Huawei's next-generation NetEngine AR6000 series enterprise routers use high-performance multi-core processors and a nonblocking switching structure, helping to deliver higher forwarding performance than the industry average. The NetEngine AR6000 also integrates functions such as SD-WAN, routing, switching, VPN, security, and MPLS, ensuring diversified and cloud-based services are fully supported.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
AR6140-9G-2AC |
|
Processor |
4-Core |
|
Forwarding Performance (LAN - > WAN + WAN - > LAN,NAT + ACL + QoS,IMIX) |
2 Gbps |
|
IPsec performance (IMIX) |
2 Gbps |
|
Fixed WAN ports |
2 x GE RJ45 + 2 x GE SFP |
|
Fixed LAN ports |
2 x GE SFP + 3 x GE RJ45 (can be configured as WAN) |
|
SIC slots |
4 |
|
WSIC slots |
0 (default)/2 (maximum) |
|
XSIC slots |
\ |
|
USB port |
1 x USB3.0 (compatible with USB 2.0) |
|
Auxiliary or console port |
1 x RJ45 console port |
|
Memory |
2 GB |
|
Flash memory |
1 GB |
|
Hot swapping |
Supported |
Product Details
Figure 1 shows the front panel of Huawei AR6140-9G-2AC.
Note：
Figure
1. RESET button NOTE:This button is used to reset the router.
If needed, you can run the factory-configuration prohibit command in the system view to disable the function of restoring the factory settings by holding down the RESET button. To enable this function again, run the undo factory-configuration prohibit command. | 2. LAN interface: two GE electrical interfaces | 3. WAN interfaces: two GE electrical interfaces |
4. LAN interfaces: two GE optical interfaces | 5. WAN interfaces: two GE optical interfaces | 6. LAN interface: one GE electrical interface |
7. Console interface | 8. USB interface 3.0 (host) |
2 shows the back panel of Huawei AR6140-9G-2AC.
Note:
Compare to Similar Items
9. Ground point | ||
10. Product model silkscreen | 11. Four SIC slots | 12. Two AC power jacks |
Table 2 shows the comparison.
|
Product Code |
AR6140-9G-2AC |
|||
|
Processor |
4-Core |
4-Core |
16-Core |
16-Core |
|
Forwarding Performance (LAN - > WAN + WAN - > LAN, NAT + ACL + QoS, IMIX) |
2 Gbps |
2 Gbps |
SRU-400H: 10 Gbps SRU-600H: 12 Gbps
|
SRU-400H: 10 Gbps SRU-600H: 12 Gbps |
|
IPsec performance (IMIX) |
2 Gbps |
2 Gbps |
SRU-400H: 6 Gbps SRU-600H: 7.5 Gbps |
SRU-400H: 6 Gbps SRU-600H: 7.5 Gbps |
|
Fixed LAN ports |
8 x GE RJ45 (can be configured as WAN)
|
2 x GE SFP + 3 x GE RJ45 (can be configured as WAN) |
\ |
\ |
|
SIC slots |
2 |
4 |
4 |
4 |
|
WSIC slots |
0 (default)/1 (maximum) |
0 (default)/2 (maximum) |
2 (default)/4 (maximum) |
2 (default)/4 (maximum) |
|
XSIC slots |
\ |
\ |
2(default)/4 (maximum) |
4 (default)/6 (maximum) |
|
USB port
|
1 x USB 3.0 (compatible with USB 2.0) + 1 x USB 2.0 |
1 x USB3.0 (compatible with USB 2.0)
|
1*USB2.0
|
1*USB2.0
|
|
Auxiliary or console port |
1 x RJ45 console port |
1 x RJ45 console port |
1 x RJ45 console port |
1 x RJ45 console port |
|
Memory |
2 GB |
2 GB |
SRU-400H: 8 GB SRU-600H: 16 GB |
SRU-400H: 8 GB SRU-600H: 16 GB |
|
Flash memory |
1 GB/ 512MB |
1 GB |
SRU-400H: 2 GB SRU-600H: 4 GB |
SRU-400H: 2 GB SRU-600H: 4 GB |
|
Router dimensions, With no mounting bracket installed (H x W x D) |
44.5mm × 390mm × 232.5mm
|
44.5 mm x 442 mm x 420 mm
|
88.1 mm x 442 mm x 470 mm
|
130.5 mm x 442 mm x 470 mm |
|
Router dimensions, With mounting bracket installed (H x W x D)
|
44.5mm × 482.6mm × 232.5mm |
44.5 mm x 482.6 mm x 572.5 mm
|
88.1 mm x 482.6 mm x 470 mm
|
130.5 mm x 482.6 mm x 470 mm |
AR6140-9G-2AC Specification
AR6140-9G-2AC Specification |
|
|
System Parameters |
|
|
Processor |
4-Core |
|
Forwarding Performance (LAN - > WAN + WAN - > LAN,NAT + ACL + QoS,IMIX) |
2 Gbps |
|
IPsec performance (IMIX) |
2 Gbps |
|
Fixed WAN ports |
2 x GE RJ45 + 2 x GE SFP |
|
Fixed LAN ports |
2 x GE SFP + 3 x GE RJ45 (can be configured as WAN) |
|
SIC slots |
4 |
|
WSIC slots |
0 (default)/2 (maximum) |
|
XSIC slots |
\ |
|
USB port |
1 x USB3.0 (compatible with USB 2.0) |
|
Auxiliary or console port |
1 x RJ45 console port |
|
Memory |
2 GB |
|
Flash memory |
1 GB |
|
Hot swapping |
Supported |
|
Dimensions and Weight |
|
|
Router dimensions,With no mounting bracket installed (H x W x D) |
44.5 mm x 442 mm x 420 mm
|
|
Router dimensions,With mounting bracket installed (H x W x D) |
44.5 mm x 482.6 mm x 572.5 mm
|
|
Packaging dimensions (H x W x D) |
175 mm x 550 mm x 710 mm |
|
Rack |
IEC |
|
Occupied rack space |
1U |
|
Power Specifications, Power Consumption, and Heat Dissipation |
|
|
Rated input voltage range (AC) |
100 V to 240 V |
|
Rated input frequency (AC) |
50 Hz/60 Hz |
|
Maximum input voltage range (AC) |
90 V to 264 V |
|
Maximum input current (AC) |
3 A |
|
Maximum output power (AC) |
150W |
|
Power supply redundancy |
Support |
|
Typical power consumption |
18W |
|
Maximum power consumption |
32W |
|
Fan module |
Built-in unpluggable fan modules |
|
Airflow |
Left to right |
|
Noise level |
54 dB |
|
Environment Parameters |
|
|
Operating temperature |
0ºC to 45ºC |
|
Operating humidity |
5% to 95% (non-condensing) |
|
Operating altitude |
< 5000 m (16404.2 ft.) |
|
Storage temperature |
–40ºC to +70ºC |
|
Storage altitude |
< 5000 m (16404.2 ft.) |
|
Software Features and Protocols |
|
|
Basic function
|
DHCP server/client/relay, PPPoE server/client, NAT, and sub-interface management |
|
LAN |
IEEE 802.1P, IEEE 802.1Q, IEEE 802.3, VLAN management, VLAN aggregation, MAC management, STP |
|
WLAN (AC)
|
AP management (AC discovery, AP access, and AP management), CAPWAP, WLAN user management, WLAN radio management (802.11a/b/g/n/ac), WLAN QoS (WMM), WLAN security (WEP, WPA, WPA2, key management) |
|
IPv4 unicast routing |
Routing policies, static routes, RIP, OSPF, IS-IS, BGP |
|
IPv6 unicast routing
|
Static routes, routing policies, RIPng, OSPFv3, IS-ISv6, BGP4+ |
|
Basic IPv6 function
|
IPv6 ND, IPv6 PMTU, IPv6 FIB, IPv6 ACL, ICMPv6, DNSv6, DHCPv6 |
|
IPv6 tunneling |
Manual tunnel, automatic tunnel, GRE tunnel, IPv6 over IPv4 tunnel, 6 to 4 tunnel, ISATAP |
|
Multicast
|
IGMP v1/v2/v3, PIM-SM, PIM-DM, MSDP, MBGP, IPv6 PIM, MLD |
|
MPLS |
LDP, MPLS L3 VPN, VLL, PWE3, static LSP, dynamic LSP, MPLS TE, IP FRR, LDP FRR, TE FRR |
|
VPN |
IPsec VPN, GRE VPN, DSVPN, A2A VPN, L2TP VPN, L2TPv3 VPN |
|
QoS
|
DiffServ mode, MPLS QoS, priority mapping, traffic policing (CAR), traffic shaping, congestion avoidance, congestion management, MQC (traffic classifier, traffic behavior, and traffic policy), hierarchical QoS, Smart Application Control (SAC) |
|
Security
|
ACL (v4/v6), domain-based stateful firewall, 802.1X authentication, MAC address authentication,portal authentication, AAA authentication, RADIUS authentication, HWTACACS authentication, PKI,broadcast storm suppression, ARP security, ICMP attack defense, URPF, CPCAR, blacklist, attack source tracing, online behavior management, IPS, URL filtering |
|
Management and maintenance
|
Upgrade management, device management, web-based network management, GTL, SNMP (v1/v2c/v3), RMON, NTP, CWMP, Auto-Config, URL-based/USB-based/DHCP deployment, NETCONF/YANG, CLI, NetStream, IP FPM, TCP FPM, TWAMP, IP accounting, NQA |
|
Safety and Regulatory Standards |
|
|
EMC standards compliance |
CISPR32 Class A EN 55032 Class A CISPR24 EN 55024 ETSI EN 300 386 AS/NZS CISPR32 Class A FCC Part 15 Subpart B Class A ICES 003 Class A IEC 61000-3-2 EN 61000-3-2 IEC 61000-3-3 EN 61000-3-3 GB 9254 VCCI-CISPR32 Class A |
|
Environmental standards compliance |
RoHS REACH WEEE |
|
Safety standards compliance
|
IEC 60950-1 EN 60950-1 UL 60950-1 CSA C22.2 No 60950-1 GB 4943.1 |
