Cisco 3500e Access Point - AIR-CAP3502E-T-K9 802.11a/g/n Ctrlr-based AP w/CleanAir; Ext Ant; T Reg Domain for Cisco Wireless AP
AIR-CAP3502E-T-K9 Specification
AIR-CAP3502E-T-K9 Specification | |
| General | |
| Device Type | Wireless access point |
| Width | 8.7 in |
| Depth | 8.7 in |
| Height | 1.9 in |
| Weight | 2.29 lbs |
| Localization | Taiwan |
| Processor / Memory / Storage | |
| RAM | 128 MB |
| Flash Memory | 32 MB |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 300 Mbps |
| Line Coding Format | CCK |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n |
| Spread Spectrum Method | OFDM |
| Status Indicators | Status |
| Features | Auto-sensing per device, power over Ethernet (PoE), MIMO technology, Wi-Fi Multimedia (WMM) support, CleanAir technology, Cisco M-Drive technology |
| Encryption Algorithm | AES, TLS, PEAP, TTLS, TKIP |
| Authentication Method | MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T - RJ-45 ¦ 1 x management - RJ-45 ¦ 6 x antenna |
| Miscellaneous | |
| Mounting Kit | Included |
| Compliant Standards | VCCI, ICES-003, EN 300.328, EN 301.489.1, EN 301.489.17, FCC Part 15.247, RSS-210, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, EN 301.893, FCC Part 15.407, EN 60601-1-2, ARIB STD-T66, ARIB STD-T71, ARIB STD-T33, CSA C22.2 No. 60950-1 |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime ¦ Limited warranty - replacement - 10 days |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 10 - 90% |
