CISCO887W-GN-A-K9 Specification

Product Number

CISCO887W-GN-A-K9

Description

Cisco 887 ADSL2/2+ Annex A Router with 802.11n FCC Compliant

Default and maximum flash memory

 128 MB

WAN

●  Fast Ethernet

●  Multimode VDSL2 and ADSl2/2+ over ISDN with ISDN backup

●  Multimode VDSL2 and ADSl2/2+ over basic telephone service

●  ADSL2/2+ over ISDN with ISDN backup

●  ADSL2/2+ over basic telephone service with ISDN backup

●  VDSL2 over basic telephone service with ISDN backup

●  Multimode G.SHDSL (2- and 4-wire support) with ISDN backup

●  Fast Ethernet and 3G WAN for Code Division Multiple Access (CDMA) and high-speed downlink packet access (HSDPA)

LAN switch

Managed 4-port 10/100BASE-T with autosensing Media Device In/Media Device Cross-Over (MDI/MDX) for auto crossover

Standard 802.11g/n access point based on IEEE 802.11n draft 2.0 standard

Optional on all models

Console or auxiliary port

RJ-45

One USB 1.1 port for advanced security features such as security tokens or USB flash memory

●  One USB 1.1 port on Cisco 880 Series Routers

●  USB devices supported:

●  USB eTokens

●  USB flash memory

External power supply

Universal 100 to 240 VAC input; 60W, 12 VDC output

Physical dimensions and weight

Product dimensions, wireless models (H x W x D):

●  1.9 x 12.8 x 10.4 in. (48 x 325 x 264 mm) (includes rubber feet)

●  1.75 x 12.8 x 10.4 in. (44 x 325 x 264 mm) (without rubber feet; excludes antennas)

●  Weight: 5.5 lb (2.5 kg) maximum

Power

Product power specifications:

●  AC input voltage: 100 to 240 VAC

●  Frequency: 50 to 60 Hz

●  Maximum output power: 60W

●  Output voltages: 12 VDC

Optional internal PoE with external adapter:

●  Maximum output power: 80W

●  External output voltage: 48 VDC

Approvals and compliance

Emissions:

●  47 CFR Part 15: 2006

●  CISPR22: 2005

●  EN300386: V1.3.3: 2005

●  EN55022: 2006

●  EN61000-3-2: 2000 [Inc amd 1 and 2]

●  EN61000-3-3: 1995 [+ amd 1: 2001]

●  ICES-003 Issue 4: 2004

●  KN 22: 2005

●  VCCI: V-3/2006.04

Immunity:

●  CISPR24: 1997 [+ amd 1 and 2]

●  EN300386: V1.3.3: 2005

●  EN50082-1: 1992

●  EN50082-1: 1997

●  EN55024: 1998 [+ amd 1 and 2]

●  EN61000-6-1: 2001

The following are supported on teleworker models:

●  AS/NRZ 3548: 1992 Class B

●  CFR 47 Part 15 Class B

●  EN60555-2 Class B

●  EN55022 Class B

●  ICES-003, Issue 2, Class B, April 1997S

Environmental operating range

●  Nonoperating temperature: -4 to 149°F (-20 to 65°C)

●  Nonoperating humidity: 5 to 95% relative humidity (noncondensing)

●  Nonoperating altitude: 0 to 15,000 ft (0 to 4570m)

●  Operating temperature

●  At sea level: 32 to 104°F (0 to 40°C)

●  Up 10,000 ft: 32 to 77°F (0 to 25°C)

●  Derating 2.7°F/10,000 ft (1.5°C/1,000 ft)

●  Operating humidity: 10 to 85% relative humidity (noncondensing)

●  Operating altitude: 0 to 10,000 ft (0 to 3000m)
