The AR530 series handles a wider temperature range, a fanless design and provides Ingress Protection 51 (IP51). With these key technologies, the AR530 is high- and low-temperature resistant, dustproof, waterproof, and can resist electro-magnetic interference.
Quick Spec
Table 1 shows the Quick Specs.
|
Product Code |
AR532 |
|
Fixed Interface |
RS485*2 |
|
Other interface |
1 Pulse out,1 Infrared, 6 Operation Keys, WLAN(Management Interface) |
|
USB 2.0 |
1 |
|
Fixed Ethernet Interface |
RS232, RS485*2 |
|
Other interface |
infrared |
|
Serial Console Interface |
1 |
|
Memory |
256 MB |
|
Flash |
512 MB |
|
Maximum Power |
12.5 W |
Product Details
Huawei AR532 provides these features:
• Applications Integrated in One Device, Reducing Total Cost of Operation
* Integrates routing and data collection functions and provides various types of interfaces, such as FE, GE, 3G, PLC, RF and RS485.
* Switching and Smart Ethernet Protection (SEP), implementing millisecond-level protection switch-over.
* Has a built-in, zone-based firewall, ensuring production security
• Better Experience with Zero Service Interruption
* Complies with substation environment standard IEC61850-3/IEEE1613.
* Provides IP51 and is dustproof and waterproof.
* Uses a fanless design and works in a wide temperature range.
* Works normally in environments that have strong electro-magnetic interference.
* Huawei PLC-IoT with multi-carrier modulation of Orthogonal Frequency Division Multiplexing (OFDM), allowing Megabit-level transmission rate.
• Open Interface to Improve IoT Applications Integration
* Open protocol standards: Complies with IEC 62056 (DLMS/COSEM), Modbus, and inter-operates easily with other devices.
* Flexible configuration and management: flexibility to configure data collection services of IoT terminals to meet customized user requirements.
AR532 Specification
AR532 Specification |
|
|
Industrial Communication Protocol |
IEC62056 |
|
Uplink: 3G/GPRS
|
1* MiniSIM, SMA Interface, Support WCDMA/HSDPA/HSUPA/HSPA+: Band 1, Band 8 GSM/GPRS/EDGE: 850 MHz/900 MHz/1800 MHz/1900 MHz |
|
Fixed Ethernet Interface |
1* GE/1*GE Combo |
|
Downlink: PLC/RF |
Huawei PLC-IoT/433M/915M RF (Optional) |
|
DI/DO Interface |
2-channel DI/2-channel DO |
|
Fixed Interface |
RS485*2 |
|
Other interface |
1 Pulse out,1 Infrared, 6 Operation Keys, WLAN(Management Interface) |
|
USB 2.0 |
1 |
|
Fixed Ethernet Interface |
RS232, RS485*2 |
|
Other interface |
infrared |
|
Serial Console Interface |
1 |
|
Memory |
256 MB |
|
Flash |
512 MB |
|
Maximum Power |
12.5 W |
|
Power Supply |
Rated input voltage range: Single-phase: 100 V to 240 V AC, Three-phase: 173 V to 415 V AC |
|
Power Frequency |
50/60 Hz |
|
Dimensions (H x W x D) |
290 mm x 180 mm x 95 mm (11.42 in. x 7.09 in. x 3.74 in.) |
|
Weight |
2.5kg |
|
Installation Method |
Wall-mounted, DIN rail mount |
|
Operating Temperature |
-25℃ to +70℃ |
|
Storage Temperature |
-40℃to +85℃ |
|
Relative Humidity |
5% RH to 95% RH (non-condensing) |
|
Protection Level |
IP51 (IP54 with outdoor cabinet) |
|
AMI Service |
Modbus |
|
LAN
|
Meter Reading, 3G/RF/Huawei PLC-IoT Communication management, Monitoring and maintenance, Version management, Fault management, Time-synchronization of meter clock |
