Cisco catalyst 2960X-24PSQ-L LAN Base standalone Layer 2 switch offers twenty-four 10/10/1000 Ethernet Gigabit ports and two 1G SFP, and two Copper 10/100/1000 uplink interfaces. The industry standard IEEE802.3at PoE+ provides up to 110W PoE power which can powers up to 8 ports of POE(first eight ports only) with 12.95W per port or 7 ports of POE with 15.4W per port or 3 ports of POE with 30W per port.
Quick Specs
Figure 1 shows the appearance of WS-C2960X-24PSQ-L.
Table 1 shows the Quick Specs
|
Product Code |
WS-C2960X-24PSQ-L |
|
Enclosure Type |
Rack-mountable - 1U |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x 1G SFP + 2 x 10/100/1000BT |
|
Ports |
24 x 10/100/1000 Ethernet Gigabit ports (8 PoE) |
|
Available PoE Power |
110W |
|
Maximum stacking number |
Not Supported |
|
Stack bandwidth |
Not Supported |
|
Forwarding Performance |
71.4Mpps |
|
Switching Bandwidth |
216Gbps |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Dimensions |
44.5 cm x 28 cm x 4.45 cm |
Product Details
Figure 2 shows the front panel of WS-C2960X-24PSQ-L.
Note:
|
① |
One Console Port |
⑤ |
Two USB Ports |
|
② |
24 x 10/100/1000 Ethernet Gigabit Ports (8 PoE) |
⑥ |
One USB mini Port |
|
③ |
2 x 10/100/1000BT |
⑦ |
LEDs Area |
|
④ |
2 x 1G SFP |
⑧ |
One MGMT Port |
- LEDs area include SYST (system), STAT (status), SPEED, and POE LEDs.
The Accessories
Table 2 shows some accessories of the WS-C2960X-24PSQ-L.
|
Models |
Description |
|
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Console Cable 6ft with RJ45 and DB9F |
|
|
Console Cable 6 ft with USB Type A and mini-B |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
WS-C2960X-24PSQ-L |
|
|
Ports |
24 x Ethernet 10/100/1000 Gigabit ports (8 PoE) |
24 x Ethernet 10/100/1000 Gigabit, PoE ports |
|
Uplinks |
2 x 1G SFP + 2 x 10/100/1000BT |
4 x 1G SFP |
|
Feature Set |
LAN Base |
LAN Base |
|
FlexStack-Plus Stacking |
Not Supported |
Optional |
|
Available PoE Power |
110W |
370W |
Get more information
Do you have any question about the Cisco Catalyst C2960X-24PSQ-L switch?
Contact us now via Live Chat or [email protected].
WS-C2960X-24PSQ-L Specification
WS-C2960X-24PSQ-L Specification |
|
|
Enclosure type |
Rack-mountable - 1U |
|
Ports |
24 x 10/100/1000 + 2 x 1G SFP + 2 10/100/1000BT |
|
Network management Interface |
10/100 Mbps Ethernet (RJ-45) |
|
Available PoE Power |
110W |
|
Forwarding bandwidth(Gbps) |
108Gbps |
|
Maximum stacking number |
None |
|
Stack Bandwidth |
None |
|
Forwarding Performance |
71.4Mpps |
|
Switching bandwidth |
216Gbps |
|
Maximum active VLANs |
1023 |
|
MAC Address Table Size |
16K (default) |
|
CPU |
APM86392 600MHz dual core |
|
RAM |
256 MB |
|
Flash Memory |
64 MB |
|
Status Indicators |
Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, PoE, and link speed |
|
Expansion / Connectivity |
|
|
Console ports |
USB (Type-B), Ethernet (RJ-45) |
|
Stacking cable |
None |
|
Power Redundancy |
Option (PWR-RPS2300) |
|
Voltage range (Auto) |
110V-240V |
|
Power Consumption Operational |
0.16KVA |
|
Miscellaneous |
|
|
Width |
17.5 Inches (44.5 cm) |
|
Depth |
11.03 Inches (28 cm) |
|
Height |
1.73 Inches (4.45 cm) |
|
Weight |
12.8 Pounds (5.8 Kg) |
|
Rack Mounting Kit |
optional |
|
MTBF in hours |
462,680 |
|
Compliant Standards |
● IEEE 802.1D Spanning Tree Protocol ● IEEE 802.3 10BASE-T |
|
System software / license |
|
|
System software |
IOS LAN BASE |
|
license |
NERGY-MGT-100-K9, EW-DO-100-DE |
|
features |
●Jumbo Frames ●VLANS ●Voice Vlan ●VTPv2 ●CDPv2 ●LLDP ●802.3ad LACP ●PVST/PVST+ ●802.1W/802.1S ●Port Fast/Uplink Fast ●port CoS Trust and Override ●Scheduling ●Priority Queuing ●Configure CoS Priority Queues ●Weighted Tail Drop ●DSCP transparency |
|
Network security |
●SSH, SSL and SCP ●RADIUS and TACACS+ ●SNMPv3 crypto ●802.1x ●802.1x Accounting / MIB ●802.1x w/ port security ●802.1x w/Voice VLAN ●802.1x Guest VLAN ●802.1x VLAN assignment ●802.1x MAC-Auth Bypass ●BPDU/Root Guard ●Port Security ●Private VALN Edge ●Storm Control ●Block unknown unicast and multicast ●IGMP Snooping ●IGMP Filter/Throttle |
|
Management and Troubleshooting |
●Auto-MDOX ●TDR ●UDLD ●IP SLA Responder ●layer 2 / IP Traceroute ●SPAN ●RSPAN ●Express Setup ●Device Manager ●Cisco Network Assistant ●Smartports + Advisor ●Troubleshooting Advisor ●Drag-and-drop Cisco IOS Upgrade ●IP Address DHCP ●Autoinstall with saved configuration ●Configuration Replace ●DHCP Auto Image Upgrade ●DHCP Port Based Allocation ●Error Disable MIB |
|
Environmental Ranges |
|
|
Operating temperature up to 5000 ft (1500 m) |
23ºF to 113ºF (-5ºC to 45ºC) |
|
Operating temperature up to 10,000 ft (3000 m) |
23ºF to 104ºF (-5ºC to 40ºC) |
|
Short-term exception at sea level* |
23ºF to 131ºF (-5ºC to 55ºC) |
|
Short-term exception up to 5000 feet (1500 m)* |
23ºF to 122ºF (-5ºC to 50ºC) |
|
Short-term exception up to 10,000 feet (3000 m)* |
23ºF to 113ºF (-5ºC to 45ºC) |
|
Short-term exception up to 13,000 feet (4000 m)* |
23º to 104ºF (-5ºC to 40ºC) |
|
Storage temperature up to 15,000 feet (4573 m) |
-13º to 158ºF (-25º to 70ºC) |
|
Operating altitude |
Up to 10,000 Feet (Up to 3000 Meters) |
|
Storage altitude |
Up to 13,000 (Up to 4000 Meters) |
|
Operating relative humidity |
10% to 95% noncondensing |
|
Storage relative humidity |
10% to 95% noncondensing |
