The Ubiquiti Networks R5AC-PTP Rocket ac Point to Point Mid-Band 5GHz Wireless Access Point revolutionizes outdoor wireless connectivity, offering advanced technology and high performance. This device is designed to provide reliable Point-to-Point bridge connections in the 5GHz spectrum, optimizing bandwidth and throughput over long distances. Embrace the power of airMAX ac technology with the R5AC-PTP for unparalleled wireless experience.
| Parameter | Detail |
|---|---|
| Frequency | Mid-Band 5GHz |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Throughput | Up to 450+ Mbps |
| Power Supply | 24V, 1A Gigabit PoE Adapter (Included) |
| Antenna | Supports External RP-SMA Antennas |
Product Features
- airMAX ac Technology for 450+ Mbps Throughput
- Dedicated Wi-Fi Radio for Management
- Plug and Play Integration with Ubiquiti Antennas
- Advanced RF Analytics
- Weather-Resistant Design for Outdoor Use
Product Applications
- Long-Distance Wireless Bridging
- High-Throughput Carrier Backhaul
- Video Surveillance Over IP Networks
| Accessory | Model |
|---|---|
| External Antennas | RP-SMA Compatible Models |
| Gigabit PoE Adapter | 24V, 1A Model |
| Mounting Bracket | Universal Pole Mount |
| Model | Differences |
|---|---|
| R5AC-PTP | N/A |
| R5AC-Lite | Lower throughput, no dedicated management radio |
| PowerBeam ac | Integrated antenna, designed for PtP and PtMP |
To get more information about the Ubiquiti Networks R5AC-PTP Rocket ac and its pricing, please contact us through Live Chat or via email at [email protected]. We're here to help you with all your wireless connectivity needs.
UBNT R5AC-PTP Specification
Ubiquiti Networks R5AC-PTP Rocket ac Point to Point Mid-Band 5GHz Wireless Access Point Specifications | |
| Brand | Ubiquiti |
| Model | UBNT R5AC-PTP |
| Type | Wireless Access Point |
| Frequency Band | 5 GHz Mid-Band |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Frequency | 5170 - 5875 MHz |
| Max. Power Consumption | 8.5W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Operating Temperature | -40 to 80�� C (-40 to 176�� F) |
| Operating Humidity | 5 to 95% Non-Condensing |
| Dimensions | 162 x 84 x 37 mm |
| Encryption | WPA2 AES Only |
| Processor Specs | Atheros MIPS 74Kc, 720 MHz |
| Memory | 128 MB DDR2 |
| LEDs | Power, Ethernet, (4) Signal Strength |
| Signal Strength LEDs | Software-Adjustable to Correspond to Custom RSSI Levels |
| Gain | 27 dBi |
| Max. VSWR | 1.5:1 |
| Polarization | Dual Linear |
| ESD/EMP Protection | Air: �� 24 kV, Contact: �� 24 kV |
| Product Certification | CE, FCC, IC |
