The Cisco® 10000 Series Router 10000-1P3-1DC is the industry-leading edge router for service providers that require subscriber awareness for delivering triple-play (data, voice, and video), broadband, and wholesale access while migrating from ATM to Gigabit Ethernet. The Cisco 10000 Series is unique in that it offers a comprehensive, single solution for business services, Multiprotocol Label Switching (MPLS), and broadband aggregation. It is built to be carrier-class with Cisco IOS® Software and hardware features. Cisco used its experience working with the world's largest service providers to optimize the Cisco 10000 Series for scalable, high-performance IP and MPLS services with five-nines (99.999) reliability.
Quick Spec
Figure 1 shows the appearance of 10000-1P3-1DC.
Table 1 shows the quick spec.
|
Product Name |
10000-1P3-1DC |
|
Product Description |
Cisco 10000 8-slot chassis, 1 PRE-3, 1 DC PEM |
|
Backplane capacity |
51.2 Gbps |
|
Physical dimensions (H x W x D) |
21.75 x 17.5 x 12 in. (55.2 x 44.5 x 30.5 cm) |
|
Weight |
130 lb (59.02 kg) fully configured chassis |
|
Rack-mounting |
19 to 23 in. (48.3 to 58.4 cm) (front, middle, or back) |
|
Power |
• DC input voltage: -48/-60 VDC • AC input voltage: 100-240 VAC, 50/60 Hz, single phase • Maximum power consumption: 1500 VA for AC PEM, 1280W for DC PEM |
Compare to Similar Items
Table 2 shows the comparison between 10000-1P3-1DC and 10000-1P3-1AC.
|
Product Name |
10000-1P3-1DC |
|
|
Product Description |
Cisco 10000 8-slot chassis, 1 PRE-3, 1 DC PEM |
Cisco 10000 8-slot chassis, 1 PRE-3, 1 AC PEM |
|
Backplane capacity |
51.2 Gbps |
51.2 Gbps |
|
Physical dimensions (H x W x D) |
21.75 x 17.5 x 12 in. (55.2 x 44.5 x 30.5 cm) |
21.75 x 17.5 x 12 in. (55.2 x 44.5 x 30.5 cm) |
|
Weight |
130 lb (59.02 kg) fully configured chassis |
130 lb (59.02 kg) fully configured chassis |
Get more information
Do you have any question about the 10000-1P3-1DC?
Contact us now via Live Chat or [email protected].
10000-1P3-1DC Specification
10000-1P3-1DC Specification |
|
|
Product Name |
10000-1P3-1DC |
|
Product Description |
Cisco 10000 8-slot chassis, 1 PRE-3, 1 DC PEM |
|
Modular slots |
• 8 slots for line cards; 16 slots for half-height line cards • 2 slots for Cisco PRE modules (1 active, 1 redundant) |
|
Hot-swappable |
Yes |
|
Backplane capacity |
51.2 Gbps |
|
Physical dimensions (H x W x D) |
21.75 x 17.5 x 12 in. (55.2 x 44.5 x 30.5 cm) |
|
Weight |
130 lb (59.02 kg) fully configured chassis |
|
Rack-mounting |
19 to 23 in. (48.3 to 58.4 cm) (front, middle, or back) |
|
Power |
• DC input voltage: -48/-60 VDC • AC input voltage: 100-240 VAC, 50/60 Hz, single phase • Maximum power consumption: 1500 VA for AC PEM, 1280W for DC PEM |
