The HP StoreEasy 1840 Storage is a flexible, scalable, and easy-to-use storage solution designed to meet the growing storage demands of small and medium businesses. It offers simplified management, reliable performance, and efficient data protection, making it ideal for various storage-intensive applications.
Quick Spec
Table 1 shows the quick spec of HP StoreEasy 1840 Storage.
| Product Name | HP StoreEasy 1840 Storage |
| Product Number | E7W85A |
| Form Factor | 2U Rack-mountable |
| Drive Type | LFF (3.5in) and SFF (2.5in) |
| Max Storage Capacity | Up to 224TB |
Product Features
- Flexible and scalable storage solution
- Simplified management and maintenance
- Reliable performance and data protection
- Supports various storage-intensive applications
- Designed for small and medium businesses
Product Applications
- File sharing and collaboration
- Backup and archiving
- Virtualization and high-performance computing
Supported Options
Table 2 shows the supported options of HP StoreEasy 1840 Storage.
| Option | Model |
| Drive Enclosure | HP 3PAR 8000 LFF/SFF Drive Enclosure |
| Storage Controller | HP StoreEasy Smart Array Controllers |
| Power Supply | HP StoreEasy Redundant Power Supply |
Get more information
Do you have any question about the HP StoreEasy 1840 Storage?
Contact us now via Live Chat or [email protected].
E7W85A Specification
E7W85A Specifications |
|
| Product Model | E7W85A |
| Product Name | HP StoreEasy 1840 Storage |
| Processor | 2 x Intel Xeon E5-2620 v4 8-core processors |
| Memory | 64 GB (8 x 8 GB) DDR4 Registered DIMMs |
| Number of Bays | 12 LFF or 24 SFF hot-plug drive bays |
| Supported Drives | HDDs: 1 TB, 2 TB, 3 TB, 4 TB, 6 TB, 8 TB, 10 TB, 12 TB, 14 TB, 16 TB; SSDs: 240 GB, 480 GB, 960 GB, 1.92 TB, 3.84 TB |
| Drive Interface | SAS, SATA, SSD |
| Maximum Capacity | Up to 576 TB (using 24 x 24 TB HDDs) |
| Host Connectivity | 4 x 10 Gb/sec Ethernet ports, 2 x 10 Gb/sec iSCSI ports, 2 x 1 Gb/sec Ethernet ports for management |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| Expansion | Up to 7 additional disk enclosures (E7W89A) for a total of 192 LFF or 384 SFF drives |
| Supported Operating Systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| Management | HP StoreEasy Management Console, Command Line Interface, SNMP, REST API |
| Supported Protocols | CIFS/SMB, NFS, FTP, HTTP, HTTPS, iSCSI, SNMP, SMTP, Telnet, SSH, SFTP |
| Redundancy Features | Redundant hot-swappable power supplies and cooling fans |
| Dimensions (W x D x H) | 445 mm x 742.2 mm x 132.1 mm |
| Power Consumption | Maximum power consumption of 1200 W |
| Operating Temperature | 10°C to 35°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% (non-condensing) |
