The Aruba JL172A, part of the HPE OfficeConnect 1850 Series, is a high-performance, smart-managed switch designed for small businesses looking for key enhanced features in an easy-to-administer solution. This model, the 24G 2XGT PoE+ 185W Switch, combines versatile connectivity, high-speed networking, and advanced security features in a cost-effective, energy-efficient package to facilitate the deployment of wireless access points, VoIP phones, and surveillance cameras.
| Quick Spec | |
|---|---|
| Product Number | JL172A |
| Ports | 24 x Gigabit Ethernet, 2 x 10GbE SFP+ |
| Power Over Ethernet (PoE) | Yes, PoE+ (185W) |
| Throughput | 95.23 Mpps |
| Switching Capacity | 128 Gbps |
Product Features
- Smart-managed layer 2+ Ethernet switch with intuitive Web GUI for easy configuration.
- High-speed connectivity with 24 Gigabit Ethernet ports and 2 10GbE SFP+ uplinks.
- Support for PoE+ with a total power budget of 185W for deploying PoE devices effortlessly.
- Auto Voice VLAN for fast and reliable deployment of VoIP applications.
- Comprehensive security features, including IEEE 802.1X and VLANs, protect against unauthorized access.
Product Applications
- Small business networks requiring reliable, high-speed network access for desktops, laptops, and wireless access points.
- Offices deploying VoIP phones, requiring high power PoE+ ports to eliminate the need for additional power supplies.
- Surveillance system connectivity, leveraging PoE+ for high-power cameras without the need for extra power cables.
| Supported Options | |
|---|---|
| 10GbE SFP+ Transceiver | J9150D |
| Gigabit Ethernet SFP Transceiver | J4858C |
| Direct Attach Cable (DAC) | J9281B |
| Compare to Similar Items | |
|---|---|
| JL172A (This Product) | 24G, PoE+ 185W, 2x10GbE |
| JL169A | 24G, No PoE, 2x10GbE |
| JL170A | 48G, No PoE, 2x10GbE |
| JL071A | 8G, PoE+ 65W, No 10GbE |
To get more information and explore how the Aruba JL172A can fulfill your networking needs, don't hesitate to contact us through Live Chat or at [email protected]. Our team is ready to assist with your queries and provide detailed information about the product, including pricing and availability.
JL172A Specification
JL172A Specifications | |
| Brand | Aruba |
| Product Name | HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch |
| Model Number | JL172A |
| Total Number of Ports | 26 |
| RJ-45 Ports | 24 x Gigabit Ethernet Network |
| Uplink Ports | 2 x 10 Gigabit Ethernet Expansion Slot |
| Power Over Ethernet (PoE) Support | PoE+ |
| PoE Power Budget | 185W |
| Switching Capacity | 128 Gbps |
| Throughput | Up to 95.2 Mpps |
| Form Factor | Rack Mountable |
| Rack Units | 1U |
| Management Features | Web Managed |
| VLAN Support | Yes |
| Quality of Service (QoS) | Yes |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1Q |
| MAC Address Table Size | 16K |
| Packet Buffer Size | 1.5 MB |
| Power Supply Included | Yes |
| Energy Efficient | Yes, IEEE 802.3az (Energy Efficient Ethernet) |
| Dimensions (W x D x H) | 17.42 x 12.7 x 1.73 in |
| Mounting Kits | Included |
