AR1220E

Brands: Huawei

(0 reviews)

﷼ 6282.56 6980.62 10% Off

Model: Huawei Next Generation AR1200 Series Router AR1220E

Detail: AR1220E,2GE COMBO,8GE LAN,2 USB,2 SIC

Huawei AR1220E router is next-generation, enterprise-class routers based on the Huawei proprietary Versatile Routing Platform (VRP).

Figure 1 shows the appearance of Huawei Router - AR1220E.

Table 1 shows the Quick Specs.

Product Code	Huawei Router - AR1220E
Memory	1 GB
Flash	512 MB
Service interfaces (standard configuration)	WAN interfaces: 2 GE combo interfaces LAN interfaces: 8 10/100/1000M auto-sensing Ethernet electrical interfaces
Extended slots	2 SIC slots
Interface number	LAN interfaces: GE0-GE7
Power module type	Built-in AC power module
Weight	12.45 kg
Dimensions (W x D x H)	390.0 mm x 232.5 mm x 44.5 mm

Figure 2 shows the front panel of Huawei Router - AR1220E.

Note:

①	Two USB interfaces (host)
②	RST button

Figure 3 shows the back panel of Huawei Router - AR1220E.

Note:

Two GE combo interfaces

Console interface

Mini USB interface

Eight GE electrical interfaces

AC power jack

Two SIC slots

Table 2 shows the recommended elements for the Huawei Router - AR1220E.

Model	Description
FE optical transceiver
SFP-FE-LX-SM1310-BIDI	eSFP,FE,BIDI Single-mode module(TX1310/RX1550,15km,LC)
eSFP-FE-LX-SM1310	eSFP,100M/155M,Single-mode Module(1310nm,15km,LC)
S-SFP-FE-LH40-SM1310	eSFP,FE,Single-mode Module(1310nm,40km,LC)
GE optical transceiver
SFP-1000BaseT	Electrical Transceiver,eSFP,GE,Electrical Interface Module(100m,RJ45)
eSFP-GE-SX-MM850	Optical Transceiver,eSFP,GE,Multi-mode Module(850nm,0.55km,LC)
SFP-GE-LX-SM1310	Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,10km,LC)
S-SFP-GE-LH40-SM1310	Optical Transceiver,eSFP,GE,Single-mode Module(1310nm,40km,LC)
S-SFP-GE-LH40-SM1550	Optical Transceiver,eSFP,GE,Single-mode Module(1550nm,40km,LC)
WAN interface card
AR-1E3T3M-W	1-Port Channelized/Unchannelized E3/T3 WAN Interface Card
xDSL interface card
AR01SLV1XA	1-Port VDSL2 over POTS WAN Interface Module

Table 3 shows the comparison between AR1220E and AR0M12VWBA00.

Model	AR1220E	AR0M12VWBA00
WAN Speed with Services	400 Mbit/s	200 Mbit/s
Fixed WAN Ports	2 x GE Combo	2 x GE
Fixed LAN Ports	8 x GE (can be configured as WAN interfaces)	8 x FE (can be configured as WAN interfaces)
Slots	SIC slots: 2 WSIC slots (default/max): 0/1
Memory	1 GB	512 MB

AR1200E Specification
WAN speed with services	400 Mbit/s
Firewall Performance (large packet)	1,800 Mbit/s
Device Switching Capacity	8 Gbit/s
Slot Switching Bandwidth	SIC & WSIC slots: 2 Gbit/s
Number of Recommended Users	100
Fixed WAN Ports	2 x GE Combo
Fixed LAN Ports	8 x GE (can be configured as WAN interfaces)
SIC Slots	2
WSIC Slots (default/max)	0/1
DSP Slots	-
Wi-Fi	-
USB 2.0 Ports	2
Mini-USB Ports	1
Serial Auxiliary/Console Port	1
Memory	1 GB
Flash	512 MB
Max. Power	60W
PoE Power	-
AC Power	100V to 240V
Frequency	50 Hz/60 Hz
DC power	-
Dimensions (H x W x D)	44.5 mm x 390 mm x 220 mm
Weight	12.45 kg
Ambient Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
