Cisco ASA 5512-K9 delivers superior performance with up to 1 Gbps stateful inspection throughput, 250 IPsec VPN peers, 100,000 concurrent connections and 1 expansion slot makes it ideally suited for the small, mid-size enterprises or branch offices while delivering enterprise-strength security. ASA 5512-K9 needs Security PLus license to support Active/Active and Active/Standby.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
ASA5512-K9 |
|
Interfaces |
6 copper GE ports, 1 copper GE management port, 1 expansion slot |
|
Stateful inspection throughput (maximum) |
1 Gbps |
|
3DES/AES VPN throughput |
200 Mbps |
|
IPsec VPN peers |
250 |
|
Virtual interfaces (VLANs) |
50; 100 |
|
Memory |
4 GB |
|
Flash |
4 GB |
|
Height (rack units) |
1 RU |
|
Dimensions (D x H x W) |
4.24 x 42.9 x 39.5 cm |
|
Package Weight |
13.1 Kg |
Product Details
Figure 1 shows the front panel of ASA5512-K9.
Table 2 shows the Front Panel LEDs’ descriptions.
|
LED |
Color |
Description |
|
BOOT |
Flashing green |
Power-up diagnostics are running, or system is booting. |
|
Solid green |
System has passed power-up diagnostics. |
|
|
Off |
Power-up diagnostics are not operational. |
|
|
ACTIVE |
Solid green |
Failover pair is operating normally. |
|
Off |
Failover is not operational. |
|
|
PS |
- |
Power supply status |
|
ALARM |
Off |
Normal operating system function. |
|
Solid amber |
Critical Alarm indicating one or more of the following: –a major failure of a hardware or software component. –an over-temperature condition. –power voltage is outside of the tolerance range. |
|
|
VPN |
Solid green |
VPN tunnel is established. |
|
Off |
No VPN tunnel established. |
|
|
HD |
Flashing green |
Proportioned to read/write activity. |
|
Solid amber |
Hard-disk drive failure. |
|
|
Off |
No hard-disk drive present. |
Figure 2 shows the back panel of ASA5512-K9.
Note：
|
① |
LEDs |
④ |
six Gigabit Ethernet data interfaces |
|
② |
One Console port |
⑤ |
AC Socket |
|
③ |
two USB Ports |
⑥ |
one Management 0/0 interface |
· There are six LEDs on the back panel: POWER, ALARM, BOOT, ACTIVE, VPN, and HD.
Compare to Similar Items
Table 4 shows the comparison of ASA5512-K9, ASA5515-K9 and ASA5525-K9.
|
Models |
ASA5512-K9 |
||
|
Stateful Inspection Throughput (maximum) |
1 Gbps |
1.2 Gbps |
2 Gbps |
|
Next-generation firewall throughput (multiprotocol) |
200 Mbps |
350 Mbps |
650 Mbps |
|
Memory |
4GB |
8GB |
8GB |
|
Flash |
4GB |
8GB |
8GB |
|
Height (rack units) |
Desk Top |
1 RU |
1 RU |
Get more information
Do you have any question of ASA5512-K9?
Contact us now via Live Chat or [email protected].
ASA5512-K9 Specification
ASA5512-K9 Specifications |
|
|
Feature |
Cisco ASA 5512-X; Security Plus |
|
Stateful Inspection Throughput (Maximum) |
1 Gbps |
|
Stateful Inspection Throughput (Multiprotocol) |
500 Mbps |
|
IPS Throughput |
250 Mbps(Extra hardware not required) |
|
Next-Generation Throughput(Multiprotocol) |
200 Mbps |
|
3DES/AES VPN Throughput |
200 Mbps |
|
Users/Nodes |
Unlimited |
|
IPsec VPN Peers |
250 |
|
Cisco Cloud Web Security Users |
100 |
|
Premium AnyConnect VPN Peers(Included/Maximum) |
2/250 |
|
Concurrent Connections |
100,000 |
|
New Connections/Second |
10,000 |
|
Virtual Interfaces (VLANs) |
50; 100 |
|
Security Contexts (Included/Maximum) |
0,0; 2,5 |
|
High Availability |
Not supported; Active/Active and Active/Standby |
|
Expansion Slot |
1 interface card |
|
User-Accessible Flash Slot |
No |
|
USB 2.0 Ports |
2 |
|
Integrated I/O |
6 GE Copper |
|
Expansion I/O |
6 GE Copper or 6 GE SFP |
|
Serial Ports |
1 RJ-45 console |
|
Solid State Drive |
1 slot, 120 GB MLC SED |
|
Memory |
4 GB |
|
Minimum System Flash |
4 GB |
|
System Bus |
Multibus architecture |
|
Temperature |
23 to 104°F (-5 to 40°C) |
|
Relative Humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4572m) |
|
Shock |
70G, 4.22 m/sec |
|
Vibration |
0.41 Grms2 (3 to 500 Hz) random input |
|
Acoustic Noise |
64.2 dBa max |
|
Temperature |
-13 to 158ºF (-25 to 70ºC) |
|
Relative Humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4570m) |
|
Shock |
70G, 4.22 m/sec |
|
Vibration |
1.12 Grms2 (3 to 500 Hz) random input |
|
AC Range Line Voltage |
100 to 240 VAC |
|
AC Normal Line Voltage |
100 to 240 VAC |
|
AC Current |
4.85A |
|
AC Frequency |
50/60 Hz |
|
Dual-Power Supplies |
None |
|
DC Domestic Line Voltage |
-40.5 to 56 VDC (-48 VDC nominal) |
|
DC International Line Voltage |
-55 to -72 VDC (-60 VDC nominal) |
|
DC Current |
15A (maximum input) |
|
Steady State |
51W |
|
Maximum Peak |
56W |
|
Maximum Heat Dissipation |
192 BTU/hr |
|
Form Factor |
1 RU, 19-in. rack-mountable |
|
Dimensions (H x W x D) |
1.67 x 16.7 x 15.6 In (4.24 x 42.9 x 39.5 cm) |
|
Weight (with AC Power Supply) |
13.39 lb (6.07 kg) |
|
Safety |
IEC 60950-1: 2005, 2nd <Edition |
|
Electromagnetic Compatibility (EMC) |
CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000-3-3 2008; |
|
Industry Certifications |
In process |
