Huawei AntiDDoS8160-CHAS-DC AntiDDoS8160 Integrated Chassis Components with DC power supplies,32U includes 8 DC Power.
Quick Specs
Figure 1 shows the appearance of AntiDDoS8160-CHAS-DC.
Table 1 shows the Quick Specs.
|
Product Code |
AntiDDoS8160-CHAS-DC |
|
Part Number |
0235G787 |
|
Description |
Integrated Chassis Components,32U(Including 8 DC Power) |
|
Attributes |
Hardware |
|
List Price(USD) |
46,000.00 |
|
Category |
Hardware |
|
Product Line |
Networking |
|
Product Family |
Security |
|
Overview |
AntiDDoS8160 |
|
Sub Product Family |
Application Security |
|
Product Series |
AntiDDoS8160 |
|
UOM |
PCS |
|
Pack Weight(kg) |
197 |
|
Pack Volume(m^3) |
0.88 |
|
Pack Dimension (D*W*H mm) |
1520*585*990 |
|
Net Dimension (D*W*H mm) |
650*442*1420 |
|
Typic Power(W) |
128 |
Compare to Similar Items
Table 2 shows the comparison of AntiDDoS8030-CHAS-AC, AntiDDoS8030-CHAS-DC, AntiDDoS8080-CHAS-DC and AntiDDoS8160-CHAS-DC.
|
Product Code |
AntiDDoS8160-CHAS-DC |
|||
|
Part Number |
0235G789 |
0235G788 |
0235G786 |
0235G787 |
|
Description |
Integrated AC Chassis Components,5U |
Integrated DC Chassis Components,4U |
Integrated Chassis Components,14U(Including 4 DC Power) |
Integrated Chassis Components,32U(Including 8 DC Power) |
Get more information
Do you have any question about the AntiDDoS8160-CHAS-DC?
Contact us now via Live Chat or [email protected].
AntiDDoS8160-CHAS-DC Specification
AntiDDoS8160 Specifications |
|
|
Interfaces and performance |
|
|
Throughput |
Up to 1,440 Gbit/s |
|
Throughput/Slot |
Up to 160 Gbit/s |
|
Mitigation Rate/Slot |
Up to 60 Mpps |
|
Latency |
80 μs |
|
Expansion Slots |
16 |
|
Expansion LPU |
FW-LPUF-120, 2 sub-slots |
|
Expansion Interfaces |
24 x GE (SFP); 5 x 10 GE (SFP+); 6 x 10 GE (SFP+); 12 x 10 GE (SFP+); 1 x 40 GE (CFP); 1 x 100 GE (CFP) |
|
Dimensions |
|
|
Height x Width x Depth |
1,420 mm x 442 mm x 650 mm (32U) |
|
Weight |
94.4 kg (empty), 233.9 kg (full) |
|
Power and Environment |
|
|
Power Supply |
Rated input voltage: |
|
Power Consumption |
6 x FW-LPUF-240 + 9 x ADS-SPUD-B + 18 x ADS-SPC-80-01: |
|
Power Redundancy |
DC: 8 hot-swappable PEM modules |
|
Operating Temperature |
0°C to 45°C (long-term), -5°C to 50°C (short-term) |
|
Storage Temperature |
-40°C to 70°C |
|
Operating Humidity |
5% RH to 85% RH, non-condensing (long-term), 5% RH to 95% RH, non-condensing (short-term) |
|
Storage Humidity |
0% RH to 95% RH |
|
Certifications |
|
|
Safety Certifications |
Electro Magnetic Compatibility (EMC) certification |
