ITCS U6-Mesh

U6-Mesh

Brands: Ubiquiti

(0 reviews)

1174.50 1305.00 10% Off

Model: U6-Mesh: Indoor/outdoor, 4x4 WiFi 6 access point

Detail: Indoor/outdoor, 4x4 WiFi 6 access point designed for mesh applications.

Categories: Wireless / Ubiquiti Outdoor Access Points
Tags:

The Access Point WiFi 6 Mesh (U6 Mesh) is a high-performance, four-stream WiFi 6 access point that provides best-in-class signal meshing to enhance the wireless coverage of home and enterprise networks.

Quick Specs

Figure 1 shows the appearance of U6-Mesh.

Table 1 shows the Quick Specs.

Product Code	U6-Mesh
Management interfaces	Ethernet Bluetooth
Networking interface	(1) GbE RJ45 port
Supported voltage range	44 to 57VDC
Max. power consumption	11.4W

Product Details

Figure 2 shows the front panel of U6-Mesh.

U6-Mesh provides these features:

High-efficiency 4x4 WiFi 6 (802.11ax)
5 GHz (4x4 MU-MIMO and OFDMA) band with a 4.8 Gbps throughput rate
4 GHz (2x2 MIMO) band with a 573.5 throughput rate
Operates at full 4x4 MIMO with 160 MHz bandwidth
Powered with 802.3af PoE (PoE adapter included)

Compare to Similar Items

Table 2 shows the comparison of U6-Mesh.

Module	U6-Mesh	U6-LR
Management interfaces	Ethernet Bluetooth	Ethernet Bluetooth
Networking interface	(1) GbE RJ45 port	(1) GbE RJ45 port
Supported voltage range	44 to 57VDC	44 to 57VDC
Max. power consumption	11.4W	16.5W

Get More Information

Do you have any question about the U6-Mesh?

U6-Mesh Specification

U6-Mesh specification
Mechanical
Dimensions	Ø48.5 x 159.5 mm (Ø1.9 x 6.28")
Enclosure material	Plastic, aluminum
Mount materials	Plastic
Weatherproofing	IPX5
Hardware
Management interfaces	Ethernet Bluetooth
Networking interface	(1) GbE RJ45 port
Button	Factory reset
LED*	White/blue *Due to chip supply shortages, the U6 AP's LED has been limited to only white and blue color modes.
Power method	802.3af PoE
Power supply	UniFi PoE switch 48V, 0.32A PoE adapter (included)
Supported voltage range	44 to 57VDC
Max. power consumption	11.4W
Max. TX power 2.4 GHz 5 GHz	22 dBm 26 dBm
MIMO 2.4 GHz 5 GHz	2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO)
Throughput rate 2.4 GHz 5 GHz	573.5 Mbps 4.8 Gbps
Antenna gain 2.4 GHz 5 GHz	3 dBi 5 dBi
Mounting	Wall, desktop, pole mount(included) Ceiling mount (optional)
Operating temperature	-30 to 60° C (-22 to 140° F)
Operating humidity	5 - 95% noncondensing
Certifications	CE, FCC, IC
Software
WiFi standards	802.11a/b/g WiFi 4/WiFi 5/WiFi 6
Wireless security	WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID	8 per radio
VLAN	802.1Q
Advanced QoS	Per-user rate limiting
Guest traffic isolation	Supported
Concurrent clients	300+
Zero wait DFS	Yes* *Supported with upcoming firmware versions
Supported Data Rates
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b	1, 2, 5.5, 11 Mbps
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)	6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5)	6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)	7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
