WS-C4500X-F-32SFP+ is one of the Catalyst 4500-X series switches. The Catalyst 4500-X series switch is a fixed aggregation switch that delivers best-in-class scalability, simplified network virtualization, and integrated network services for space-constrained environments in campus networks.
Quick Specs
Figure 1 shows the appearance of WS-C4500X-F-32SFP+.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C4500X-F-32SFP+ |
|
Ports |
32 × 1G or 10G Ethernet ports (requires either SFP or SFP+ transceivers) |
|
Uplink Module Slot |
1Expansion Module (Optional): 8x10 GE SFP+/SFP - C4KX-NM-8SFP+ |
|
Management Port |
10/100/1000 Base-T |
|
USB Port |
Type A (storage and boot) up-to 4 GB |
|
Dual Power Supply |
Yes |
|
Field Replaceable Fans |
Yes (5 fans) |
|
Fan Redundancy |
No performance impact with single fan failure |
|
System Throughput |
Up to 800 Gbps |
|
Forwarding Entries |
32x10 GE Port Base SKU: IPv4: 256K, IPv6: 128K |
|
Flexible Netflow Entries |
128K |
|
Onboard Memory (SRAM DDR-II) |
4 GB |
|
Port Buffers |
32-MB Shared Memory |
|
CPU |
Dual Core 1.5 GHz |
|
NVRAM |
2 GB |
|
Optional External Memory (SD Card) |
2 GB |
|
System Power Consumption |
330W nominal/400W max ·Power supplies, either AC-input or DC-input, are not included in the basic configuration; they are ordered separately |
|
Airflow |
Back-to-front airflow (fan assemblies and the power supplies are color coded blue) |
|
Chassis dimensions (H x W x D) |
1.75 x 17.25 x 21 in. (4.4 x 43.8 x 53.3 cm) (H x W x D) |
|
Chassis weight |
19 lb (8.62 kg) (without power supplies) |
Product Details
Figure 2 shows the front panel of WS-C4500X-F-32SFP+.
Note:
|
① |
UID LED and switch combination |
|
② |
STATUS LED |
|
③ |
PS1 LED |
|
④ |
PS2 LED |
|
⑤ |
FAN LED |
|
⑥ |
USB ports (2 ports) Top port is a Type A connector; bottom port is a Type B connector |
|
⑦ |
Ethernet ports (32 port version shown) Note The 16 port version of the chassis does not have the block of 16 ports on the right side of the front panel. Ethernet ports require either an SFP or an SFP+ transceiver to operate. |
|
⑧ |
Port status LEDs (1 LED per port) |
|
⑨ |
8-port uplink module (part no. C4KX-NM-8SFP+) (Included as part of the WS-C4500X-24ES and WS-C4500X-40ES chassis; available as an optional upgrade on the other Catalyst 4500-X series chassis) |
Figure 3 shows the back panel of WS-C4500X-F-32SFP+ with installed AC-input power supply. No power supply is included in this product. Need to order a power supply in addition.
Note:
|
① |
SECURE DIGITAL port |
② |
CONSOLE port |
|
③ |
10/100/1000 MGT port |
④ |
Fan assemblies (5 assemblies) |
|
⑤ |
Chassis ground pad |
⑥ |
Power supply bay (AC-input power supply shown installed) |
|
⑦ |
Power supply bay (AC-input power supply shown installed) |
|
The Accessories
Table 2 shows the recommended elements for the WS-C4500X-F-32SFP+.
|
Category |
Model |
Description |
|
Power Supplies
|
Catalyst 4500X 750W AC back to front cooling 2nd power supply |
|
|
License
|
IP Base to Ent. Services license for 32 Port Catalyst 4500-X |
|
|
CARD
|
Catalyst 4500X 8 Port 10G Network Module |
|
|
Console Cable |
Console Cable 6ft with RJ45 and DB9F |
|
|
1G SFP
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM
|
||
|
1000BASE-T SFP
|
||
|
1000BASE-BX SFP, 1310NM
|
||
|
1000BASE-BX SFP, 1490NM |
||
|
1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM |
||
|
10G SFP
|
10GBASE-SR SFP Module |
|
|
10GBASE-LRM SFP Module |
||
|
10GBASE-CU SFP+ Cable 3 Meter
|
Compare to Similar Items
Table 3 shows the comparison of WS-C4500X-F-32SFP+ and WS-C4500X-16SFP+.
|
Model |
WS-C4500X-F-32SFP+ |
|
|
Ports |
32 × 1G or 10G Ethernet ports (requires either SFP or SFP+ transceivers) |
16 × 1G or 10G Ethernet ports (requires either SFP or SFP+ transceivers) |
|
Base System |
Back to Front Airflow |
Front to Back Airflow |
|
MTBF Information |
199,720 h |
209,330 h |
|
Fan assemblies |
5 assemblies (fan assemblies and the power supplies are color coded blue) |
5 assemblies (fan assemblies and the power supplies are color coded burgundy) |
Get more information
Do you have any question about the WS-C4500X-F-32SFP+?
Contact us now via Live Chat or [email protected].
WS-C4500X-F-32SFP+ Specification
WS-C4500X-F-32SFP+ Specification |
|
|
System |
|
|
Base System |
Back to Front Airflow: ● 32x10 GE SFP+/SFP - WS-C4500X-F-32SFP+ |
|
Management Port |
10/100/1000 Base-T |
|
USB Port |
Type A (storage and boot) up-to 4 GB |
|
Dual Power Supply |
Yes |
|
Field Replaceable Fans |
Yes (5 fans) |
|
Fan Redundancy |
No performance impact with single fan failure |
|
Scalability |
|
|
System Throughput |
Up to 800 Gbps |
|
IPv4 Routing in Hardware |
Up to 250 Mpps |
|
IPv6 Routing in Hardware |
Up to 125 Mpps |
|
L2 Bridging in Hardware |
Up to 250 Mpps |
|
Media Access Control (MAC) Entries |
55K |
|
Forwarding Entries |
32x10 GE Port Base SKU: IPv4: 256K, IPv6: 128K |
|
Flexible Netflow Entries |
128K |
|
Switched Port Analyzer (SPAN), Remote Switched Port Analyzer (RSPAN) |
8 line rate bidirectional sessions (ingress and egress) |
|
Total VLANs |
4094 |
|
Total Switched Virtual Interfaces (SVIs) |
4094 |
|
IGMP groups |
32K |
|
Multicast routes |
32x10 GE Port Base SKU: IPv4: 32K, IPv6: 32K |
|
Dynamic Host Configuration Protocol (DHCP) Snooping Entries |
12K (DHCP snooping bindings) |
|
ARP Entries |
47K |
|
Spanning Tree Protocol Instances |
10K |
|
Jumbo Frame Support for Bridged and Routed Packets |
Up to 9216 bytes |
|
High Availability and Resiliency |
|
|
High Availability Solution |
Virtual Switching System (VSS) |
|
Number of stackable switches in VSS |
Up to 2 |
|
VSS Throughput |
Up to 1.6 Tbps |
|
Virtual Switch Link |
1GE or 10GE |
|
Max number of Virtual Switch Links |
8 |
|
In-Service Software Upgrade |
Across the switches |
|
Nonstop Forwarding with Stateful Switchover |
Across the switches |
|
CPU and Memory |
|
|
Onboard Memory (SRAM DDR-II) |
4 GB |
|
Port Buffers |
32-MB Shared Memory |
|
CPU |
Dual Core 1.5 GHz |
|
NVRAM |
2 GB |
|
Optional External Memory (SD Card) |
2 GB |
|
QoS Features |
|
|
Port Queues |
8 Queues/Port |
|
CPU Queues |
64 |
|
QoS Entries |
128K (64K ingress and 64K in egress) Shared with ACL |
|
Aggregate Rate-Limiting |
Ingress port or VLAN and egress VLAN or Layer 3 port |
|
Rate-Limiting Level Types |
Committed Information Rate (CIR), Peak Information Rate (PIR) |
|
Aggregate Traffic Rate-Limiting Policers (1K=1024) |
16K |
|
Flow-Based Rate-Limiting Method; Number of Rates |
Supported using flow-records in the classification criteria and policing action |
|
Qos Policy Enforcement |
Per Port or Per Vlan or Per Port, Per VLAN Granularity |
|
Class of Service (CoS) |
Yes |
|
Differentiated Services Code Point (DSCP) |
Yes |
|
Security Features |
|
|
Port Security |
Yes |
|
IEEE 802.1x and 802.1x Extensions |
Yes |
|
VLAN, Router, and Port ACLs |
Yes |
|
Security ACL Entries (1K=1024) |
128K (64K ingress and 64K in egress) Shared with QoS |
|
Unicast Reverse Path Forwarding (uRPF) Check in Hardware |
Yes |
|
CPU Rate Limiters (DoS Protection) Includes Control Plane Policing |
Yes |
|
Private VLANs |
Yes |
|
Micro Flow Policer |
Yes. Supported using flow records in the class-map |
|
CPU HW Rate Limiters by Packet Per Second (pps) and Bit Rate Policers (bps) |
Supported in hardware control-plane policing (CoPP) |
|
Control Plane Policing (CoPP) for Multicast |
Yes |
|
ACL Labels |
Yes |
|
Port ACL |
Yes |
|
Traffic Storm Control (formally known as Broadcast/Multicast Suppression) |
Yes |
|
Virtualization Features |
|
|
VRF-Lite Scalability |
64 |
|
Easy Virtual Network (EVN) Scalability |
32 |
|
Environmental Conditions |
|
|
Operating Temperature |
0°C to 40°C (RH to 90%) |
|
Storage Temperature |
-40°C to 70°C (RH 93%) |
|
Operating Altitude |
60m below sea level to 3000m above sea level |
|
Relative Humidity |
Nonoperating Humidity: 95% RH |
|
Acoustic Noise Measured per ISO 7779 and Declared per ISO 9296 Bystander Positions Operating to an Ambient Temperature of 25°C |
Industrial Product: 65 dBA maximum |
|
RoHS |
Reduction of Hazardous Substances (ROHS) 5 |
|
Power Supply |
|
|
AC Power Max Rating |
750W |
|
System Power Consumption |
330W nominal/400W max |
|
Input-Voltage Range and Frequency |
AC 100 to 240 VAC 50-60 Hz/DC -72 VDC to -40 VDC |
|
DC Power Max Rating |
750W |
|
AC to DC failover and vice versa |
Yes |
|
Total Output BTU (Note: 1000 BTU/hr = 293W) |
1122 BTU/hr (330 W) nominal/1365 BTU/hr (400 W) max |
|
Input Current |
AC 11A @ 110VAC, 6 A @ 200VAC/DC 25A Max |
|
Output Ratings |
12V @ 62A & 3.3V @ 3A |
|
Output Holdup Time |
AC = 16 ms; DC = 4 ms @ maximum load |
|
Power-Supply Input Receptacles |
AC IEC 60320 C15/DC Custom detachable screw terminal (supplied) |
|
Power Cord Rating |
AC 15A/DC 25A |
|
MTBF Information |
|
|
WS-C4500X-F-32SFP+ |
199,720 |
|
Regulatory Standards Compliance |
|
|
Regulatory Compliance |
CE marking |
|
EMI and EMC Compliance |
47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A CNS13438 Class A EN55024 CISPR24 EN300386 KN24 |
|
Safety Certifications |
UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition AS/NZS 60950-1 |
|
Industry EMC, Safety, and Environmental Standards |
GR-63-Core Network Equipment Building Systems (NEBS) Level 3 GR-1089-Core Level 3 |
