The ASA5515-SSD120-K9 is one of the ASA5515-X series firewalls, which deliver up to 1.2 Gbps stateful inspection throughput, 250 IPsec VPN peers, 250,000 concurrent connections and 1 expansion slot. They ideally suits for the small, mid-size enterprises or branch offices. ASA5515-SSD120-K9 is integrated with 120G SSD which can install the FirePower services and monitored the overall security by using FireSight Management Center.
Quick Specs
Figure 1 shows the appearance of ASA5515-SSD120-K9.
Table 1 shows the Quick Specs.
|
Product Code |
ASA5515-SSD120-K9 |
|
Bundle |
Integrated with 120G SSD which can install the FirePower services and monitored the overall security by using FireSight Management Center. |
|
Interfaces |
6 copper GE ports, 1 copper GE management port |
|
Stateful inspection throughput (multiprotocol) |
600 Mbps |
|
Maximum 3DES/AES VPN throughput |
250 Mbps |
|
IPsec site-to-site VPN peers |
250 |
|
Virtual interfaces (VLANs) |
100 |
|
Height (rack units) |
1 RU |
|
Dimensions (D x H x W) |
4.24 x 42.9 x 39.5 cm |
Product Details
Figure 2 shows the front panel of ASA5515-SSD120-K9.
Notes:
|
① |
Power button |
|
② |
Front Panel LED |
|
③ |
Hard-disk release button |
Figure 3 shows the back panel of ASA5515-SSD120-K9.
Note：
|
① |
Back Panel LED: Power, Alarm, Boot, Active, VPN, HD0, HD1 |
④ |
Power supply |
|
② |
Console port |
⑤ |
GigabitEthernet data interfaces (0/0 through 0/5) |
|
③ |
USB Ports |
⑥ |
Management 0/0 interface |
· The GigabitEthernet interface connects with an RJ-45 cable and must be restricted to management use only
Compare to Similar Items
Table 3 shows the comparison of ASA5515-SSD120-K9 and ASA5515-K9.
|
Models |
ASA5515-SSD120-K9 |
|
|
Bundle |
Integrated with 120G SSD |
None |
|
Interfaces |
6 GE Copper |
6 GE Copper |
|
Stateful Inspection Throughput(multiprotocol) |
1.2 Gbps |
1.2 Gbps |
|
Maximum 3DES/AES VPN Throughput |
250 Mbps |
250 Mbps |
Get more information
Do you have any question of ASA5515-SSD120-K9?
Contact us now via Live Chat or [email protected].
ASA5515-SSD120-K9 Specification
ASA5515-SSD120-K9 Specification |
|
|
Stateful inspection throughput (maximum) |
1.2 Gbps |
|
Stateful inspection throughput (multiprotocol]) |
600 Mbps |
|
ASA IPS throughput |
400 Mbps |
|
Next-generation firewall throughput(multiprotocol) |
350 Mbps |
|
Triple Data Encryption Standard/Advanced Encryption Standard (3DES/AES) VPN throughput |
250 Mbps |
|
IPsec VPN peers |
250 |
|
Cisco AnyConnect Premium VPN peers (included; maximum) |
2; 250 |
|
Concurrent connections |
250,000 |
|
New connections per second |
15,000 |
|
Virtual interfaces (VLANs) |
100 |
|
Security contexts[7](included; maximum) |
2, 5 |
|
High availability |
Active/active and active/standby |
|
Expansion slot |
1 interface card |
|
User-accessible Flash slot |
No |
|
USB 2.0 ports |
2 |
|
Integrated I/O |
6 GE copper |
|
Expansion I/O |
6 GE copper or |
|
Memory |
8 GB |
|
Dimensions (H x W x D) |
1.67 x 16.7 x 15.6 In (4.24 x 42.9 x 39.5 cm) |
|
Weight (with AC power supply) |
13.39 lb (6.07 kg) |
