The HPE ProLiant MicroServer Gen10 delivers an affordable compact entry level server specifically designed for small offices, home offices, or small business environments. This compact and easy to use server can be placed almost anywhere. Simple access to hard drives, memory and PCIe slots allow easy management, installation and upgrades. HPE MicroServer Gen10 is available with ClearOS Software from HPE delivering an intuitive Web based GUI and application marketplace that is pre-loaded on your hard drive, making it ready to use right out of the box. It utilizes the AMD accelerated processing unit (APU) with graphics cores embedded to improve graphic software performance without installing an additional PCIe graphics adapter.
Highlights
- The HPE ProLiant MicroServer Gen10 can be configured with ClearOS Software from HPE, an operating system with an intuitive Web based GUI and application marketplace that can be factory pre-loaded for your convenience.
- The HPE ProLiant MicroServer Gen10 is available with easy access to hard drives, memory, and PCIe slots for simple installation or upgrade.
- HPE ProLiant MicroServer Gen10 supports the AMD accelerated processing unit (APU) with the graphics core embedded to aid customers with graphics related workloads without installing an additional graphic card.
Quick Spec
Table 1 shows the quick spec.
| Type | Server |
| Product Form Factor | Ultra micro tower |
| Server Scalability | 1-way |
| Internal Bays Qty | 4 |
| Front Accessible Bays Qty | 1 |
| CPU | AMD Opteron X3216 / 1.6 GHz |
| Max Turbo Speed | 3 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Installed Size | L2 cache - 1 MB |
| Cache Per Processor | 1 MB |
| Technology | DDR4 SDRAM - ECC |
| Effective Memory Speed | 2400 MHz |
| Rated Memory Speed | 2400 MHz |
| Memory Specification Compliance | PC4-19200 |
| Form Factor | DIMM 288-pin |
| Slots | 2 (total) |
| Features | Unbuffered |
| Controller Interface Type | SATA 6Gb/s |
| Storage Controller Name | Marvell 88SE9230 |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Monitor Type | None. |
| Video Interfaces | VGA |
| Ethernet Ports | 2 x Gigabit Ethernet |
Compare to Similar Items
Table 2 shows the comparison to similar items of 873830-S01.
| Model | Description | Differences |
|---|---|---|
| 873643-L21 | HPE DL380 Gen10 Xeon-Bronze 3106 (1.7GHz/8-core/85W) FIO Processor Kit | Different server model and processor |
| 873643-B21 | HPE DL380 Gen10 Xeon-Bronze 3106 (1.7GHz/8-core/85W) Processor Kit | Different server model and processor |
| 870761-B21 | HPE 900GB SAS 12G Enterprise 15K LFF (3.5in) LPC 3yr Wty Digitally Signed | Different storage type and capacity |
Get More Information
Do you have any question about the 873830-S01?
Contact us now via Live Chat or [email protected].
873830-S01 Specification
| 873830-S01 Specification | |
| Type | Server |
| Product Form Factor | Ultra micro tower |
| Server Scalability | 1-way |
| Internal Bays Qty | 4 |
| Front Accessible Bays Qty | 1 |
| CPU | AMD Opteron X3216 / 1.6 GHz |
| Max Turbo Speed | 3 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Installed Size | L2 cache - 1 MB |
| Cache Per Processor | 1 MB |
| Technology | DDR4 SDRAM - ECC |
| Effective Memory Speed | 2400 MHz |
| Rated Memory Speed | 2400 MHz |
| Memory Specification Compliance | PC4-19200 |
| Form Factor | DIMM 288-pin |
| Slots | 2 (total) |
| Features | Unbuffered |
| Controller Interface Type | SATA 6Gb/s |
| Storage Controller Name | Marvell 88SE9230 |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Monitor Type | None. |
| Video Interfaces | VGA |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM5720 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Bays | 1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 4 (free) x internal 3.5" LFF |
| Interfaces | 1 x VGA ¦ 3 x USB 2.0 (2 rear, 1 internal) ¦ 2 x LAN (Gigabit Ethernet) ¦ 4 x USB 3.0 (2 front, 2 rear) |
| Compliant Standards | ICES-003, EN55024, EMC, FCC CFR47 Part 15, ACPI 5.0, GB 9254, CNS 13438, EN61000-3-2, EN61000-3-3, K24, CISPR 32, EN 55032 |
| Device Type | Power supply |
| Nominal Voltage | AC 120/230 V (50/60 Hz) |
| Power Provided | 200 Watt |
| OS Certified | Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, ClearOS |
| Service & Support | Limited warranty - parts and labor - 1 year - on-site |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Product Description | HPE ProLiant MicroServer Gen10 Entry - ultra micro tower - Opteron X3216 1.6 GHz - 8 GB |
| Processor | 1 x AMD Opteron X3216 / 1.6 GHz (3 GHz) (Dual-Core) |
| Cache Memory | 1 MB L2 cache |
| RAM | 8 GB (installed) / 32 GB (max) DDR4 SDRAM - ECC - PC4-19200 |
| Storage Controller | SATA (SATA 6Gb/s) (Marvell 88SE9230) |
| Server Storage Bays | Non-hot-swap |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Networking | GigE |
| Power | AC 120/230 V (50/60 Hz) |
| manufacturer | Hewlett Packard Enterprise |
| Configuration Features | 1 x 8 GB |
