Cisco ASA 5545-K9 delivers superior performance with up to 3 Gbps stateful inspection throughput, 2500 IPsec VPN peers, 750,000 concurrent connections and 1 expansion slot makes it ideally suited for the mid-size, large-size enterprises, internet edge deployments or even data center while delivering enterprise-strength security.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
ASA5545-K9 |
|
Interfaces |
8 copper GE ports, 1 copper GE management port, 1 expansion slot |
|
Stateful inspection throughput (maximum) |
3 Gbps |
|
3DES/AES VPN throughput |
400 Mbps |
|
IPsec VPN peers |
2,500 |
|
Virtual interfaces (VLANs) |
300 |
|
Memory |
12 GB |
|
Flash |
8 GB |
|
Height (rack units) |
1 RU |
|
Dimensions (D x H x W) |
4.24 x 42.9 x 48.4 cm |
|
Package Weight |
17.17 Kg |
Product Details
Figure 1 shows the front panel of ASA5545-K9.
Table 2 shows the Front Panel LEDs’ descriptions.
|
LED |
Color |
Description |
|
BOOT |
Flashing green |
Power-up diagnostics are running, or system is booting. |
|
Solid green |
System has passed power-up diagnostics. |
|
|
Off |
Power-up diagnostics are not operational. |
|
|
ACTIVE |
Solid green |
Failover pair is operating normally. |
|
Off |
Failover is not operational. |
|
|
PS |
- |
Power supply status |
|
ALARM |
Off |
Normal operating system function. |
|
Solid amber |
Critical Alarm indicating one or more of the following: –a major failure of a hardware or software component. –an over-temperature condition. –power voltage is outside of the tolerance range. |
|
|
VPN |
Solid green |
VPN tunnel is established. |
|
Off |
No VPN tunnel established. |
|
|
HD0 |
Flashing green |
Proportioned to read/write activity. |
|
Solid amber |
Hard-disk drive failure. |
|
|
Off |
No hard-disk drive present. |
|
|
HD1 |
Flashing green |
Proportioned to read/write activity. |
|
Solid amber |
Hard-disk drive failure. |
|
|
Off |
No hard-disk drive present. |
Figure 2 shows the back panel of ASA5545-K9.
Note：
|
① |
LEDs |
⑤ |
AC Socket |
|
② |
One Console port |
⑥ |
one Management 0/0 interface |
|
③ |
Two USB Ports |
⑦ |
I/O slot |
|
④ |
Eight Gigabit Ethernet data interfaces |
|
· There are seven LEDs on the back panel: POWER, ALARM, BOOT, ACTIVE, VPN, HD0 and HD1.
Compare to Similar Items
Table 4 shows the comparison of ASA5515-K9, ASA5525-K9 and ASA5545-K9.
|
Models |
ASA5545-K9 |
||
|
Stateful Inspection Throughput (maximum) |
1.2 Gbps |
2 Gbps |
3 Gbps |
|
Next-generation firewall throughput (multiprotocol) |
350 Mbps |
650 Mbps |
1 Gbps |
|
Memory |
8GB |
8GB |
12GB |
|
Flash |
8GB |
8GB |
8GB |
|
Height (rack units) |
1 RU |
1 RU |
1RU |
Get more information
Do you have any question of ASA5545-K9?
Contact us now via Live Chat or [email protected].
ASA5545-K9 Specification
ASA5545-K9 Specification |
|
|
Stateful Inspection Throughput (Maximum) |
3 Gbps |
|
Stateful Inspection Throughput (Multiprotocol) |
1.5 Gbps |
|
IPS Throughput |
900 Mpbs |
|
Next-Generation Throughput(Multiprotocol) |
1 Gbps |
|
3DES/AES VPN Throughput |
400 Mbps |
|
Users/Nodes |
Unlimited |
|
IPsec VPN Peers |
2,500 |
|
Cisco Cloud Web Security Users |
5,000 |
|
Premium AnyConnect VPN Peers(Included/Maximum) |
2/2500 |
|
Concurrent Connections |
750,000 |
|
New Connections/Second |
30,000 |
|
Virtual Interfaces (VLANs) |
300 |
|
Security Contexts (Included/Maximum) |
2; 50 |
|
High Availability |
Active/Active and Active/Standby |
|
Expansion Slot |
1 interface card |
|
User-Accessible Flash Slot |
- |
|
USB 2.0 Ports |
2 |
|
Integrated I/O |
8 GE Copper |
|
Expansion I/O |
6 GE Copper or 6 GE SFP |
|
Serial Ports |
1 RJ-45 console |
|
Solid State Drive |
2 slot, RAID 1 120 GB MLC SED |
|
Memory |
12 GB |
|
Minimum System Flash |
8 GB |
|
System Bus |
Multibus architecture |
|
Temperature |
23 to 104°F (-5 to 40°C) |
|
Relative Humidity |
90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 10,000 ft (3050m) |
|
Shock |
50G, 2 m/sec |
|
Vibration |
0.41 Grms2 (3 to 500 Hz) random input |
|
Acoustic Noise |
64.2 dBa max |
|
Temperature |
-13 to 158ºF (-25 to 70ºC) |
|
Relative Humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4572m) |
|
Shock |
70G, 4.22 m/sec |
|
Vibration |
1.12 Grms2 (3 to 500 Hz) random input |
|
AC Range Line Voltage |
100 to 240 VAC |
|
AC Normal Line Voltage |
100 to 240 VAC |
|
AC Current |
4.85A |
|
AC Frequency |
50/60 Hz |
|
Dual-Power Supplies |
Yes |
|
DC Domestic Line Voltage |
-40.5 to 56 VDC (-48 VDC nominal) |
|
DC International Line Voltage |
-55 to -72 VDC (-60 VDC nominal) |
|
DC Current |
15A (maximum input) |
|
Steady State |
86W |
|
Maximum Peak |
125W |
|
Maximum Heat Dissipation |
427 BTU/hr |
|
Form Factor |
1 RU, 19-in. rack-mountable |
|
Dimensions (H x W x D) |
1.67 x 16.7 x 19.1 in. (4.24 x 42.9 x 48.4 cm) |
|
Weight (with AC Power Supply) |
16.82 lb (7.63 kg) with single power supply 18.86 lb (8.61 kg) with dual power supply |
|
Safety |
IEC 60950-1: 2005, 2nd Edition EN 60950-1:2006+A11: 2009 UL 60950-1:2007, 2nd Edition; CSA C22.2 No. 60950-1-07, 2nd Edition |
|
Electromagnetic Compatibility (EMC) |
CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000-3-3 2008; FCC: CFR 47, Part 15 Subpart B Class A 2010, ANSI C63.4 2009; ICES-003 ISSUE 4 FEBRUARY.2004; VCCI: V-3/2011.04; C-TICK: AS/NZS CISPR 22,2009 KC: KN22 & KN24 |
|
Industry Certifications |
In process |
