N9K-C92160YC-X is one of the Cisco Nexus 9200 switches. 92160YC-X Switch is optimized for Cisco NX-OS deployments. It provides 48 1/10/25-Gb host ports and up to six hybrid uplink ports that can be configured as 10, 25, 40, or 100-Gb ports. With 3.2 Tbps of switching capacity, the 92160YC-X delivers line-rate Layer 2 and 3 features for demanding enterprise, service provider hosting, and cloud computing environments.
Quick Spec
Table 1 shows the quick spec.
|
Part Number |
N9K-C92160YC-X |
|
Ports |
48 x 10- and 25-Gbps SFP+ and 6 QSFP+ ports (4 are 100-Gbps capable) |
|
Supported speeds |
1, 10, and 25 Gbps on SFP+ ports 10, 25, 40, and 100 Gbps on QSFP+ ports |
|
Port configuration |
48 x 10/25-Gbps ports for downlinks; 4 of the 6 uplink ports are 100-Gbps capable. Ports 50 and 52 can be individually configured into 1 x 100 Gbps, 4 x 10 Gbps, 4 x 25 Gbps, 1 x 40 Gbps, or 2 x 50 Gbps |
|
CPU |
2 cores |
|
System memory |
16G |
|
SSD drive |
24G |
|
Shared system buffer |
20MB |
|
Management ports |
2 ports: 1 RJ-45 and 1SFP |
|
USB ports |
1 |
|
RS-232 serial ports |
1 |
|
Power supplies (up to 2) |
650W AC, 930W DC, or 1200W AC/HVDC |
|
Physical dimensions (H x W x D) |
1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm) |
|
Weight (without power supplies or fans) |
14.12 lb (6.4 kg) |
Product Details
Figure 1 shows the front panel of N9K-C92160YC-X.
Note:
|
① |
10-Gigabit SFP+ downlink ports (48) supporting 1-, 10-, and 25-Gigabit Ethernet |
|
② |
100-Gigabit QSFP28 uplink ports (6) supporting 40- and 100-Gigabit Ethernet |
Figure 2 shows the back panel of N9K-C92160YC-X.
Note:
|
① |
Power Supply |
⑤ |
Chassis LEDs (Beacon [BCN] and Status [STS]) |
|
② |
4 x Fan Module |
⑥ |
USB port used for saving or copying functions |
|
③ |
Power Supply |
⑦ |
Out-of-band management port (SFP port) |
|
④ |
Out-of-band management port (RJ-45 port) |
⑧ |
Console port (RS232 port) |
Compare to Similar Item
Table 2 shows the comparison.
|
Part Number |
N9K-C92160YC-X |
|
|
Ports |
48 x 10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports |
48 x 10- and 25-Gbps SFP+ and 6 QSFP+ ports (4 are 100-Gbps capable) |
|
CPU |
4 cores |
2 cores |
|
System memory |
24 GB |
16G |
|
SSD drive |
64 GB |
24G |
Get more information
Do you have any question about the N9K-C92160YC-X?
Contact us now via Live Chat or [email protected].
N9K-C92160YC-X Specification
N9K-C92160YC-X Specification |
|
|
Ports |
48 x 10- and 25-Gbps SFP+ and 6 QSFP+ ports (4 are 100-Gbps capable) |
|
Supported speeds |
1, 10, and 25 Gbps on SFP+ ports 10, 25, 40, and 100 Gbps on QSFP+ ports |
|
Port configuration |
48 x 10/25-Gbps ports for downlinks; 4 of the 6 uplink ports are 100-Gbps capable. Ports 50 and 52 can be individually configured into 1 x 100 Gbps, 4 x 10 Gbps, 4 x 25 Gbps, 1 x 40 Gbps, or 2 x 50 Gbps |
|
CPU |
2 cores |
|
System memory |
16G |
|
SSD drive |
24G |
|
Shared system buffer |
20MB |
|
Management ports |
2 ports: 1 RJ-45 and 1SFP |
|
USB ports |
1 |
|
RS-232 serial ports |
1 |
|
Power supplies (up to 2) |
650W AC, 930W DC, or 1200W AC/HVDC |
|
Typical power (AC) |
10-Gbps mode: 150W 25-Gbps mode: 170W |
|
Maximum power (AC) |
475W |
|
Input voltage (AC) |
100 to 240V |
|
Input voltage (HVAC) |
200 to 277V |
|
Input voltage (DC) |
–40 to –72V DC (minimum and maximum) –48 to –60V DC (nominal) |
|
Input voltage (HVDC) |
240 to 380V |
|
Frequency (AC) |
50 to 60 Hz |
|
Fans |
4 |
|
Airflow |
Port-side intake and exhaust |
|
MTBF (hours) |
379,400 |
|
Physical (H x W x D) |
1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm) |
|
Acoustics |
51.9 dBA at 40% fan speed, 56.2 dBA at 70% fan speed, and 66.0 dB at 100% fan speed |
|
RoHS compliance |
Yes |
|
Number of longest prefix match (LPM) routes |
Default: 6,000 LPM heavy mode: 650,000 |
|
Number of IP host entries |
Default: 96,000 LPM heavy mode: 650,000 |
|
Number of MAC address entries |
92,000 |
|
Number of multicast routes |
Shipping: 8,000 Maximum: 32,000 |
|
Number of Interior Gateway Management Protocol (IGMP) snooping groups |
Shipping: 8,000 Maximum: 32,000 |
|
Number of access control list (ACL) entries |
Per slice of the forwarding engine: 4,000 ingress 2,000 egress Maximum: 8,000 ingress 4,000 egress Shipping: 7,164 ingress 3,580 egress |
|
Maximum number of VLANs |
3,967 |
|
Number of Virtual Routing and Forwarding (VRF) instances |
Shipping: 1,000 Maximum: 16,000 |
|
Maximum number of links in a Port Channel |
32 |
|
Maximum number of ECMP paths |
64 |
|
Maximum number of ECMP groups |
256 |
|
Maximum number of ECMP members |
64,000 |
|
Maximum number of Port Channels |
512 |
|
Number of active SPAN sessions |
4 |
|
Number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances |
3,967 |
|
Number of Hot-Standby Router Protocol (HSRP) groups |
490 |
|
Number of Multiple Spanning Tree (MST) instances |
64 |
|
Maximum Number of VxLAN Tunnel Endpoints (VTEPs) |
256 |
|
Operating temperature |
32 to 104°F (0 to 40°C) |
|
Nonoperating (storage) temperature |
-40 to 158°F (-40 to 70°C) |
|
Humidity |
5 to 95% (noncondensing) |
|
Altitude |
0 to 13,123 ft (0 to 4000m) |
|
Weight (without power supplies or fans) |
14.12 lb (6.4 kg) |
