The Cloud Key Plus (UCK G2 Plus) is a compact, powerful UniFi OS Console with pre-installed UniFi Network and Protect applications and an upgradeable, 1 terabyte (TB) hard disk drive (HDD).
Quick Specs
Figure 1 shows the appearance of UCK-G2-Plus.
Table 1 shows the Quick Specs.
|
Product Code |
UCK-G2-Plus |
|
Management Interface |
UniFi Management Portal; UniFi SDN; UniFi Protect |
|
eMMC Memory |
32 GB |
|
Networking Interface |
(1) 10/100/1000 Ethernet Port |
|
Power Method |
Standard 802.3af PoE; Quick Charge 2.0/3.0 Power Adapter (9VDC, 2A) |
|
Dimensions |
131.16 x 27.10 x 134.20 mm (5.16 x 1.07 x 5.28") |
Product Details
Figure 2 shows the front panel of UCK-G2-Plus.
Figure 3 shows the back panel of UCK-G2-Plus.
UCK-G2-Plus provides these features:
- Compatible with the free UniFi Network and Protect applications
- Simple, Bluetooth-powered console setup via the Network and Protect mobile apps
- Powered by 802.3af PoE or QC 2.0 USB-C
- Built-in battery for automatic safe shutdown
- Pre-installed 2.5", 1 TB hard drive that can be upgraded to 5 TB
- Front panel display that helps you to review UniFi system details at a glance
- Allows you to easily scale your deployment by connecting additional UniFi devices
Compare to Similar Items
Table 2 shows the comparison of UCK-G2-Plus.
|
Module |
UCK-G2-Plus |
|
|
Management Interface |
UniFi Management Portal; UniFi SDN; UniFi Protect |
UniFi App; UniFi Network Interface |
|
eMMC Memory |
32 GB |
32 GB |
|
Networking Interface |
(1) 10/100/1000 Ethernet Port |
(1) 10/100/1000 Ethernet Port |
|
Power Method |
Standard 802.3af PoE; Quick Charge 2.0/3.0 Power Adapter (9VDC, 2A) |
Standard 802.3 af PoE, DC 5V 1A Powered |
|
Dimensions |
131.16 x 27.10 x 134.20 mm (5.16 x 1.07 x 5.28") |
27.10 x 46.80 x 119.75 mm (1.07 x 1.84 x 4.71”) |
Get More Information
Do you have any question about the UCK-G2-Plus?
Contact us now via Live Chat or [email protected].
UCK-G2-Plus Specification
UCK-G2-Plus Specification |
|
|
Dimensions |
131.16 x 27.10 x 134.20 mm (5.16 x 1.07 x 5.28") |
|
Enclosure |
Anodized Aluminum |
|
Management Interface |
UniFi Management Portal; UniFi SDN; UniFi Protect |
|
Hard Drive Capacity |
1 TB 2.5" SATA HDD (user-upgradeable) |
|
Device Capacity |
|
|
UniFi Protect Mode |
Up to 20 UniFi Cameras |
|
UniFi SDN + UniFi Protect |
Up to 15 UniFi Cameras and 50 UniFi Devices |
|
Processor |
APQ8053 8 Core with 3 GB RAM |
|
eMMC Memory |
32 GB |
|
Networking Interface |
(1) 10/100/1000 Ethernet Port |
|
Buttons |
(1) Power; (1) Reset |
|
LEDs |
(1) Power, White/Blue |
|
Power Method |
Standard 802.3af PoE; Quick Charge 2.0/3.0 Power Adapter (9VDC, 2A) |
|
Supported Voltage Range |
Standard 802.3af PoE or 9VDC, 2A |
|
Max. Power Consumption |
12.95W (PoE); USB-C Power |
|
Operating Temperature |
0 to 35° C (32 to 95° F) |
|
Operating Humidity |
20 to 80% Noncondensing |
