C1-CISCO1941/K9 is the CISCO1941/K9 with Cisco ONE Software. Cisco ONE Software suites provide a cost-effective and flexible way for you to acquire software for your data center, routing, switching, and wireless needs.
The Cisco 1941 Router, modular router, is designed for branch offices.
Quick Specs
Figure 1 shows the front view of Cisco Router 1941/K9.
Table 1 shows the Quick Specs of the C1-CISCO1941/K9.
|
Product Code |
C1-CISCO1941/K9 |
|
Rack Units |
2 RU |
|
Interfaces |
2 integrated 10/100/1000 Ethernet ports: GE0/0&GE0/1 |
|
Expansion Slot(s) |
2 enhanced High-Speed WAN Interface Card slots 1 Internal Services Module slot |
|
RAM |
512 MB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Dimensions |
34.3 cm x 29.2 cm x 8.9 cm |
|
Package Weight |
10.48 Kg |
Product Details
Figure 2 shows the statue LEDs, on the front panel of the 1941/K9, including three statues: SYS, ACT and PoE.
Table 2 shows the front panel LEDs area description.
|
LED |
Color |
Description |
|
SYS |
Solid green |
Solid green indicates normal operation. |
|
Blinking green |
System is booting or is in ROM monitor mode. |
|
|
Amber |
System error. |
|
|
Off |
Power is off or system board is faulty. |
|
|
ACT |
Green |
Solid or blinking when any packets are transmitted or received on any WAN or LAN, or when monitoring system activity. |
|
PoE |
Green |
PoE is available. |
|
Amber |
Power supply is not supplying PoE power. |
Figure 3 shows the back panel of this router with LEDs.
Note:
|
① |
Kensington security slot |
⑤ |
EN (Enable USB console) |
|
② |
CF 1 |
⑥ |
EN (Enable RJ-45 console) |
|
③ |
CF 0 |
⑦ |
S (Speed) |
|
④ |
ISM or WLAN |
⑧ |
L (Link) |
Table 3 shows the back panel LEDs area description.
|
LED |
Color |
Description |
Location |
|
CF 1 |
Green |
Flash memory is busy. |
Back Panel |
|
Amber |
Initialized with error. |
||
|
Blinking Green then turns off |
CompactFlash is ready for removal. |
||
|
CF 0 |
Green |
Flash memory is busy. |
Back Panel |
|
Amber |
Initialized with error. |
||
|
Blinking Green then turns off |
CompactFlash is ready for removal. |
||
|
S (Speed) |
1 blink + pause |
GE port operating at 10 Mb/s. |
Back Panel |
|
2 blink + pause |
GE port operating at 100 Mb/s. |
||
|
3 blink + pause |
GE port operating at 1000 Mb/s. |
||
|
L (Link) |
Green |
GE link is established. |
Back Panel |
|
Off |
No GE link is established. |
||
|
EN (RJ-45 console port) |
Green |
The RJ-45 console port is active. |
Back Panel |
|
EN (USB serial console port) |
Green |
The USB console port is active. |
Back Panel |
Figure 4 shows the ports and slots on the back panel of C1-CISCO1941/K9.
Note:
|
① |
On/Off switch |
⑦ |
Compact flash 2 |
|
② |
HWIC slot 1 |
⑧ |
HWIC slot 2 |
|
③ |
Input power connector |
⑨ |
USB serial port |
|
④ |
AUX port |
⑩ |
GE 0/1 |
|
⑤ |
GE 0/0 |
⑪ |
USB ports |
|
⑥ |
Compact flash 1 |
||
·Cisco 1941/K9 supports 2 integrated EHWIC slots for flexible configurations. It supports two modules: 1 double wide HWIC-D or single wide EHWIC/HWIC module or a 2nd single wide E-HIC/HWIC module.
·2 high-speed USB 2.0 ports enable another mechanism secure token capabilities and storage.
·The 1941 has 2 external Compact Flash slots supporting to extend up to 8GB.
Figure 5 shows the internal view of the Cisco 1941.
There is a blank Memory slot inside the device, supporting to extend memory.
Modularity Features
The Cisco 1941 provides significantly enhanced modular capabilities offering investment protection for customers.
Table 4 shows interfaces and modules for this router.
|
Models |
Description |
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
HWIC two routed port Cisco Router High-Speed WAN Interface card |
|
|
1-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco Voice/WAN Card VWIC3-1MFT-T1/E1 |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-T1/E1 |
|
|
Cisco Voice&WAN T1/E1 interface moudle VWIC3-1MFT-G703 |
|
|
Cisco Voice/WAN Card VWIC3-2MFT-G703 |
Get more information
Do you have any question about the C1-CISCO1941/K9?
Contact us now via Live Chat or [email protected].
C1-CISCO1941/K9 Specification
C1-CISCO1941/K9 Specification |
|
|
Main Specs |
|
|
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
CISCO1941/K9 |
|
Product Type |
Router |
|
Form Factor |
External - modular - 2U |
|
Dimensions (WxDxH) |
34.3 cm x 29.2 cm x 8.9 cm |
|
Weight |
5.8 kg |
|
DRAM Memory |
512 MB (installed) / 2 GB (max) |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Network / Transport Protocol |
IPSec |
|
Remote Management Protocol |
SNMP, RMON |
|
Features |
Cisco IOS IP Base , firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED) |
|
Compliant Standards |
IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag |
|
Power |
AC 120/230 V ( 50/60 Hz |
|
Services and Slot Density |
|
|
Embedded hardware-based crypto acceleration (IPSec + SSL) |
Yes |
|
Total Onboard LAN 10/100/1000 |
2 |
|
RJ-45-Based Ports |
2 |
|
SFP-Based Ports |
0 |
|
SM Slots |
0 |
|
Double-Wide SM Slots |
0 |
|
EHWIC Slots |
2 |
|
Double-Wide EHWIC slots (use of a double-wide EHWIC slot will consume two EHWIC slots) |
1 |
|
ISM Slots |
1 (0 on the Cisco 1941W) |
|
Memory (DDR2 Error Correction Code [ECC] ECC DRAM) - Default |
512 MB |
|
Memory (DDR2 ECC DRAM) - Maximum |
2.0 GB |
|
Compact Flash (external) - Default |
slot 0: 256 MB slot 1: none |
|
Compact Flash (external) - Maximum |
slot 0: 4 GB slot 1: 4 GB |
|
External USB flash memory slots (Type A) |
2 |
|
USB Console Port (Type B) (up to 115.2 kbps) |
1 |
|
Serial Console Port (up to 115.2 kbps) |
1 |
|
Serial Auxiliary Port (up to 115.2 kbps |
1 |
|
Power Supply Options |
AC, POE |
|
Redundant Power Supply Support |
No |
|
Power Specifications |
|
|
AC Input Voltage |
100-240 V ~ |
|
AC Input Frequency |
47-63 Hz |
|
AC Input Current range AC Power Supply (Max) (Amps) |
1.5-0.6 |
|
AC Input Surge Current |
<50 A |
|
Typical Power (No Modules) |
35 W |
|
Maximum Power capacity with AC power supply |
110 W |
|
Maximum Power capacity with PoE power supply (platform only) |
110 W |
|
Maximum PoE device power capacity with PoE power supply |
80 W |
|
Physical Specifications |
|
|
Dimensions (H x W x D) |
3.5 in x 13.5 in x 11.5 in (34.3 cm x 29.2 cm x 8.9 cm) |
|
Rack Height |
2 RU |
|
Rack-mount 19in. (48.3 cm) EIA |
Included |
|
Wall-mount (refer to installation guide for approved orientation) |
Yes |
|
Package Weight |
23.1 lbs (10.48 Kg) |
|
Weight-with AC power supply (no modules) |
12 lbs(5.44 Kg) |
|
Weight-with POE power supply (no modules) |
12.8 lbs (5.8 Kg) |
|
Maximum Weight-Fully Configured |
14 lbs (6.35 Kg) |
|
Airflow |
Front to Side |
|
Environmental Specifications |
|
|
Operating Condition |
|
|
Temperature-5906 feet (1800 m) max. altitude |
0-40°C (32-104°F) |
|
Temperature-9843 feet (3000 m) max. altitude |
0-25°C (32-77°F) |
|
Altitude |
3000 m (10000 ft) |
|
Humidity |
10 to 85% RH |
|
Acoustic: Sound Pressure (Typ/Max) |
26/46 dBA |
|
Acoustic: Sound Power (Typ/Max) |
36/55 dBA |
|
Transportation/Storage Condition |
|
|
Temperature |
-40 - 70 oC (-40 - 158 oF) |
|
Humidity |
5 to 95%RH |
|
Altitude |
4570m (15000 ft) |
|
Regulatory Compliance |
|
|
Safety |
UL 60950-1 CAN/CSA C22.2 No. 60950-1 EN 60950-1 AS/NZS 60950-1 IEC 60950-1 |
|
EMC |
47 CFR, Part 15 ICES-003 Class A EN55022 Class A CISPR22 Class A AS/NZS 3548 Class A VCCI V-3 CNS 13438 EN 300-386 EN 61000 (Immunity) EN 55024, CISPR 24 EN50082-1 |
|
Telecom |
TIA/EIA/IS-968 CS-03 ANSI T1.101 ITU-T G.823, G.824 IEEE 802.3 RTTE Directive |
