Feature

Cisco ASA 5512-X; Security Plus

Stateful Inspection Throughput (Maximum)

1 Gbps

Stateful Inspection Throughput (Multiprotocol)

500 Mbps

IPS Throughput

250 Mbps
(Extra hardware not required)

Next-Generation Throughput(Multiprotocol)

200 Mbps

3DES/AES VPN Throughput

200 Mbps

Users/Nodes

Unlimited

IPsec VPN Peers

250

Cisco Cloud Web Security Users

100

Premium AnyConnect VPN Peers(Included/Maximum)

2/250

Concurrent Connections

100,000

New Connections/Second

10,000

Virtual Interfaces (VLANs)

50; 100

Security Contexts (Included/Maximum)

0,0; 2,5

High Availability

Not supported; Active/Active and Active/Standby

Expansion Slot

1 interface card

User-Accessible Flash Slot

No

USB 2.0 Ports

2

Integrated I/O

6 GE Copper

Expansion I/O

6 GE Copper or 6 GE SFP

Serial Ports

1 RJ-45 console

Solid State Drive

1 slot, 120 GB MLC SED

Memory

4 GB

Minimum System Flash

4 GB

System Bus

Multibus architecture

Temperature

23 to 104°F (-5 to 40°C)

Relative Humidity

10 to 90 percent noncondensing

Altitude

Designed and tested for 0 to 15,000 ft (4572m)

Shock

70G, 4.22 m/sec

Vibration

0.41 Grms2 (3 to 500 Hz) random input

Acoustic Noise

64.2 dBa max

Temperature

-13 to 158ºF (-25 to 70ºC)

Relative Humidity

10 to 90 percent noncondensing

Altitude

Designed and tested for 0 to 15,000 ft (4570m)

Shock

70G, 4.22 m/sec

Vibration

1.12 Grms2 (3 to 500 Hz) random input

AC Range Line Voltage

100 to 240 VAC

AC Normal Line Voltage

100 to 240 VAC

AC Current

4.85A

AC Frequency

50/60 Hz

Dual-Power Supplies

None

DC Domestic Line Voltage

-40.5 to 56 VDC (-48 VDC nominal)

DC International Line Voltage

-55 to -72 VDC

(-60 VDC nominal)

DC Current

15A (maximum input)

Steady State

51W

Maximum Peak

56W

Maximum Heat Dissipation

192 BTU/hr

Form Factor

1 RU, 19-in. rack-mountable

Dimensions (H x W x D)

1.67 x 16.7 x 15.6 In (4.24 x 42.9 x 39.5 cm)

Weight (with AC Power Supply)

13.39 lb (6.07 kg)

Safety

IEC 60950-1: 2005, 2ndEdition
EN 60950-1:2006+A11: 2009
UL 60950-1:2007, 2ndEdition;
CSA C22.2 No. 60950-1-07, 2nd Edition

Electromagnetic Compatibility (EMC)

CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000-3-3 2008;
FCC: CFR 47, Part 15 Subpart B Class A 2010, ANSI C63.4 2009;
ICES-003 ISSUE 4 FEBRUARY.2004;
VCCI: V-3/2011.04;
C-TICK: AS/NZS CISPR 22,2009
KC: KN22 & KN24

Industry Certifications

In process
