WS-C2960CX-8PC-L equips 8 Gigabit Ethernet POE+ ports with 2 x 1 Gigabit copper and 2 x 1 Gigabit SFP uplinks. The POE powers up to 30W/port and supplies total 124W POE budget which can power IP phones, IP Cam or other POE devices.
Quick Specs
Figure 1 shows the appearance of WS-C2960CX-8PC-L.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C2960CX-8PC-L |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x 1G copper plus 2 x 1G SFP |
|
Ports |
8 x 10/100/1000 Gigabit Ethernet ports |
|
Available POE Power |
124W |
|
Forwarding Bandwidth |
12 Gbps |
|
Switching Bandwidth (full-duplex capacity) |
24 Gbps |
|
RAM |
512 MB |
|
Flash Memory |
128 MB |
|
Dimensions |
4.44 x 26.9 x 23.8 cm |
|
Package Weight |
4.65 Kg |
Product Details
Figure 2 shows the front panel of WS-C2960CX-8PC-L.
Note:
|
① |
Mode button |
⑤ |
8 x 10/100/1000 ports |
|
② |
USB Type A port |
⑥ |
2 x 1G copper |
|
③ |
RJ-45 Console Port |
⑦ |
SFP module slots |
|
④ |
USB mini-Type B (console) port |
⑧ |
LED Area |
Table 2 shows the four LEDs descriptions.
|
LED |
Color/Port Mode |
Description |
|
SYST (System LED) |
Off |
System is not powered on. |
|
Green |
System is operating normally. |
|
|
Amber |
System is receiving power but is not operating properly. |
|
|
STAT |
Port status |
The port status. This is the default mode. |
|
SPEED |
Port speed |
The port operating speed: 10, 100, or 1000 Mb/s. |
|
POE |
Off |
PoE is not enabled. |
|
Green |
PoE is enabled. Ports are functioning correctly. |
|
|
Blinking Amber |
-PoE mode is not selected -At least one of the 10/100 or 10/100/100 PoE ports has been denied power -At least one of the ports has a PoE fault |
The console LEDs show which console port is in use.
If you connect a cable to a console port, the switch automatically uses that port for console communication. If you connect two console cables, the USB-mini console port has priority.
Table 3 shows the Console LED description.
|
LED |
Color |
Description |
|
RJ-45 console port |
Green |
RJ-45 console port is active. USB-mini console port LED is not active. |
|
Off |
Port is not active. USB-mini console port is active. |
|
|
USB-mini console port |
Green |
USB-mini console port is active. RJ-45 console port LED is not active. |
|
Off |
Port is not active. RJ-45 console port is active. |
The Accessories
Table 4 shows some recommended cables.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
Compare to similar item
|
Models |
WS-C2960CX-8PC-L |
|
|
Uplinks |
2 x 1G copper or 2 x 1G SFP |
2 x 1G copper or 2 x 1G SFP |
|
Ports |
8 x 10/100/1000 Gigabit Ethernet |
8 x 10/100/1000 Gigabit Ethernet |
|
Feature set |
LAN Base |
LAN Base |
|
Available POE Power |
124W |
None |
Solution
How to use this product to build Network for Small Business (Requires Router & Voice Module)?
See here: SMB Network Options
Get more information
Do you have any question about the WS-C2960CX-8PC-L?
Contact us now via Live Chat or [email protected].
WS-C2960CX-8PC-L Specification
WS-2960CX-8PC-L Specification |
|
|
Ethernet Ports |
8 x 10/100/1000 Gigabit Ethernet |
|
PoE |
8 PoE+ |
|
Available |
124W |
|
Uplinks |
2 x 1G copper plus 2 x 1G SFP |
|
Default Software |
LAN Base |
|
Forwarding Bandwidth |
12 Gbps |
|
Switching Bandwidth (full-duplex capacity) |
24 Gbps |
|
Flash memory |
128 MB |
|
Memory DRAM |
512 MB |
|
Max VLANs |
255 |
|
VLAN IDs |
4000 |
|
Maximum transmission unit (MTU) |
Up to 9000 bytes |
|
Jumbo frames |
9198 bytes |
|
Forwarding rate 64 Byte Packet |
17.9 mpps |
|
Power connectors |
- Customers can provide power to a switch by using the internal power supply. The connector is located at the back of the switch. The internal power supply is an autoranging unit - The internal power supply supports input voltages between 100 and 240VAC |
|
Indicators |
Per-port status: Link integrity, disabled, activity, speed, full-duplex System status: System, link status, link duplex, link speed |
|
Dimensions |
1.75 x 10.6 x 9.4 in (4.44 x 26.9 x 23.8 cm) |
|
Weight |
5.0 lb (2.27 Kg) |
|
Package Weight |
10.25 lb (4.65 Kg) |
|
Operating* temperature up to 5000 ft (1524 m) |
-5°C to +45°C (+23°F to +113°F) |
|
Operating* temperature up to 10,000 ft (3048 m) |
-5°C to +45°C (+23°F to +113°F) |
|
Storage temperature up to 15,000 ft (4572 m) |
-25°C to +70°C (-13°F to +158°F) |
|
Operating altitude |
Up to 3048 m (Up to 10,000 ft) |
|
Storage altitude |
Up to 4000 m (Up to 15,000 ft) |
|
Operating relative humidity |
5% to 95% noncondensing |
|
Storage relative humidity |
5% to 95% noncondensing |
|
Mean time between failure (MTBF) |
569,530 |
