Dell PowerEdge T30 Mini Tower Server is ideal for small office/home office collaboration, file storage and sharing, and data protection. This model is the Dell PowerEdge T30 server with E3-1225 v5 processor, 8GB memory and 1TB hard drive.
Quick Specs
Table 1 shows the quick spec.
|
Product Series |
Dell PowerEdge T30 Server |
|
Fixed Configuration |
Intel® Xeon® processor E3-1225 v5, 8GB memory, 1TB hard drive, SATA and a 1 year warranty |
|
Processor |
Intel Xeon E3-1225 v5 3.3G, 8M cache, 4C/4T, turbo (80W) |
|
Operating System |
No Operating System |
|
Memory |
8GB UDIMM, 2400MT/s, Single Rank, x8 Data Width |
|
Hard Drive |
1TB 7.2K RPM SATA 6Gbps Entry 3.5in Cabled Hard Drive |
|
RAID Controllers |
Software RAID: Intel Rapid Storage Controller 12.0 (supports SATA 6Gb/s or SATA 3Gb/s) |
|
Dimensions |
Height: 14.17 inch / 359.9mm |
Product Details
Figure 1 shows the front and back panel description of Dell PowerEdge T30 Server.
Front Panel:
|
① |
Power indicator, power button |
⑤ |
USB 3.0 port (2) |
|
② |
Optical drive (optional) |
⑥ |
USB 2.0 port (2) |
|
③ |
Microphone connector |
⑦ |
Drive status indicator |
|
④ |
Headphone connector |
|
Back Panel:
|
① |
AC power status indicator |
⑨ |
USB 3.0 port (4) |
|
② |
Self-diagnostic button |
⑩ |
Line-out connector |
|
③ |
Power connector |
⑪ |
Line-in or microphone connector |
|
④ |
PS/2 mouse port |
⑫ |
Expansion card slots (4) |
|
⑤ |
PS/2 keyboard port |
⑬ |
Padlock ring |
|
⑥ |
USB 2.0 port (2) |
⑭ |
Security-cable slot |
|
⑦ |
Display ports (2) |
⑮ |
Ethernet port (NIC) |
|
⑧ |
HDMI port |
⑯ |
Serial port |
Compare to Similar Item
Table 2 shows the comparison.
|
Product Model |
Dell PowerEdge T30 Xeon E3-1225 v5 8GB 1TB SATA Tower Server |
|
|
Product Series |
Dell PowerEdge T30 Server |
Dell PowerEdge T30 Server |
|
Fixed Configuration |
Intel® Pentium® G4400 processor, 4GB memory, 1TB hard drive, SATA and a 1 year warranty |
Intel® Xeon® processor E3-1225 v5, 8GB memory, 1TB hard drive, SATA and a 1 year warranty |
|
Processor |
Intel Pentium G4400 3.3GHz, 3M cache, 2C/2T, no turbo (54W) |
Intel Xeon E3-1225 v5 3.3G, 8M cache, 4C/4T, turbo (80W) |
|
Operating System |
No Operating System |
No Operating System |
|
Memory |
4GB UDIMM, 2400MT/s, Single Rank, x8 Data Width |
8GB UDIMM, 2400MT/s, Single Rank, x8 Data Width |
|
RAID Controllers |
Software RAID: Intel Rapid Storage Controller 12.0 (supports SATA 6Gb/s or SATA 3Gb/s) |
Software RAID: Intel Rapid Storage Controller 12.0 (supports SATA 6Gb/s or SATA 3Gb/s) |
|
Optical Drive |
No Internal Optical Drive |
DVD+/-RW SATA Internal |
Dell Server Configuration
Table 3 shows the Dell T30 Server Configuration. You can contact us to order a T30 server according to this guide.
|
Model |
|
|
Description |
Ideal for small office/home office collaboration, file storage and sharing, and data protection |
|
Processor |
1 processor from the following product families: Intel® Xeon® processor E3-1225 v5 Intel Pentium® G4400 |
|
Memory |
Architecture: 4 DIMM slots |
|
PCI Slots |
4 slots: |
|
Network Controller |
Intel I219-LM Gigabit Ethernet LAN 10/100/1000 1-port |
|
Storage |
Up to 6 total SATA HDDs (4 x 3.5” SATA HDD + 2 additional 2.5” SATA HDD (w/ expansion kit and optional controller card) |
Dell PowerEdge T30 Xeon E3-1225 v5 8GB 1TB SATA Tower Server Specification
Dell PowerEdge T30 Xeon E3-1225 v5 8GB 1TB SATA Tower Server Specification |
|
|
Product Series |
Dell PowerEdge T30 Server |
|
Model |
Dell PowerEdge T30 Pentium G4400 4GB 1TB SATA Tower Server |
|
Fixed Configuration |
Intel® Xeon® processor E3-1225 v5, 8GB memory, 1TB hard drive, SATA and a 1 year warranty |
|
Processor |
Intel Xeon E3-1225 v5 3.3G, 8M cache, 4C/4T, turbo (80W) |
|
Operating System |
No Operating System |
|
Memory |
8GB UDIMM, 2400MT/s, Single Rank, x8 Data Width |
|
Hard Drive |
1TB 7.2K RPM SATA 6Gbps Entry 3.5in Cabled Hard Drive |
|
Warranty |
1Yr Basic Hardware Warranty Repair: 5x10 HW-Only, 5x10 NBD Parts |
|
Optical Drive |
DVD+/-RW SATA Internal |
|
Chipset |
Intel C236 |
|
Storage |
Up to 6 total SATA HDDs (4 x 3.5” SATA HDD + 2 additional 2.5” SATA HDD (w/ expansion kit and optional controller card) |
|
Slots |
4 slots: 1 PCI |
|
RAID Controllers |
Software RAID: Intel Rapid Storage Controller 12.0 (supports SATA 6Gb/s or SATA 3Gb/s) |
|
Network Controller |
Intel I219-LM Gigabit Ethernet LAN 10/100/1000 1-port |
|
Power |
290W |
|
Availability |
Error Correction Code (ECC) memory |
|
Chassis |
Mini tower |
|
Management |
Intel AMT 11.0 (supported on Intel Xeon config) |
|
Dimensions |
Height: 14.17 inch / 359.9mm |
|
Ports |
10x USB, 1 microphone, 1x headphone, PS2, Displayport, HDMI, RJ45, serial, audio in, audio out |
