C2951-VSEC-SRE/K9 is the Cisco Router ISR G2 with SRE and Voice Security Bundle. Its Voice Security Bundle features is the same as C2951-VSEC/K9, but it’s bundled with SRE 700, PVDM3-32, UC, SEC Lic. PAK.
Quick Specs
Table 1 shows the Quick Specs of the C2951-VSEC-SRE/K9.
|
Product Code |
C2951-VSEC-SRE/K9 |
|
Bundle |
Cisco 2951 SRE Bundle, SRE 700, PVDM3-32, UC, SEC Lic. PAK |
|
Rack Units |
2U |
|
Interfaces |
3 integrated 10/100/1000 Ethernet ports with 1 port capable of RJ-45 or SFP connectivity |
|
Expansion Slot(s) |
2 service module slot 1 Internal Service Module slot 3 onboard digital signal processor slots 4 Enhanced high-speed WAN interface card (EHWIC) slots |
|
RAM |
512 MB (installed) / 2 GB (max) - DDR2 SDDRAM Memory |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Dimensions |
47 cm x 43.8 cm x 8.9 cm |
Product Details
Figure 1 shows the front panel of CISCO2951/K9. C2951-VSEC-SRE/K9 is similar with it.
Note:
|
① |
AC OK |
④ |
Optional RPS adapter(blank panel shown) |
|
② |
On/Off switch |
⑤ |
LEDs area |
|
③ |
AC power connector |
Figure 2 show the expansion slots and ports on the back panel.
Note:
|
① |
Compact flash 0 and 1 (0, right) |
⑦ |
10/100/1000 Ethernet port (GE 0/1 and GE 0/2) |
|
② |
EHWIC 0,1,2 and 3 (0, far right) |
⑧ |
10/100/1000 Ethernet port GE 0/0 |
|
③ |
USB serial port |
⑨ |
Ground |
|
④ |
RJ-45 serial console port |
⑩ |
USB 0 and 1 (1, top) |
|
⑤ |
AUX port |
⑪ |
Service module slots |
|
⑥ |
SFP |
Table 2. Summary of Features and Benefits of Cisco Services-Ready Engine
|
Key Features |
Key Benefits |
|
☆ Ability to host Cisco, third-party, and custom applications ☆ Small physical, energy, and carbon footprint ☆ High-performance, high-capacity hardware ☆ On-demand remote application provisioning ☆ Centralized management and troubleshooting |
☆ Consolidate and simplify branch-office infrastructure into one device ☆ Save on energy bills, hardware support contracts, and onsite visits ☆ Improve versatility and flexibility of branch-office infrastructure ☆ Quickly and cost-effectively adapt branch-office services and applications to evolving business needs |
Table 3 shows Cisco SRE Module Product Specifications. C2951-VSEC-SRE/K9 supports SRE 700.
|
Feature |
Cisco SRE 300 ISM |
Cisco SRE 700 and SRE 710 SMs |
Cisco SRE 900 and SRE 910 SMs |
|
Product part number |
ISM-SRE-300-K9 |
SM-SRE-700-K9 SM-SRE-710-K9 |
SM-SRE-900-K9 SM-SRE-910-K9 |
|
Form factor |
ISM |
SM |
SM |
|
CPU |
Genuine Intel Processor, 1.06 GHz |
Intel Core2 Solo, 1.86 GHz |
Intel Core2 Duo, 1.86 GHz |
|
DRAM |
512 MB |
4 GB |
4 GB (default) or 8 GB |
|
Compact Flash memory |
4-GB internal USB flash-memory module |
2-GB internal USB flash-memory module |
2-GB internal USB flash-memory module |
|
Hard disk |
None |
One 500-GB SATA 5400 rpm (SRE 700) 7200 rpm (SRE 710) |
Two 500-GB SATA (1 TB in non-RAID mode) 5400 rpm (SRE 900) 7200 rpm (SRE 910) |
|
Hot-swappable hard disk drive (HDD) |
None |
None |
Yes |
|
RAID support |
None |
None |
RAID 0 or 1 (application dependent) |
|
Internal network interfaces |
Gigabit Ethernet connectivity to router backplane |
Gigabit Ethernet connectivity to router backplane |
Gigabit Ethernet connectivity to router backplane |
|
External network interfaces |
None |
One USB connector One RJ-45 Gigabit Ethernet connector |
One USB connector One RJ-45 Gigabit Ethernet connector |
|
Router platforms |
Cisco 1941, 2901, 2911, 2921, 2951, 3925, and 3945 Integrated Services Routers |
Cisco 2911, 2921, 2951, 3925, 3925E, 3945, and 3945E Integrated Services Routers |
Cisco 2911, 2921, 2951, 3925, 3925E, 3945, and 3945E Integrated Services Routers |
|
Cisco IOS Software (on router) |
Release 15.0(1)M |
Release 15.1(4)M |
Release 15.1(4)M |
|
Embedded hardware-based cryptography acceleration |
No |
No |
Yes |
|
Supported Applications |
|||
|
Applications |
• Cisco Unity Express • Cisco Application Extension Platform (AXP) • Cisco Wireless LAN Controller (WLC) |
• Cisco Unity Express • Cisco UCS Express • Cisco AXP • Cisco WLC • Cisco Wide Area Application Services (WAAS) • Infoblox Core Network Services • Cisco Prime Network Analysis Module (NAM) • Cisco Unified SIP Proxy • Cisco Unified Messaging Gateway (UMG) • Cisco Survivable Remote Site Voicemail (SRSV) • Sagemcom Fax over IP • Tiani Spirit Medical Data Exchange Solution • Orion Health Rhapsody Connect • NetScout nGenius Integrated Agent • BlueCat Adonis DNS/DHCP and Proteus IPAM • LogLogic MX-Virtual Appliance • SecureLogix Voice Policy Firewall • Open Text RightFax Fax over IP • Visual Network Systems OmniPoint Element • Uplogix Local Management Platform • IndustryWeapon CommandCenterHD |
• Cisco Unity Express • Cisco UCS Express • Cisco AXP • Cisco WLC • Cisco WAAS • Cisco Video Surveillance • Infoblox Core Network Services • Cisco Prime Network Analysis Module (NAM) • Cisco Unified SIP Proxy • Cisco Unified Messaging Gateway (UMG) • Cisco Survivable Remote Site Voicemail (SRSV) • Sagemcom Fax over IP • Tiani Spirit Medical Data Exchange Solution • Orion Health Rhapsody Connect • NetScout nGenius Integrated Agent • BlueCat Adonis DNS/DHCP and Proteus IPAM • LogLogic MX-Virtual Appliance • SecureLogix Voice Policy Firewall • Open Text RightFax Fax over IP • Visual Network Systems OmniPoint Element • Uplogix Local Management Platform • Industry Weapon CommandCenterHD |
Modularity Features
Table 4 shows some recommended modules for this router.
|
Models |
Description |
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology |
|
|
2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
|
|
Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU |
|
|
Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers |
|
|
Internal Services Module (ISM) with Services Ready Engine |
|
|
256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR |
|
|
256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900 |
|
|
1GB USB Flash Token |
Compare to Similar Routers
Table 5 shows the comparison between CISCO2951/K9 and C2951-VSEC-SRE/K9.
|
Model |
C2951-VSEC-SRE/K9 |
|
|
Bundle |
N/A |
Cisco 2951 SRE Bundle, SRE 700, PVDM3-32, UC, SEC Lic. PAK |
|
Interface |
3GE |
3GE |
|
EHWIC slot |
4 |
4 |
|
SIM Slot |
2 |
2 |
|
SFP |
1 |
1 |
|
Memory |
512MB (installed) / 2 GB (max) |
512MB (installed) / 2 GB (max) |
|
Flash Memory |
512MB (installed) / 8 GB (max) |
512MB (installed) / 8 GB (max) |
|
Rack Unit |
2 U |
2 U |
Get more information
Do you have any question about the C2951-VSEC-SRE/K9 router?
C2951-VSEC-SRE/K9 Specification
C2951-VSEC-SRE/K9 Specifications |
|
|
Manufacturer |
Cisco Systems, Inc |
|
Manufacturer Part Number |
C2951-VSEC-SRE/K9 |
|
Product Type |
Router |
|
Bundle |
Cisco 2951 SRE Bundle, SRE 700, PVDM3-32, UC, SEC Lic. PAK |
|
Form Factor |
External - modular - 2U |
|
Dimensions (WxDxH) |
43.8 cm x 47 cm x 8.9 cm |
|
DRAM Memory |
512 MB (installed) / 2 GB (max) - DDR2 SDDRAM Memory |
|
Flash Memory |
256 MB (installed) / 8 GB (max) |
|
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
|
Network / Transport Protocol |
L2TP, IPSec, PPPoE, PPPoA |
|
Remote Management Protocol |
SNMP, RMON |
|
Digital Ports Qty |
32 |
|
Features |
Firewall protection, Layer 3 switching, Layer 2 switching, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN) |
|
Compliant Standards |
IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag |
|
Power |
AC 120/230 V ( 47 - 63 Hz ) |
