Aruba 7030 (RW) 64 AP Branch Controller
Aruba 7000 Series Mobility Controllers enhance WLAN performance by centralizing all control functionality for individual Aruba access points (APs) to improve AP utilization, security, and client roaming. Ideally suited for midsize
campuses and branches, the 7000 Series can be deployed using Zero Touch Provisioning (ZTP) to simplify deployment.
Product Details
Table 1 shows the performance and capacity of Aruba 7000 controllers.
|
Model |
7005 |
7008 |
7010 |
7024 |
7030 |
|
Maximum campus AP licenses |
16 |
16 |
32 |
32 |
64 |
|
Maximum remote AP licenses |
16 |
16 |
32 |
32 |
64 |
|
Maximum concurrent users/devices |
1,024 |
1,024 |
2,048 |
2,048 |
4,096 |
|
Maximum VLANs |
4,094 |
4,094 |
4,094 |
4,094 |
4,096 |
|
Active firewall sessions |
64k |
64k |
64k |
32768 |
64k |
|
Concurrent GRE tunnels |
256 |
256 |
512 |
512 |
1,024 |
|
Concurrent IPsec sessions |
512 |
512 |
1,024 |
1,024 |
2,048 |
|
Mobility Access Switch tunneled-node ports |
512 |
512 |
1,024 |
1,024 |
2,048 |
|
Firewall throughput |
2 Gbps |
2 Gbps |
4 Gbps |
4 Gbps |
8 Gbps |
|
Encrypted throughput (3DES, AES-CBC) |
1.2 Gbps |
1.2 Gbps |
2.4 Gbps |
2.4 Gbps |
2.4 Gbps |
|
Encrypted throughput (AES-CCM) |
1.6 Gbps |
1.6 Gbps |
3.4 Gbps |
3.4 Gbps |
4 Gbps |
Note: To order Aruba Access Points, please visit HPE Aruba 100 Series Access Points, HPE Aruba 200 Series Access Points, HPE Aruba 300 Series Access Points.
Quick Spec
Table 2 shows the quick spec.
|
Product Model |
Aruba 7030 (RW) 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clients Controller |
|
Maximum campus AP licenses |
64 |
|
Maximum remote AP licenses |
64 |
|
Maximum concurrent users/devices |
4096 |
|
Maximum VLANs |
4,096 |
|
Active firewall sessions |
64k |
|
Concurrent GRE tunnels |
1024 |
|
Concurrent IPsec sessions |
4096 |
|
Mobility Access Switch tunneled-node ports |
2048 |
|
Firewall throughput |
8 Gbps |
|
Encrypted throughput (3DES, AES-CBC) |
2.4 Gbps |
|
Encrypted throughput (AES-CCM) |
4 Gbps |
|
Form factor/footprint |
1 rack unit |
|
10/100/1000BASE-T |
8 (combo) |
|
USB 2.0 |
1 |
|
Management/status LEDs |
Yes (2) |
|
LINK/ACT and status LEDs |
Yes |
|
LCD panel and navigation buttons |
Yes |
|
Console port |
Yes (mini USB, RJ-45) |
|
Out-of-band management port |
No |
|
Dimension (H × W × D) |
4.4 cm x 30.5 cm x 21.1 cm |
|
MTBF (hours, @ 25C) |
390,679 |
|
Operating temperature |
0° C to 40° C |
|
Storage temperature |
-40° C to 70° C |
|
Humidity/storage humidity |
5% to 95%, NC |
|
Acoustic noise |
29.1 – 57.4 dBA |
|
Maximum power consumption |
55W |
Get more information
Do you have any question about the Aruba JW686A?
Contact us now via Live Chat or [email protected].
JW686A Specification
JW686A Specification |
|
|
Product Model |
Aruba 7030 (RW) 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clients Controller |
|
Maximum campus AP licenses |
64 |
|
Maximum remote AP licenses |
64 |
|
Maximum concurrent users/devices |
4096 |
|
Maximum VLANs |
4,096 |
|
Active firewall sessions |
64k |
|
Concurrent GRE tunnels |
1024 |
|
Concurrent IPsec sessions |
4096 |
|
Mobility Access Switch tunneled-node ports |
2048 |
|
Firewall throughput |
8 Gbps |
|
Encrypted throughput (3DES, AES-CBC) |
2.4 Gbps |
|
Encrypted throughput (AES-CCM) |
4 Gbps |
|
Form factor/footprint |
1 rack unit |
|
10/100/1000BASE-T |
8 (combo) |
|
USB 2.0 |
1 |
|
Management/status LEDs |
Yes (2) |
|
LINK/ACT and status LEDs |
Yes |
|
LCD panel and navigation buttons |
Yes |
|
Console port |
Yes (mini USB, RJ-45) |
|
Out-of-band management port |
No |
|
Dimension (H × W × D) |
4.4 cm x 30.5 cm x 21.1 cm |
|
MTBF (hours, @ 25C) |
390,679 |
|
Operating temperature |
0° C to 40° C |
|
Storage temperature |
-40° C to 70° C |
|
Humidity/storage humidity |
5% to 95%, NC |
|
Acoustic noise |
29.1 – 57.4 dBA |
|
Maximum power consumption |
55W |
|
Safety certifications |
UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition EN 60950:2005 IEC 60950-1 Second Edition NOM (obtained by partners and distributors) |
|
Electromagnetic emissions certifications |
FCC Part 15 Class B CE AS/NZS CISPR22 Class B CISPR22 Class A (7010, 7024, 7030), Class B (7005) EN55022 Class A (7010, 7024, 7030), Class B (7005) ICES-003 Class A (7010, 7024, 7030), Class B (7005) VCCI Class A (7010, 7024, 7030), Class B (7005) EN61000-3-2 EN61000-3-3 EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4- 6, EN 61000-4-8, EN 61000-4-11, AS/NZS 3548 KN22 Class B KCC CNS13438 Class B EN55024/CISPR24 KN24 Industry Canada Class B CE mark, cTUVus, CB, C-tick, Anatel, NOM, MIC |
|
Telco |
Common Language Equipment Identifier (CLEI) Code |
