ASA5525-DC-K8 Specification

Product Number

ASA5525-DC-K8

Product Description

ASA 5525-X with SW. 8GE Data. 1GE Mgmt. DC. DES

Throughput:

Application Control (AVC)

1,100 Mbps

Throughput:

Application Control (AVC) and IPS

650 Mbps

Maximum concurrent sessions

500,000

Maximum New Connections per second

20,000

Supported applications

More than 3,000

URL categories

80+

Number of URLs categorized

More than 280 million

Centralized configuration, logging, monitoring, and reporting

Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center

On-Device Management

ASDM

Stateful inspection throughput (maximum)

2 Gbps

Stateful inspection throughput (multiprotocol)

1 Gbps

Triple Data Encryption Standard/
Advanced Encryption Standard (3DES/AES) VPN throughput

300 Mbps

Users/nodes

Unlimited

IPsec site-to-site VPN peers

750

Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections

750

Virtual interfaces (VLANs)

200

Security contexts(included; maximum)

2; 20

High availability

Active/Active and Active/Standby

Integrated Wireless Access Point

(See Cisco AP 702 datasheet for WiFi technical details)

N/A

Expansion slot

1 interface card

User-accessible Flash slot

0

USB 2.0 ports

2

Integrated I/O

8 GE copper

Expansion I/O

6 GE copper or

6 GE SFP

Dedicated management port

Yes (1 GE)

Serial ports

1 RJ-45 console

Solid-state drive

1 slot,

120 GB MLC SED

Memory

8 GB

System flash

8 GB

System bus

Multibus architecture

Temperature

23 to 104°F (-5 to 40°C)

Relative humidity

90 percent

Altitude

Designed and tested for 0 to 10,000 ft (3050 m)

Acoustic
noise

64.2 dBA max

Temperature

-13 to 158ºF (-25 to 70ºC)

Relative humidity

10 to 90 percent

Altitude

Designed and tested for 0 to 15,000 ft (4572 m)

AC range line voltage

100 to 240 VAC

AC normal line voltage

100 to 240 VAC

AC current

4.85A

AC frequency

50/60 Hz

Dual-power supplies

Yes

DC domestic line voltage

-40.5 to 56 VDC

(-48 VDC nominal)

DC international line voltage

-55 to -72 VDC

(-60 VDC nominal)

DC current

15A (maximum input)

Steady state

75W

Maximum
peak

108W

Maximum
heat dissipation

369 Btu/hr

Form factor

1RU, 19-in. rack-mountable

Dimensions(H x W x D)

1.75 x 17.5 x 14.25 in.(4.45 x 20.04 x 36.20 cm)

Weight (with AC power supply)

22.0 lb (10 kg)
