ITCS HPE ML350 Gen10 8SFF 877622-001

Sale Off

HPE ML350 Gen10 8SFF 877622-001

Brands: HPE

(0 reviews)

﷼ 21880.12 24311.25 10% Off

Model: 877622-001 - HPE Proliant ML350 Gen10 Server

Detail: <p style="margin-bottom: 0px;">HPE ProLiant ML350 Gen10 4114 2.2GHz 10-core 2P 32GB-R P408i-a 8SFF 2x800W RPS Perf Rack US Server</p>

Categories: Servers / HPE Tower Servers
Tags:

877622-001 is the HPE ML350 Gen10 4114 2P 32G 8SFF P408i-a 2x800W FS RPS Performance Rack Server. Driving a wide range of workloads with a flexible, shorter and rackable chassis design that can fit in different physical environments, the secure 2P HPE ProLiant ML350 Gen10 Server delivers the ideal set of performance and expandability for changing business needs making it the choice for growing SMBs, remote/branch offices of large enterprises and data centers.

Quick Spec

Table 1 shows the quick spec.

SKU	877622-001
Model Name	HPE ML350 Gen10 4114 2P 32G 8SFF P408i-a 2x800W FS RPS Performance Rack Server
Processor	4114 (10-Core, 2.2 GHz, 85W)
Number of Processors	Two processors
Memory	32 GB RDIMM SR 2600 MT/s (2x 16 GB)
Network Controller	Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter
Storage Controller	P408i-a
Hard Drive	None ship as standard
Internal Storage	8 SFF chassis with optional SFF HDD Cage Kit (874568-B21), upgradeable to 24 SFF. Opt. 8 SFF NVMe Express Bay Kit (874569-B21)
Form Factor	4U Tower

Product Details

Figure 1 shows the Front View – SFF chassis with optional Gen10 8SFF HDD Cage Kits shown (Rack mode), and Rear View – With HPE Flex Slot RPS shown.

Note (Front View):

①	iLO Service Port	⑦	Power On/Stand-by button and System Power LED
②	USB 3.0 port	⑧	Box1: optional HDD Drive Cage Bay for additional 8 SFF or 4 LFF drives support, or upgradeable to 2 HH media devices + 1 slim-line DVD.
③	USB 3.0 port	⑨	Serial number/iLO information pull tab
④	UID Button/LED	⑩	Box2: optional HDD Drive Cage Bay for additional 8 SFF or 4LFF drives support, or upgradeable to 8 SFF NVMe Express Bay
⑤	NIC Status LED	⑪	Box3: default with one 8 SFF HDD Drive Cage
⑥	System Health LED

Note (Back View):

①	HPE Flexible Slot 2 (Optional – empty with power supply blank shown)	⑧	Embedded 2 x 1GbE Network ports
②	Power supply Power connection	⑨	USB 3.0 port x 2
③	HPE Flexible Slot 1 Power Supply	⑩	PCI Slots (Slots 1-4) – Slot 1 and 3 can support Optional GPU
④	Display Port	⑪	Padlock eye
⑤	VGA Port	⑫	Serial Port
⑥	Dedicated iLO Management Port (RJ45)	⑬	PCI Slots (Slots 5-8) (requires Optional second processor) – Slot 5 and 7 can support Optional GPU
⑦	Embedded 2 x 1GbE Network ports

Options

Table 2 shows the recommended options.

Model	Description
815102-B21	HPE 128GB (1x128GB) Octal Rank x4 DDR4-2666 CAS-22-19-19 3DS Load Reduced Memory Kit
817738-B21	HPE Ethernet 10Gb 2-port 562T Adapter
875470-B21	HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
875509-B21	HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
875474-B21	HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
875511-B21	HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
835955-B21	HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit
815098-B21	HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit
815100-B21	HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit
815101-B21	HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Smart Memory Kit

Compare to Similar Item

Table 3 shows the comparison.

SKU	877621-001	877622-001
Model Name	HPE ML350 Gen10 4110 1P 16G 8SFF P408i-a 800W FS RPS Base Tower Server	HPE ML350 Gen10 4114 2P 32G 8SFF P408i-a 2x800W FS RPS Performance Rack Server
Processor	4110 (8-Core, 2.1 GHz, 85W)	4114 (10-Core, 2.2 GHz, 85W)
Number of Processors	One processor	Two processors
Memory	16 GB RDIMM SR 2600 MT/s (1x 16 GB)	32 GB RDIMM SR 2600 MT/s (2x 16 GB)
Network Controller	Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter	Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter
Storage Controller	P408i-a	P408i-a
Hard Drive	None ship as standard	None ship as standard
Internal Storage	8 SFF chassis with optional SFF HDD Cage Kit (874568-B21) to be selected. Upgradeable to 24 SFF max. Opt. 8 SFF NVMe Express Bay Kit (874569-B21)	8 SFF chassis with optional SFF HDD Cage Kit (874568-B21), upgradeable to 24 SFF. Opt. 8 SFF NVMe Express Bay Kit (874569-B21)

Get More Information

Do you have any question about the 877622-001?

HPE ML350 Gen10 8SFF 877622-001 Specification

877622-001 Specification
Model Name	HPE ML350 Gen10 4114 2P 32G 8SFF P408i-a 2x800W FS RPS Performance Rack Server
Processor	4114 (10-Core, 2.2 GHz, 85W)
Number of Processors	Two processors
Memory	32 GB RDIMM SR 2600 MT/s (2x 16 GB) NOTE: running at 2400 MT/s due to Processor limitation.
Network Controller	Embedded 4-Port 1GbE HPE Ethernet 1Gb 4-port 369i Adapter NOTE: embedded 4x1GbE HPE Ethernet 1Gb 4-port 369i Adapter does not support speeds of 100MB/s and 10MB/s.
Hard Drive	None ship as standard
Internal Storage	8 SFF chassis with optional SFF HDD Cage Kit (874568-B21), upgradeable to 24 SFF. Opt. 8 SFF NVMe Express Bay Kit (874569-B21)
Optical Drive Bay	Optional Slimline ODD Bay Kit (874577-B21) for SATA DVD-ROM/DVD-RW optical drive Optional Media Drive Support Kit (874570-B21) for RDX or tape/LTO devices, up to 2
Optical Drive	None ship as standard
PCI-Express Slots	8-slots (x16, x8, x16, x8, x16, x8, x16, x8) as standard
Power Supply	2x 800W HPE FlexSlot power supply (1+1)
Fans	6 standard fans
Management	HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses)
Energy Star	2.1 certified
Form Factor	5U Rack
