The 865438-B21 HPE 800W FS Ti Ht Plg LH Pwr Sply Kit is a high-quality power supply kit designed for HPE servers. It provides a reliable and efficient power solution for data centers and server environments. With a power output of 800W, it can handle the demanding power requirements of modern server systems. The kit features a titanium efficiency rating, ensuring energy savings and reducing operating costs. It is compatible with various HPE server models and offers a hot-plug design for easy installation and maintenance.
Quick Spec
Table 1 shows the quick spec of 865438-B21.
| Parameter | Description |
|---|---|
| Model | 865438-B21 |
| Power Output | 800W |
| Efficiency | Titanium |
| Compatibility | HPE servers |
| Design | Hot-plug |
Product Features
- High-quality power supply kit for HPE servers
- 800W power output for demanding server systems
- Titanium efficiency rating for energy savings
- Compatible with various HPE server models
- Hot-plug design for easy installation and maintenance
Product Applications
- Data centers
- Server environments
- Enterprise IT infrastructure
Compare to Similar Items
Table 2 shows the comparison to similar items of 865438-B21.
| Model | Description | Differences |
|---|---|---|
| 865434-B21 | HPE 800W FS 48VDC Ht Plg LH Pwr Sply Kit | Different power source (AC vs. DC) |
| 865428-B21 | HPE 800W FS Univ Ht Plg LH Pwr Sply Kit | Different power source (AC vs. universal) |
| 864259-B21 | HPE 4TB SAS 7.2K LFF ST 512e Spl HDD | Different product category (power supply kit vs. hard drive) |
Get more information
Do you have any question about the 865438-B21?
Contact us now via Live Chat or [email protected].
865438-B21 Specification
865438-B21 Specification | |
| Dimensions & Weight | |
| Width | 2.7 in |
| Depth | 8.9 in |
| Height | 1.6 in |
| Weight | 32.1 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 3.5 lbs |
| Shipping Depth | 14.8 in |
| Shipping Height | 5.8 in |
| Shipping Width | 7.5 in |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| General | |
| Product Type | Power supply - hot-plug / redundant |
| Subcategory | Power supplies |
| Header | |
| Compatibility | PC |
| Manufacturer | HP CTO Server Avnet |
| Packaged Quantity | 1 |
| Product Line | HPE |
| Brand | HPE |
| Miscellaneous | |
| Compliant Standards | BSMI, C-Tick, CCC, CISPR Class A, cUL, KCC, Low halogen, TUV, UL, WEEE |
| Power Device | |
| Voltage Required | AC 200-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Provided | 800 Watt |
| Input Connector Type | Power IEC 60320 C14 |
| Form Factor | Plug-in module |
| Specification Compliance | Flex Slot |
| Power Capacity (VA) | 860 VA |
| Power Supply Compatibility | PC/Server |
| Efficiency | 96% |
| 80 PLUS Certification | 80 PLUS Titanium |
