity Slots
Router Interfaces	3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 Management : 1 x console - RJ-45 Management : 1 x console - mini-USB Type B Serial : 1 x auxiliary - RJ-45 USB : 2 x 4 PIN USB Type A 2 x SFP (mini-GBIC)
Expansion Slots Total (Free)	4 ( 4 ) x HWIC 3 ( 2 ) x PVDM 2 ( 1 ) x CompactFlash Card 1 ( 1 ) x Expansion Slot
Power Supply
Power Device	Power supply - internal
Voltage Required	AC 120/230 V ( 50/60 Hz )
Dimensions / Weight / Miscellaneous
Width	47.6 cm
Depth	43.8 cm
Height	8.9 cm
Weight	17.7 kg
Compliant Standards	CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, AS/NZS 3548, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438
System Software
Software Included	Cisco IOS Unified Communications, Cisco Unified Communications Manager Express / Cisco Unified Survivable Remote Site Telephony (25 phones)
