The Ubiquiti UBNT R5AC-PTMP represents a leading solution for high-performance Point-to-Multi Point (PtMP) bridging applications. Engineered with precision, it delivers unmatched efficiency and reliability for a wide range of network deployments, making it an ideal choice for those requiring robust connectivity and maximum performance in diverse environments.
Quick Spec
| Parameter | Data |
|---|---|
| Product Model | UBNT R5AC-PTMP |
| Application | PtMP Bridging |
| Frequency | 5 GHz |
| Throughput | 500+ Mbps |
| Network Interface | (1) 10/100/1000 Ethernet Port |
Product Features
- High-Performance airMAX ac technology
- Dedicated Wi-Fi Radio for Management
- Plug and Play Integration
- Advanced RF analytics
- Weather-Resistant Design
Product Applications
Specific scenarios where the UBNT R5AC-PTMP excels include:
- Rural Internet Service Provision
- Campus-wide Networking
- Urban Infrastructure Connectivity
Supported Options
| Accessory | Model |
|---|---|
| Antennas | airMAX ac Antennas |
| Mounting | Universal Arm Bracket |
| Enclosures | Outdoor UV Stabilized Plastic |
Compare to Similar Items
| Model | Differences |
|---|---|
| UBNT R5AC-LITE | Lower throughput and no dedicated management radio |
| UBNT PowerBeam AC | Directional, for PtP applications |
| UBNT LiteBeam AC | More cost-effective, slightly lower performance |
Get more information
For further details about the UBNT R5AC-PTMP and insights on pricing, feel free to contact us through Live Chat or email us at [email protected]. Our team of experts is ready to assist you with your queries and help you make the right choice for your networking needs.
UBNT R5AC-PTMP Specification
UBNT R5AC-PTMP Specifications |
|
| Brand | Ubiquiti |
| Model Name | UBNT R5AC-PTMP |
| Application | Point-to-Multi Point (PtMP) Bridging |
| Frequency | 5 GHz |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Enclosure | Outdoor UV Stabilized Plastic |
| Max. Power Consumption | 8.5W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | Passive Power over Ethernet (48V), 802.3at Supported |
| Gain | 26 dBi |
| Processor Specs | Atheros MIPS 74Kc, 720 MHz |
| Memory | 128 MB DDR2 SDRAM |
| LEDs | Power, Ethernet, (4) Signal Strength |
| Signal Strength LEDs | Software-Adjustable to Correspond to Custom RSSI Levels |
| Maximum Throughput | 450+ Mbps |
| Maximum Range | Up to 25+ km |
| Security | WPA2 AES Only |
| Operating Temperature | -40 to 80�� C (-40 to 176�� F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Software | airOS? 7 |
| Regulatory Compliance | FCC, IC, CE |
| Supported Voltage Range | 18-24VDC |
