The HPE Smart Array P408e-p SR Gen10 Controller, supporting 12Gb/s SAS and PCIe 3.0, is ideal for maximizing performance on externally attached drives while supporting advanced RAID levels with 4 GB flash-backed write cache (FBWC). This controller operates in Mixed Mode which combines RAID and HBA operations simultaneously. It has eight external SAS lanes, allowing connection to externally attached SAS or SATA drives, and provides enterprise-class storage performance, reliability, security and efficiency needed to address your evolving data storage needs. This controller offers enhanced security by encrypting data-at-rest on any drive with HPE Smart Array SR Secure Encryption.
The Gen10 controllers are supported by the HPE Smart Storage Battery, which supports multiple devices and is sold separately
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
804405-B21 |
|
Description |
Smart Array P408E-P SR GEN10 Controller |
|
Product Line |
Smart Array |
|
Product Model |
P408e-p |
|
Product Type |
SAS Controller |
|
Host Interface |
PCI Express 3.0 x8 |
|
Controller Type |
12Gb/s SAS Serial ATA/600 |
|
RAID Supported |
Yes |
|
RAID Levels |
0 1 5 6 10 50 60 1 ADM 10 ADM |
|
Data Backup Type |
Flash Backed Cache |
|
Number of SAS Ports (External) |
8 |
|
SAS Connector Details |
2 |
|
Cache Memory |
4 GB |
|
Form Factor |
Plug-in Card |
|
Manufacturer |
HPE |
Get more information
Do you have any question about the 804405-B21?
Contact us now via Live Chat or [email protected].
804405-B21 Specification
804405-B21 Specification | |
| General | |
| Product Type | Storage controller (RAID) |
| Bay Provided | |
| Type | None |
| Header | |
| Manufacturer | HP CTO Server Avnet |
| Packaged Quantity | 1 |
| Product Line | HPE Smart Array |
| Model | P408e-p SR Gen10 |
| Brand | HPE |
| Interface Provided | |
| Qty | 2 |
| Type | SATA 6Gb/s / SAS 12Gb/s |
| Miscellaneous | |
| Compliant Standards | FIPS 140-2 Level 1 |
| Features | Flash Backed Write-back Cache (FBWC) |
| Color Category | Green, Silver |
| Power Device | |
| Type | None |
| Storage Controller | |
| Form Factor | Plug-in card |
| Supported Devices | Disk array (RAID), Hard drive |
| RAID Level | RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60 |
| Data Transfer Rate | 1.2 GBps |
| Channel Qty | 8 |
| Buffer Size | 4 GB |
| Maximum LUNs | 64 |
| Host Bus | PCIe 3.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| System Requirements | |
| Min Operating System | CentOS, Citrix XenServer, ClearOS, Microsoft Windows Hyper-V Server, Microsoft Windows Server, Oracle Linux, Oracle Solaris, Red Hat Enterprise Linux, VMware vSphere (ESXi) |
