Cisco Catalyst 2960 Compact 8 ports LAN Base switch supports easy deployment and reduces cabling costs. They help to extend services whenever and wherever you want.
Quick Specs
Figure 1 shows the appearance of WS-C2960C-8TC-L.
Table 1 shows the Quick Specs.
|
Product Code |
WS-C2960C-8TC-L |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x 1G copper or 2 x 1G SFP |
|
Ports |
8 x 10/100 Fast Ethernet |
|
Forwarding Bandwidth |
10 Gbps |
|
RAM |
128 MB |
|
Flash Memory |
64 MB |
|
Dimensions |
4.6cm x 26.9cm x 23.9cm |
|
Package Weight |
4.38 Kg |
Product Details
Figure 2 shows the front panel of WS-C2960C-8TC-L.
Note: ①Mode Button ②Mini USB Port ③ Console Port ④8 x 10/100 Fast Ethernet Ports ⑤ 2 x 1G copper or 2 x 1G SFP
Figure 3 shows the back panel of WS-C2960C-8TC-L.
Note: ①Power Connector
The Accessories
Table 2 shows some recommended cables and SFP modules.
|
Models |
Descriptions |
|
Cisco CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B |
|
|
Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F |
|
|
GLC-SX-MM GE SFP, LC connector SX transceiver |
|
|
1000BASE-LX/LH SFP for Both Multimode and Single-Mode Fibers |
|
|
1000BASE-BX SFP, 1490NM |
|
|
1000BASE-BX SFP, 1310NM |
|
|
100BASE-FX SFP for FE port |
|
|
100BASE-LX SFP for FE port |
|
|
100BASE-BX10-D SFP |
|
|
100BASE-BX10-U SFP |
Compare to similar item
Table 3 shows the comparison between WS-C2960C-8TC-S and WS-C2960C-8TC-L.
|
Models |
WS-C2960C-8TC-L |
|
|
Uplinks |
2 x 1G copper or 2 x 1G SFP |
2 x 1G copper or 2 x 1G SFP |
|
Ports |
8 x 10/100 Fast Ethernet |
8 x 10/100 Fast Ethernet |
|
Feature set |
LAN Lite |
LAN Base |
Get more information
Do you have any question about the WS-C2960C-8TC-L?
Contact us now via Live Chat or [email protected].
WS-C2960C-8TC-L Specification
WS-C2960C-8TC-L Specification |
|
|
Manufacturer: |
Cisco |
|
Product ID: |
WS-C2960C-8TC-L |
|
Product Description: |
2960C Switch 8 FE, 2 x Dual Purpose Uplink, LAN Base |
|
Product Type: |
Ethernet Switch |
| Marketing Information | |
|---|---|
|
The Cisco Catalyst 3560-C and 2960-C Series compact switches are small form-factor Gigabit Ethernet and Fast Ethernet switches designed for deployments outside the wiring closet. Enterprise and commercial customers can deliver advanced security services, unified communications, wireless, IP video cameras, and other applications for the office workspace, branch office, classroom, cruise ship, and other wiring-constrained environments. |
|
| Interfaces/Ports | |
|
Total Number of Network Ports: |
8 |
|
Token Ring Port: |
No |
|
LRE Port: |
No |
|
Uplink Port: |
No |
|
USB: |
Yes |
|
Number of RJ-45 Ports: |
8 |
| Media & Performance | |
|
Ethernet Technology: |
Gigabit Ethernet |
|
Network Technology: |
10/100/1000Base-T 10/100Base-TX |
| I/O Expansions | |
|
Number of Total Expansion Slots: |
2 |
|
Expansion Slot Type: |
SFP |
|
Shared SFP Slot: |
Yes |
|
Number of SFP Slots: |
2 |
| Network & Communication | |
|
Layer Supported: |
2 |
| Management & Protocols | |
|
Manageable: |
Yes |
|
Management: |
|
| Memory | |
|
Standard Memory: |
128 MB |
|
Memory Technology: |
DRAM |
|
Flash Memory: |
64 MB |
| Power Description | |
|
PoE (RJ-45) Port: |
Yes |
|
Input Voltage: |
110 V AC 220 V AC |
|
Power Source: |
Power Supply |
| Physical Characteristics | |
|
Form Factor: |
Rack-mountable Desktop Wall Mountable |
|
Height: |
1.8" (4.6 cm) |
|
Width: |
10.6" (26.9 cm) |
|
Depth: |
9.4" (23.9 cm) |
|
Weight (Approximate): |
4.10 lb (1.86 Kg) |
|
Package Weight:: |
9.66 lb (4.38 Kg) |
