HPE J4858C is a HP X121 1G SFP LC SX Transceiver. It’s a small form-factor pluggable (SFP) Gigabit SX transceiver that provides a full-duplex Gigabit solution up to 550 m on multimode fiber.
Quick Specs
This figure shows the appearance.
Table 1 shows the quick specs.
|
Product Number |
J4858C |
|
Type |
HP X121 1G SFP LC SX Transceiver |
|
Ports |
1 LC 1000Base-SX port (IEEE 802.3z Type 1000Base-SX), Duplex: full only |
|
Cabling distance (maximum) |
2-220 m (62.5 µm core diameter, 160 MHz*km bandwidth), 2-275 m (62.5 µm core diameter, 200 MHz*km bandwidth), 2-500 m (50 µm core diameter, 400 MHz*km bandwidth), 2-550 m (50 µm core diameter, 500 MHz*km bandwidth) |
|
Dimensions |
2.24 width x 0.54 depth x 0.486 in. height |
|
Weight |
0.04 lb. |
Compare to Similar Item
Table 2 shows the comparison.
|
Product Number |
J4858C |
|
|
Type |
HPE X111 100M SFP LC FX Transceiver |
HP X121 1G SFP LC SX Transceiver |
|
Ports |
1 LC 100BASE-FX port (IEEE 802.3u Type 100BASE-FX); Duplex: half or full |
1 LC 1000Base-SX port (IEEE 802.3z Type 1000Base-SX), Duplex: full only |
Get more information
Do you have any question about the J4858C?
Contact us now via Live Chat or [email protected].
J4858C Specification
J4858C Specifications |
|
|
Type |
HP X121 1G SFP LC SX Transceiver |
|
Ports |
1 LC 1000Base-SX port (IEEE 802.3z Type 1000Base-SX), Duplex: full only |
|
Cabling distance (maximum) |
2-220 m (62.5 µm core diameter, 160 MHz*km bandwidth), 2-275 m (62.5 µm core diameter, 200 MHz*km bandwidth), 2-500 m (50 µm core diameter, 400 MHz*km bandwidth), 2-550 m (50 µm core diameter, 500 MHz*km bandwidth) |
|
Dimensions |
2.24 width x 0.54 depth x 0.486 in. height |
|
Weight |
0.04 lb. |
