E7V99A is an HPE MSA 1040 2 Port FC DC LFF Storage, including LFF Array Chassis and two MSA 1040 FC 2-port controllers, SFPs installed, but drives not included. HPE MSA 1040 Storage offers many of the MSA 2040 features but at lower entry price points. ProLiant and BladeSystems administrators as well as IT generalists will find storage management tasks simple and intuitive with MSA. The MSA 1040 arrays leverage a new fourth-generation controller architecture with a new processor, 2-host ports and 4 GB data (read/write) cache and 2 GB of system memory per controller. Take advantage of the latest hard drive and solid state drive advances by selecting the HDD form factor and technology which best meet your application and budget requirements. Unlike many competing arrays, the MSA 1040 ships standard with intuitive management tools and powerful data services such as snapshots for increased data protection.
Quick Spec
Table 1 shows the quick spec.
|
Model |
E7V99A |
|
Capacity Single Enclosure and Maximum Additional Drive Enclosures |
120 TB (single LFF array-head -using 12 x 10TB LFF SAS MDL drives) 480 TB (by adding 3 LFF Disk Enclosures behind LFF Array & using 10 TB LFF SAS MDL drives) |
|
Cache |
6 GB per controller |
|
Host Interconnect |
2 x 8Gb Fibre Channel ports per controller |
Product Details
Figure 1 shows the MSA 1040 Array LFF or supported 12-drive expansion enclosure.
Note:
|
① |
Left ear |
⑤ |
Disk drive Fault/UID LED |
|
② |
Disk drive Slots |
⑥ |
Disk drive Online/Activity LED |
|
③ |
Right ear |
⑦ |
Enclosure ID LED |
|
④ |
Unit Identification (UID) LED Heartbeat LED Fault ID LED |
|
|
Figure 2 shows the rear panel layout of the MSA 1040 controller enclosure.
Note:
|
① |
AC Power supply |
|
② |
Controller module A |
|
③ |
AC Power supply |
|
④ |
Controller module B |
Supported Hardware
Table 2 shows the supported hardware.
|
SKU |
Description |
|
HPE MSA 10TB 12G SAS 7.2K LFF 1yr Wty 512e HDD |
|
|
HP MSA 8TB 12G SAS 7.2K 3.5in 512e HDD |
|
|
HP MSA 300GB 12G SAS 15K 3.5in CC HDD |
|
|
HP MSA 450GB 12G SAS 15K 3.5in CC HDD |
|
|
HP MSA 600GB 12G SAS 15K 3.5in CC HDD |
Compare to Similar Items
Table 3 shows the comparison.
|
Model |
E7V99A |
||
|
Description |
HPE MSA 1040 2 Port FC DC LFF Storage |
HPE MSA 1040 2 Port FC DC SFF Storage |
HPE MSA 1040 2 Port 1G ISCSI DC LFF Storage |
|
Hard Disks |
LFF |
SFF |
LFF |
|
Host interface |
MSA 1040 2-port FC Controller |
MSA 1040 2-port FC Controller |
MSA 1040 2-port 1GbE iSCSI Controller |
|
Form factor |
2U base array, 2U LFF |
2U base array, 2U SFF |
2U base array, 2U LFF |
Get More Information
Do you have any question about the E7V99A?
Contact us now via Live Chat or [email protected].
E7V99A Specification
MSA 1040 Specification |
|
|
Capacity Single Enclosure and Maximum Additional Drive Enclosures |
LFF: 120 TB (single LFF array-head -using 12 x 10TB LFF SAS MDL drives) 480 TB (by adding 3 LFF Disk Enclosures behind LFF Array & using 10 TB LFF SAS MDL drives) SFF: 43.2 TB (single SFF array-head - using 24 x 1.8TB SFF SAS drives) 178.2 TB (by adding 3 SFF Disk Enclosures behind SFF Array & using 1.8TB SFF SAS drives) NOTE: 1) maximum available storage capacity depends on the RAID level being implemented |
|
Pool Capacity |
GL200: 169 TB (154 TiB) GL210: 219 TB (200 TiB) GL220: 329 TB (300 TiB) GL220 with Large Pool Support: 562 TB (512 TiB) NOTE: 1) The above pool capacities by firmware release apply to virtual storage only 2) The above capacities are usable capacity/pool. Each MSA system can support two pools. Therefore each MSA storage system can have double the usable capacity listed above |
|
Cache |
6 GB per controller NOTE: 6GB cache includes Data (Read/Write) cache = 4GB and Metadata and System OS cache = 2GB |
|
Total LUNs (LUN size are dependent of the storage architecture: Linear vs. Virtualized) |
size: 140TB (128TiB) Thin Provisioning allows you to create the LUNs independent of the physical storage |
|
Host Interconnect |
2 x 8Gb Fibre Channel ports per controller 2 x 1GbE RJ-45 ports per controller 2 x 10GbE ports per controller 2x 12Gb SAS ports per controller |
|
Maximum Drives w/ 3 expansion |
48 LFF/99 SFF |
|
Maximum Host Supported |
64 in v2 UI 512 in v3 UI |
|
Standard Software |
Snapshots (64) |
|
Optional Software |
Remote Snap (linear storage only) Max Snapshot (512) |
