Cisco Catalyst WS-C3560X-48T-E is 48 Gigabit Ethernet ports standalone switch with four optional 1G/10G network uplink module and no option to stack in IP service feature set. IP service feature set provides up to 1005-Vlans and advanced layer 3 routing features, advanced security features and management features. WS-C3560X-48T-E is designed for enterprise distribution layer switching in full layer 3 capability includes BGP, EIGRP, OSFP, IPv4/v6, multicast routing, IPSLA, Netflow, advanced Qos, VRF-lite. WS-C3560X-48T-S switch comes with one default power supply module, customers can purchase additional power supply module insert into power supply bay 2 in order to power redundancy.
WS-C3560X-48T-E
Cisco Catalyst 3560-X Series Switch
- 48 * 10/100/1000 Gigabit Ethernet ports with optional uplink network modules
- Dual redundant, modular power supplies and fans
- IP service feature set with full Layer 3 routing features, VRF-lite, IPSLA, advanced QoS, PIM, Netflow, PBR
- 64MB flash and 256 memory (DRAM)
- USB Type-A and Type-B ports for storage and console respectively and an out-of-band Ethernet management port
Figure 1
Cisco Catalyst 3560-X Series Switches support 4 optional network modules for uplink ports (Figure 1);
The default switch configuration doesn't include the uplink module;
When purchasing switch, customers have flexibility to choose any group of network modules described below:
Product Number |
Product Description |
C3KX-NM-1G |
Four GbE port network module |
C3KX-NM-10G |
Two 10GbE SFP+ ports network module with four physical ports with two SFP+ and two regular SFP ports |
C3KX-NM-10GT |
Two 10GB-T ports network module |
C3KX-SM-10G |
Service Module with two 10GbE SFP+ ports network module for Netflow and MACsec encryption |
Figure 2
Dual Redundant Modular Power Supplies
Cisco Catalyst 3750-X Series and 3560-X Series Switches support dual redundant power supplies (Figure 2);
One power supply is shipped with the switch by default;
Other power supply/suppliers can be purchased when ordering the switch or next time according to your needs.
If only one power supply is installed, it should always be in the power supply bay 1.
Table below shows the different power supplies available in these switches and available PoE power.
Power Supply Models
Models |
Default Power Supply |
Available PoE Power |
24 Port Data Switch |
C3KX-PWR-350WAC |
- |
48 Port Data Switch |
||
24 Port PoE Switch |
C3KX-PWR-715WAC |
435W |
48 Port PoE Switch |
||
48 Port Full PoE Switch |
C3KX-PWR-1100WAC |
800W |
24 Port UPOE Switch |
C3KX-PWR-1100WAC |
800W |
48 Port UPOE Switch |
WS-C3560X-48T-E (USED) Specification
WS-C3560X-48T-E data sheet | |
---|---|
Manufacturer | Cisco Systems, Inc |
Manufacturer Part Number | WS-C3560X-48T-E |
Product Type | Switch - 48 ports - L3 - Managed |
Form Factor | Rack mountable - 1U |
Switch Ports | 48 x 10/100/1000 Ethernet Ports Ethernet Ports |
Routing Protocol | RIP-1, RIP-2, HSRP, VRRP, BLGP, OSPF, EIGRP, BGP, PIM |
Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI |
Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
Features | Hot swap module replacement, Layer 3 switching, Layer 2 switching, dynamic IP address assignment , DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), EIGR, OSPF, BGP, PIM |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae |
DRAM Memory | 256 MB |
Flash Memory | 64 MB Flash |
Status Indicators | Port status, link activity, port transmission speed, port duplex mode, power, system |
Connectivity Slots | |
Interfaces | 48 x 10Base-T/100Base-TX/1000Base-T - RJ-45 USB : 1 x 4 PIN USB Type A 1 x console - mini-USB Type B - management 1 x RS-232 - RJ-45 - management 1 x 10Base-T/100Base-TX - RJ-45 - management |
Expansion Slot(s) | 1 (total) / 1 (free) x Expansion Slot |
Power Supply | |
Power Device | Power supply - redundant - plug-in module |
Installed Qty | 1 (installed) / 2 (max) |
Power Redundancy | Optional |
Power Redundancy Scheme | 1+1 (with optional power supply) |
Voltage Required | AC 120/230 V ( 50/60 Hz ) |
Features | Redundant Power System (RPS) connector |
Dimensions / Weight / Miscellaneous | |
Width | 44.5 cm |
Depth | 46 cm |
Height | 4.5 cm |
Weight | 7.3 kg |
Rack Mounting Kit | Optional |
MTBF | 186,778 hour(s) |
Compliant Standards | CE, TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1 |
System Software | |
Software Included | Cisco IOS IP Service |
