WS-C2960L-24PS-LL offering 24 x GigE PoE+ ports, 4 x 1G SFP and LAN Lite, is one of the Cisco Catalyst 2960-L Series Switches. These 2960-L switches are fixed-configuration, Gigabit Ethernet switches that provide entry-level enterprise-class Layer 2 access for branch offices, conventional workspaces, and out-of-wiring closet applications. Designed for operational simplicity to lower total cost of ownership, they enable secure and energy-efficient business operations with a range of Cisco IOS Software features. There is an Asia Pacific Part number: WS-C2960L-24PS-AP. It is the same as the WS-C2960L-24PS-LL.
Quick Specs
Figure 1 shows the appearance of WS-C2960L-24PS-LL.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C2960L-24PS-LL |
|
IOS |
LAN Lite |
|
Forwarding bandwidth |
28 Gbps |
|
Switching bandwidth |
56 Gbps |
|
10/100/1000 Ethernet Ports |
24 PoE+ Ports |
|
Available PoE Power |
195W |
|
Uplink Interfaces |
4 x 1G SFP |
|
Fanless |
Y |
|
DRAM |
512 MB |
|
Flash memory |
256 MB |
|
Dimensions (H x D x W) |
1.73 x 10.45 x 17.5 in. (4.4 x 26.5 x 44.5 cm) |
|
Net Weight |
7.63 lb (3.46 kg) |
Product Details
Figure 2 shows the front panel of WS-C2960L-24PS-LL.
Note:
|
① |
Mode button |
⑤ |
SFP module slots |
|
② |
USB mini-Type B (console) port |
⑥ |
USB Type A port |
|
③ |
RJ-45 Console Port |
⑦ |
System LEDs |
|
④ |
24 x 10/100/1000 PoE+ ports |
· There are a Security slot, Heat sink fins and an AC power connector on the back panel.
The Accessories
Table 2 shows the recommended elements for the WS-C2960L-24PS-LL.
|
Model |
Description |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
|
|
CAB-ACE= AC Power Cord (Europe), C13, CEE 7, 1.5M |
|
|
CAB-ACU= AC Power Cord (UK), C13, BS 1363, 2.5m |
Compare to Similar Items
Table 3 shows the comparison of WS-C2960L-24TS-LL and WS-C2960L-24PS-LL.
|
Model |
WS-C2960L-24PS-LL |
|
|
IOS |
LAN Lite |
LAN Lite |
|
Forwarding bandwidth |
28 Gbps |
28 Gbps |
|
Switching bandwidth |
56 Gbps |
56 Gbps |
|
10/100/1000 Ethernet Ports |
24 |
24 |
|
Available PoE Power |
N/A |
195W |
|
Uplink Interfaces |
4 x 1G SFP |
4 x 1G SFP |
Get more information
Do you have any question about the WS-C2960L-24PS-LL?
Contact us now via Live Chat or [email protected].
WS-C2960L-24PS-LL Specification
WS-C2960L-24PS-LL Specifications |
|
| Product Model | WS-C2960L-24PS-LL |
| Ports | 24 x Gigabit Ethernet ports |
| Power over Ethernet (PoE) | Yes (24 ports) |
| Device Type | Switch - 24 ports - Managed |
| Enclosure Type | Rack-mountable |
| PoE Budget |
195 W |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10240 bytes |
| Routing Protocol |
IGMP, MLDv2, MLD |
| Power | AC 120/230 V (50 - 60 Hz) |
| Maximum Transmission Unit (MTU) | 9198 bytes |
| Power Supply | Internal |
| Dimensions (WxDxH) | 44.5 cm x 26.5 cm x 4.4 cm |
| Software | Cisco IOS LAN Lite |
| QoS | Yes |
| Management | Web GUI, CLI, SNMP, RMON |
