Huawei new-generation RH2288H v3 rack server delivers high-performance, large storage capacity and scalability in 2U space. This server is ideal for Internet, big data, cloud computing, high-performance computing, telecom service and mission-critical applications. Huawei RH2288H V3 Rack Server supports two Intel Xeon E5-2600 V3 series processors, 24 DDR4 DIMMS, 9 PCIe slots and optional Huawei high-performance PCIe SSDs and dual-slot GPUs. With the Industry-leading RAID technologies and flexible storage expansion, Huawei RH2288H V3 Rack Server can supports from 8 to 28 hard disks and employs the latest 12Gbits/s SAS technology to support massive data transmission. This RH2288H V3 Rack Server offers 4 configurations, including 8-disk configuration, 10-disk configuration, 12-disk configuration and 25-disk configuration.
Quick Specs
Table 1.
|
Product |
Huawei RH2288H V3 Rack Server |
|
Processors |
Intel® Xeon® E5-2600 v3/v4 series processors |
|
Memory |
24 DDR4 RDIMMs/LRDIMMs |
|
Internal Storage |
Hard disk configurations: · 8 x 2.5-inch front SAS/SATA HDDs or SSDs· 10 x 3.5-inch front SATA HDDs · 12 x 3.5-inch front SAS/SATA HDDs (4 NVMe SSDs supported by the NVMe model) and 2 rear hard disk modules, each module providing 2 x 2.5-inch SAS/SATA HDDs or SSDs, or 2 x 3.5-inch SAS/SATA HDDs · 25 x 2.5-inch front SAS/SATA HDDs or SSDs and 2 or 3 x 2.5-inch rear SAS/SATA HDDs or SSDs Built-in flash memory: · 2 mini-SSD cards (SATADOMs)· 2 SD cards |
|
RAID |
· RAID 0, 1, 10, 5, 50, 6, or 60 · Configured with a supercapacitor for power-off protection for the cache (optional) · RAID state transition, configuration memory, self-diagnosis, and web-based remote configuration |
|
LOM Network Ports |
2 GE or 4 GE ports, or 2 x 10 GE ports, or 2 x 56 Gbit/s FDR InfiniBand ports |
|
PCIe Expansion |
Up to 9 PCIe 3.0 slots |
|
Fan Modules |
Hot-swappable fan modules in N+1 redundancy mode |
|
Power Supply Units |
2 hot-swappable PSUs in 1+1 redundancy mode |
|
Management |
· Uses the Huawei Hi1710 management chip and independent ports · Supports standard management interfaces, such as SNMP and IPMI; provides GUI, remote KVM, virtual media, SOL, Predictive Failure Analysis (PFA), intelligent power supply, remote control, and hardware monitoring Incorporates a touchscreen LCD panel for fault diagnosis · Supports Huawei eSight management software and integration with third-party management systems, such as VMware vCenter, Microsoft System Center, and Nagios |
|
Operating Temperature |
5°C to 45°C (41°F to 113°F), ASHRAE Class A3 and A4 compliant |
|
Dimensions (W x D x H) |
RH2288H V3 with 3.5-inch hard disks: 447 mm x 748 mm x 86.1 mm RH2288H V3 with 2.5-inch hard disks: 447 mm x 708 mm x 86.1 mm |
Product Details
Figure 1 shows the configurations of RH2288H V3 server.
Figure 1-1 RH2288H V3 server 8-disk configuration.
Figure 1-2 RH2288H V3 server 10-disk configuration.
Figure 1-3 RH2288H V3 server 12-disk configuration.
Figure 1-4 RH2288H V3 server 25-disk configuration.
Figure 2 shows the back panel of RH1288 V3 server.
Note:
|
① |
LAN on motherboard (LOM) |
⑦ |
Serial port |
|
② |
UID indicator |
⑧ |
Power socket for a PSU |
|
③ |
USB 3.0 port |
⑨ |
Power Supply Unit (PSU) |
|
④ |
USB 3.0 port |
⑩ |
I/O module 1 (providing slots 1 to 3 from top to |
|
⑤ |
Mgmt management network port |
⑪ |
Onboard PCIe slots (numbered 4) |
|
⑥ |
VGA port |
⑫ |
Onboard PCIe slots (numbered 5) |
Compare to Similar Items
Table 2 shows the comparison of HUAWEI RH1288 V3 RACK SERVER and HUAWEI RH2288H V3 RACK SERVER.
|
Model |
HUAWEI RH2288H V3 RACK SERVER |
|
|
Processors |
Intel® Xeon® E5-2600 v3/v4 series processors |
Intel® Xeon® E5-2600 v3/v4 series processors |
|
Memory |
16 DDR4 RDIMMs/LRDIMMs |
24 DDR4 RDIMMs/LRDIMMs |
|
LOM Network Ports |
2 GE or 4 GE ports, or 2 x 10 GE ports, or 2 x 56 Gbit/s FDR InfiniBand ports |
2 GE or 4 GE ports, or 2 x 10 GE ports, or 2 x 56 Gbit/s FDR InfiniBand ports |
|
PCIe Expansion |
Up to 3 PCIe slots |
Up to 9 PCIe 3.0 slots |
|
Fan Modules |
5 hot-swappable fan modules in N+1 redundancy mode |
Hot-swappable fan modules in N+1 redundancy mode |
|
Power Supply Units |
2 hot-swappable PSUs in 1+1 redundancy mode |
2 hot-swappable PSUs in 1+1 redundancy mode |
Get more information
Do you have any question about the HUAWEI RH2288H V3 RACK SERVER?
Contact us now via Live Chat or [email protected].
Huawei RH2288H V3 Rack Server Specification
HUAWEI RH2288H V3 RACK SERVER Specifications |
|
|
Processors |
One or two Intel Xeon E5-2600 v3 series processors |
|
Memory |
24 DDR4 RDIMMs/LRDIMMs |
|
Internal Storage |
Hard disk configurations: |
|
RAID Support |
● RAID 0, 1, 10, 5, 50, 6, or 60 |
|
LOM Network Ports |
Two GE electrical ports, supporting NC-SI, WOL, and PXE |
|
PCIe Expansion |
Up to 9 PCIe 3.0 slots |
|
Fan Modules |
Hot-swappable fan modules in N+1 redundancy mode |
|
PSUs |
2 hot-swappable PSUs in 1+1 redundancy mode |
|
Management |
● Uses the Huawei Hi1710 management chip and independent ports, supports standard management interfaces, such as SNMP and IPMI, provides the GUI, remote KVM, virtual media, SOL, Predictive Failure Analysis (PFA), intelligent power supply, remote control, and hardware monitoring, all integrated in a touch LCD diagnosis panel |
|
Operating Temperature |
5ºC to 35ºC (41ºF to 95ºF) |
